Dura Trel PROVIDENCE ARBOR Assembly Instructions

max 5 x 3.5

General Information

PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches

Tools Required

... Battery or Electric Drill
... Tape Measure
... Hammer or Rubber Mallet
with #2 phillips bit
(recommended)
Providence Arbor
11178 (M)
Model#
Part #
1 2" sq. x 84" Left Post
2 2" sq. x 84" Right Post
3 ⅞ x 1½ x 22" Top/Bottom Cross Rail
4 ⅞ x 1½ x 22" Center Cross Rail
5 ¼ x 1½ x 59½" Vertical Slat
6 1½ x 4 x 64" Arbor Top
7 ⅞ x 1½ x 28" Arbor Top Cross Rail
8 ⅞ x 1½ x 16" Corner Brace
9 5 ⅜" Arbor Top End Cap
10 Hardware Bag
2" sq. Post Cap
⅞ x 1½" End Cap
1¼" Painted Screw
Super Glue Tube
11 Arbor Ground Anchor Kit
16" Steel Ground Anchor (L-Shaped)
#8 - 1" Painted Self Tapping Screw
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
(includes:)
1-877-258-6020
www.dura-trel.com
