Dura Trel Compost Bin Deluxe Assembly Instructions

TOOLS NEEDED:

Drill with #2 Phillips Bit (recommended) or
Phillips Screwdriver
Super or Crazy Glue

BACK PANEL ASSEMBLY

(Refer to Left Side of Drawing 1)
Lay both back posts on a flat surface with screw pilot holes facing upwards and routed holes for rails facing
inwards. Slide the 35 ¾" back rails completely into routed slots in both posts. Fasten with 1 ¼" screws and
snap screw caps over screw heads.

FRONT PANEL ASSEMBLY

(Refer to Right Side of Drawing 1)
Lay both front posts on flat surface with straight routed holes for front rails facing inward. Slide the 35 ¾"
front braces completely into the top and bottom routed holes of both posts. Fasten with 1 ¼" screws, snap
screw caps over screw heads.

COMPOST BIN ASSEMBLY

(Refer to Drawing 2)
With back panel laying flat with routed openings facing up; slide the angled side rails completely into both
back posts. Fasten with 1 ¼" screws, snap caps over screw heads. Next slide front panel onto side
rails making sure there is enough gap inside front posts to easily slide removable front rails
in and out. Fasten side rails to front posts. Apply glue to inside edges of 4 x 4" post caps and place on top
of posts.
Insert Front Removable Rails by sliding into one post completely then slide into other post, adjust so Handle
cutouts line up evenly down center.
If you encounter missing or defective parts, please contact manufacturer direct at toll free #
Dura-Trel, Inc. ~ PO Box 122, Sheboygan Falls, WI 53085 ~ Toll Free 877-258-6020
#11134 C
