max 5 x 3.5
General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... Tape Measure
... Hammer or Rubber Mallet
... Shovel or Post Hole Digger
... PVC, Super, or Crazy Glue
with #2 phillips bit
(recommended)
(recommended)
Winchester Trellis
11174 (M)
Model#
Part #
1
2" sq. x 84" Left Post
2
2" sq. x 84" Right Post
3
⅞ x 1½ x 56¾" Center
4
⅞ x 1½ x 56¾" Bottom
5
⅞ x 3 x 56¾" Rail
6
1 x 1 x 84" Rail
7
1 x 1 x 82" Rail
8
1 x 1 x 80" Rail
9
1 x 1 x 78" Rail
10
Hardware Bag
¾ x 2½" Spacer Tube
2" sq." Post Cap
1 x 1" Arrowhead Cap
¾" Painted Screw
#10 - 6" Screw
#10 - Screw Cap
#10 - Screw Backer
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
1
1
10
1
1
1
2
2
2
1
4
2
7
17
4
4
4
1
Advertisement
Table of Contents
Related Manuals for Dura Trel Winchester Trellis 11174
Summary of Contents for Dura Trel Winchester Trellis 11174
- Page 1 Winchester Trellis 11174 (M) Model# Assembly Instructions Part # Description 2" sq. x 84" Left Post max 5 x 3.5 2" sq. x 84" Right Post ⅞ x 1½ x 56¾" Center ⅞ x 1½ x 56¾" Bottom ⅞ x 3 x 56¾" Rail 1 x 1 x 84"...
- Page 2 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
- Page 3 Lay out one right post (part 2). Starting at bottom, insert bottom support rail (part 5), bottom cross rail (part 4) and center cross rails (part 3). Slide left post (part 1) over corresponding support and cross rails. Starting with center hole, insert 84” vertical rail (part 6) through cross rails.
- Page 4 Working outward away from center, insert 82” vertical rails (part 7) through cross rails. Insert 80” vertical rails (part 8) through cross rails. Insert 78” vertical rails (part 9) through cross rails. Winchester Trellis 4...
- Page 5 Using ¾" painted screws, screw together trellis. Be sure that all parts are fully inserted into posts before securing. Using PVC, super or crazy glue, glue post caps onto posts and arrowhead caps onto vertical rails. To secure to wall, slide 6” screw through clear screw backer.
- Page 6 Winchester Trellis 11174 2" sq. x 84" WCT Left Post 1.00 2" sq. x 84" WCT Right Post 1.00 ⅞ x 1½ x 56¾" WCT Center 10.00 ⅞ x 1½ x 56¾" WCT Bottom 1.00 ⅞ x 3 x 56¾" Rail 1.00 1 x 1 x 84"...
