Stirling - 1 Drawer 2 Door Robe
Assembly Instructions -
Dimensions
Width - 72cm
Depth - 49cm
Height - 189cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
343/9049
345/7162
MADE IN
BRITAIN
Issue 1 - 07/11/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Stirling 343/9049
Summary of Contents for Argos Stirling 343/9049
- Page 1 Stirling - 1 Drawer 2 Door Robe Assembly Instructions - 343/9049 Please keep for future reference 345/7162 Dimensions Width - 72cm Depth - 49cm MADE IN Height - 189cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 07/11/14...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 48kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (D3014A) (718 x 490mm) Base (D3015B) (718 x 490mm) Left Side Right Side (D3016A) (D3017A)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the large drawer sides and down into the groove in the large drawer front Step 5 Fit the large drawer back Fit the drawer back between the drawer sides Make sure that the...
- Page 7 Assembly Instructions Step 8 Prepare the left side Fit 3 hinge plates to the left side making sure that the slot is facing towards the finished front edge. Push a rail holder into the left side . Make sure that it is fitted straight, in line with the panel edges and then secure with screw...
- Page 8 Assembly Instructions Step 9 Prepare the right side Fit 3 hinge plates to the right side making sure that the slot is facing towards the finished front edge. Push a rail holder into the right side . Make sure that it is fitted straight, in line with the panel edges and then Finished front edge...
- Page 9 Assembly Instructions Step 11 Prepare the back rail Plain chipboard Insert 2 large locking surface nuts into the back rail Finished front edge Note: The arrow on the locking nut must point towards the hole in the edge of the panel. Tap 2 wooden dowels into the back rail 10mm...
- Page 10 Assembly Instructions Step 13 Fit the left side Push the left side onto the horozontal and back rail Attach the left side the horizontal using 2 screws Use a screwdriver to tighten the large locking fitted to the back rail Step 14 Fit the top Attach the top...
- Page 11 Assembly Instructions Step 15 Fit the base Attach the base the left side and right side using 4 screws p l a c h i s u r f a c Step 16 Fit the feet Fit the 4 feet to the base using 4 screws .
- Page 12 Assembly Instructions Step 17 The measurement from top corner X to bottom corner X must be Fit the back equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y.
- Page 13 Assembly Instructions Step 19 Fit the hanging rail Push hanging rail into the rail holders fitted to the side panels. Step 20 Prepare the 2 doors Push fit 3 hinges into each of the 2 doors Secure each hinge with 2 screws Note: Before securing with the screws, make...
- Page 14 Assembly Instructions Step 21 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 15 Assembly Instructions Step 22 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 16 Lift with care. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3105...
