UX552

Product Specifications
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
DVI DVI-D 24pin
DisplayPort DisplayPort Connector
VGA (RGB)* 4 15pin Mini D-sub
HDMI HDMI Connector
VGA 15pin Mini D-sub
(YPbPr)* 4
Output Signal
DisplayPort DisplayPort Connector
HDMI HDMI Connector
AUDIO
AUDIO Input Stereo Mini Jack
HDMI Connector
DisplayPort Connector
AUDIO Stereo Mini Jack
Output
Speaker Output
Control
SD card Hub
USB Hub
Power Supply
External Power Supply
Power Consumption
Operational Environment
Storage Environment
Dimension*
5
Weight
VESA compatible mounting interface
Power Management
Power supply for Slot 2 type OPTION
NOTEE: Technical specifications are subject to change without notice.
* 1 : Compressed image.
* : When you use Option Board accessories, please contact your supplier for detailed information.
2
* 3 : Reproduced text may look blurred.
* : Common terminal.
4
* 5 : Measurements are of the monitor only and do not include removable parts that protrude.
55"/138.8 cm diagonal
Pixel Pitch: 0.630 mm
Resolution: 1920 x 1080
Color: Over 16 million colors (depending on display card used)
Brightness: 700 cd/m (Max.) @25 °C
2
Contrast Ratio: 4000:1
Viewing Angle: 89° (typ) @ CR>10
Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz
Vertical: 50.0 - 85.0 Hz (Analog Input)
24.0 - 85.0 Hz (Digital Input)
Analog: 13.5 MHz, 25.0 MHz - 200.0 MHz
Digital: 25.0 MHz - 165.0 MHz (DVI), 25.0 MHz - 600.0 MHz (HDMI/DisplayPort)
1209.60 x 680.40 mm
Digital RGB DVI (HDCP 1.4)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Digital RGB DisplayPort V1.2 (HDCP 1.3)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1080p, 1080i, 720p@50 Hz/60 Hz, 576p@50 Hz, 480p@60 Hz, 3840x2160 (24 Hz/30 Hz/60 Hz
(DisplayPort1.2))*
Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Digital YUV HDMI (HDCP 1.4/2.2)
Digital RGB VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1080p, 1080i, 720p@50 Hz/60 Hz, 576p@50 Hz, 480p@60 Hz, 576i@50 Hz, 480i@60 Hz,
3840x2160 (30 Hz/24 Hz/25 Hz/60Hz (MODE2))*
Component Y: 1.0 Vp-p/75 ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p, 1080i, 720p@50 Hz/60 Hz, 576p@50 Hz, 480p@60 Hz, 576i@50 Hz, 480i@60 Hz
Digital RGB DisplayPort V1.2 (HDCP 1.3)
Digital RGB HDMI (HDCP 1.4/2.2)
Analog Audio Stereo L/R 0.5 Vrms
Digital Audio PCM 32, 44.1, 48 kHz (16/20/24 bit)
Digital Audio PCM 32, 44.1, 48 kHz (16/20/24 bit)
Analog Audio Stereo L/R 0.5 Vrms
External Speaker Jack 15 W + 15 W (8 ohm)
RS-232C In: 9 Pin D-sub
LAN: RJ-45 10 BASE-T/100 BASE-TX x 2
Remote IN: Stereo Mini Jack 3.5 mm Ø
Port: microSD card. Up to 32 GB microSDHC is supported.
USB1 (SENSOR): USB 2.0 Downstream port
USB2: USB 2.0 Upstream port
USB CM1 (2A): Power supply port, 5 V/2 A (max.)
USB CM2: USB service port for maintenance
Media Player USB: Media Player/Firmware update port
4.9 - 1.9 A @ 100-240 V AC, 50/60 Hz
Please refer to Appendix D (see
Normal operation: Approx. 195 W
Temperature* : 0 - 40 °C / 32 - 104 °F
2
Humidity: 20 - 80 % (without condensation)
Altitude: 0 - 3000 m (Brightness may decrease with altitude)
Temperature: -20 - 60 °C / -4 - 140 °F
Humidity: 10 - 90 % (without condensation) / 90 % - 3.5 % x (Temp - 40 °C) regarding over 40 °C
1213.5 (W) x 684.3 (H) x 100.3 (D) mm/47.78 (W) x 26.94 (H) x 3.95 (D) inches
29.3 kg (64.6 lbs)
400 mm x 400 mm (M6, 4 Holes)
VESA DPM
16 V/3.6 A
English−96
*
1, 3
*
1,
page 126)
1 , 1920X1080 (60 Hz), 1080p, 1080i
, WUXGA60* , 1920x1080 (60 Hz),
1 1
, WUXGA60* , 1920X1080 (60 Hz)
1 1
, WUXGA60* , 1920x1080 (60 Hz),
1 1
, 4096x2160 (24 Hz)* *
3 1, 3
