General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
or
... Phillips Screwdriver
... Tape Measure
... Rubber Mallet or Hammer
(recommended)
with #2 phillips bit
(optional but recommended)
3/4' Grapevine Arbor
11119/09
Model#
Part #
1
⅞ x 1½ x 60½" Left Leg
2
⅞ x 1½ x 60½" Right Leg
3
⅞ x 1½ x 28" Top/Bottom Cross Rail
4
⅞ x 1½ x 28" Center Cross Rail
5
⅝ x 53" Tube
6
⅞ x 1½ x 36 / 48" Arbor Top
7
¾ x 27 ⅞" Tube
8
⅞ x 1½ x 12" Flared Ground Anchor
9
Hardware Bag
¾" Painted Screw
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
2
2
4
2
10
2
5
4
1
22
1
