CYBEX R Series Assembly Instructions Manual page 22

Install Accessory Tray Bottom
1. Install the grommet to the frame.
2. Install screws securing the accessory tray bottom to the accessory tray top using a Phillips screwdriver.
3. Install screw securing the accessory tray bottom to the frame using a Phillips screwdriver.
Install Side Handles
1. Remove three locknuts from left support leg using 17mm open-end wrench and 6mm Allen wrench. Keep the
two spacers in place.
Item
1
2
Screw, Pan Head Phillips, 8-16 x
3
Item
1
2
Item
1
2
3 Screw, Pan Head Phillips, 6 x .50"
Screw, Pan Head Phillips, 8-16 x
4
Page 22 of 47
Description
Accessory Tray Top
Accessory Tray Base
.50"
Description
Grommet, Nylon, Long
Frame
Description
Accessory Tray Bottom
Accessory Tray Top
.50"
Qty.
1
1
2
Qty.
1
1
Qty.
1
1
2
1
