General Information:
Read through carefully before beginning assembly.
»
When assembling components, place on a clean, flat,
»
non-abrasive surface to avoid scratches.
In the event of missing or defective parts, please call our
»
customer service department directly at 1-877-258-6020
Tools required:
Cordless Drill with #2 phillips bit
»
Tape measure
»
Shovel
»
PVC or Super Glue
»
FIGURE 1
Part identification
4'
4' Three Board
x
planter BEd
Model# 11182
Part #
1
4" sq. x 24" Corner Post
2
1½" x 5½" x 48" Rail
3
1½" x 5½" x 45" Rail
4
4" sq. Flat Post Cap
5
Hardware Kit (includes):
2" Kappet Screws
Kappet Screw Caps
FIGURE 3
Product Dimensions
Assembly Instructions
Parts List:
Description
FIGURE 2
Product Planting
Dimensions
Qty
4
6
6
4
48
48
Advertisement
Table of Contents
Related Manuals for Dura Trel 11182
Summary of Contents for Dura Trel 11182
- Page 1 4’ 4’ Three Board planter BEd Model# 11182 Assembly Instructions Parts List: Part # Description General Information: 4” sq. x 24” Corner Post 1½” x 5½” x 48” Rail Read through carefully before beginning assembly. » When assembling components, place on a clean, flat, »...
- Page 2 Insert ends of three 1½” x 5½” x 48” rails (part 2) into two 4” x 4” x 24” corner posts (part 1). Using 2” kappet screws, screw together planter bed side. Snap kappet screw caps over screw heads. Be sure all parts are fully inserted into posts before securing.
