- Page 1 Mendoza - 2 Door 1 Drawer Robe 330/9430 346/6744 355/4041 Width - 90cm Depth - 53cm Height - 180cm If you need help or have damage or missing parts, call the Customer Helpline: 03456 400 800 Issue 1 - 12/09/12...
- Page 3 5 Fixed shelf 2 Base (82.3 x 48cm) (82.3 x 49.1cm) 1 Top panel (90 x 53cm) 3 Left side panel 4 Right side panel (177.5 x 49.6cm) (177.5 x 49.6cm) 7 Side plinth x 2 8 Front plinth (88.8 x 9cm) (51.4 x 8.8cm) 10 H profile 9 Hanging rail...
- Page 4 If you have damaged or missing components, call the Customer Helpline: 03456 400 800 30mm Screw x 46 Ø8x25mm Wooden dowel x 48 45mm Screw x 08 25mm Screw x 09 16mm Screw x 48 Ø8x35mm Large wooden dowel x 02 Nails x 50 Hanging rail support x 2 Metal door knocker x 01...
- Page 5 Fitting wooden dowels: Insert dowels into holes in the indicated parts. Fix hanging rail support in the pre marked holes on the left side panel and right side panel using screws Attention pre marked holes Attention pre marked holes...
- Page 6 Fixing door clip and knocker: Fix door clip in the pre marked holes on top rail using screws as shown. Fix straight door Attention knocker in the pre pre marked holes marked holes on top rail using screws as shown. Attention! Step 3 Fixing front frames:...
- Page 7 Attention correct Fixing front frames: holes position. Attention correct holes position. Fix right front frame 5mm. the right side panel through blocks using 48mm. screws as shown. Attention: Note correct position of parts before fixing. Fixing front frames: Fix left front frame the left side panel through blocks using...
- Page 8 Step 6 Note: Make sure rounded edges are facing up and holes are facing down on bottom rail Assembling the cabinet: (Two people required for Door clip to be an easier assembly) facing down. With help, fit base panel , fixed shelf , top rail , bottom rail...
- Page 9 Step 8 Assembling the cabinet: Attention to the Fix side plinths parts alignment the side panels using screws Note: Make sure side plinths are aligned to the bottom and front edges of the side panels. Fix front plinth the bottom frame using screws Note: Make sure...
- Page 10 Step 10 Fixing back panels: Carefully turn the product upright. Important: Cabinet MUST be “square” when back panels ate attached. Attach the right back panel first using nails Position profile large profile and small profile to the attached back panel. Carefully slot the second back panel into...
- Page 11 Step 12 Preparing the doors: Attention pre marked holes Right door: Fix door clips to the pre marked holes on right door using screws as shown. Attach right hinge to the pre marked holes on right door using screws Note: Make sure hinges are positioned as shown in the diagram.
- Page 12 Step 13 Carefully turn the doors with their front facing up. Fix handles to the doors using bolts Step 14 Fixing hinges: Fix left door hinges to the pre Attention marked holes on the left front frame as shown. pre marked holes Note correct position of the hinge prior to fixing.
- Page 13 Step 15 Assembling the drawers: Attach drawer sides to the drawer front using screws Slide drawer bottom into slots on drawer sides. Holding the drawer back in place and flush to the edge of drawer side, fix them to the drawer back using screws Using bolt attach...
- Page 14 Step 17 Insert drawer into unit. With the back of the drawers past the front frames, use a hammer to tap the dowels in flush to the drawer sides. This is a safety catch to stop drawers falling out. Step 18 Fixing to wall.
