  • Page 1 MVME4100ET Single Board Computer Installation and Use P/N: 6806800K76G May 2016...
  • Page 2 Artesyn reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Artesyn to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    Factory Installed Linux ............. . 52 MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 4 4.11 XMC Expansion ..............85 MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 5 6.5.3 Displaying VME Settings ........... . . 111 MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 6 Related Documentation ............. . 125 Artesyn Embedded Technologies - Embedded Computing Documentation ....125 Manufacturers’...
  • Page 7 MVME4100ET Specifications ........
  • Page 8 List of Tables Table B-1 Artesyn Embedded Technologies - Embedded Computing Publications ....125 Table B-2 Manufacturer’s Publications ........... .125 Table B-3 Related Specifications .
  • Page 9 Battery Location ............121 MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 10 List of Figures MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 11: About This Manual

    About this Manual Overview of Contents This manual provides the information required to install and configure an MVME4100ET Single Board Computer. Additionally, this manual provides specific preparation and installation information and data applicable to the board. The MVME4100ET Single Board Computer, with the Freescale MPC8548E System on Chip (SoC) processor, provides a high-performance, cost-effective continuation for currently deployed VME infrastructure.
  • Page 12 Institute of Electrical and Electronics Engineers Inter IC JTAG Joint Test Access Group KBAUD Kilo Baud Local Bus Controller Mbps Megabits Per Second NAND (Not and) Flash that is used for storage MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 13 Static Random Access Memory TSEC Three-Speed Ethernet Controller 2eSST Two edge Source Synchronous Transfer UART Universal Asynchronous Receiver/Transmitter Volts Input/Output Voltage VITA VMEbus International Trade Association Versa Module Eurocard Vital Product Data Watts MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 14 Repeated item for example node 1, node 2, ..., node Omission of information from example/command that is not necessary at the time being Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers) Logical OR MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 15 Safety Notes on page 17 Sicherheitshinweise on page 6806800K76C July 2011 Updated Table "MVME4100ET Specifications" on page 6806800K76B March 2011 Minor correction to Factory Installed Linux on page 6806800K76A July 2010 Initial version MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 16 About this Manual About this Manual MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 17: Safety Notes

    Artesyn intends to provide all necessary information to install and handle the product in this manual. Because of the complexity of this product and its various uses, we do not guarantee that the given information is complete.
  • Page 18 Changes or modifications not expressly approved by Artesyn Embedded Technologies could void the user's authority to operate the equipment. Board products are tested in a representative system to show compliance with the above mentioned requirements.
  • Page 19 When exchanging the on-board lithium battery, make sure that the new and the old battery are from exactly the same battery manufacturer and of the same models. If the respective battery model is not available, contact your local Artesyn sales representative for the availability of alternative, officially approved battery models.
  • Page 20 Environment Always dispose of used batteries, boards, and RTMs according to your country’s legislation and manufacturer’s instructions. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 21: Sicherheitshinweise

    Produkt mit vielfältigen Einsatzmöglichkeiten handelt, können wir die Vollständigkeit der im Handbuch enthaltenen Informationen nicht garantieren. Falls Sie weitere Informationen benötigen sollten, wenden Sie sich bitte an die für Sie zuständige Geschäftsstelle von Artesyn. Das Produkt wurde entwickelt, um die Sicherheitsanforderungen für SELV Geräte nach der Norm EN 60950-1 für informationstechnische Einrichtungen zu erfüllen.
  • Page 22 Sicherheitshinweise Das Produkt wurde in einem Artesyn Standardsystem getestet. Es erfüllt die für digitale Geräte der Klasse A gültigen Grenzwerte in einem solchen System gemäß den FCC-Richtlinien Abschnitt 15 bzw. EN 55022 Klasse A. Diese Grenzwerte sollen einen angemessenen Schutz vor Störstrahlung beim Betrieb des Produktes in Gewerbe- sowie Industriegebieten...
  • Page 23 Funktionen belegt sein. Das Ändern dieser Schalter kann im normalen Betrieb Störungen auslösen. Verstellen Sie nur solche Schalter, die nicht mit "Reserved" gekennzeichnet sind. Prüfen und ggf. ändern Sie die Einstellungen der nicht mit "Reserved" gekennzeichneten Schalter, bevor Sie das Produkt installieren. MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 24 Wenn Sie die Batterie schnell austauschen, bleiben die Zeiteinstellungen möglicherweise erhalten. Datenverlust Wenn die Batterie wenig oder unzureichend mit Spannung versorgt wird, wird der RTC initialisiert. Tauschen Sie die Batterie aus, bevor sieben Jahre tatsächlicher Nutzung vergangen sind. MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 25 Um Schäden zu vermeiden, sollten Sie keinen Schraubendreher zum Ausbau der Batterie verwenden. Umweltschutz Entsorgen Sie alte Batterien und/oder Boards/RTMs stets gemäß der in Ihrem Land gültigen Gesetzgebung und den Empfehlungen des Herstellers. MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 26 Sicherheitshinweise MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 27: Introduction

    The MVME4100ET Single Board Computer is a VMEbus board based on the MPC8548E Integrated Processor. It is a full 6U board and occupies a single VME card slot with PMC cards installed. The MVME4100ET is compliant with the VITA standards VMEbus, 2eSST, and PCI-X as listed in Appendix B, Related Documentation.
  • Page 28 ANSI/VITA 1.7-2003 compliant (Increased Current Level for 96 pin & 160 pin DIN/IEC Connector Standard) VITA 41.0, version 0.9 compliant Two five-row P1 and P2 backplane connectors One Tsi148 VMEbus controller Form Factor Standard 6U VME, one slot MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 29: Standard Compliances

    Switches for VME geographical addressing in a three-row backplane Software Support VxWorks OS support Linux OS support Standard Compliances The MVME4100ET is designed to be CE compliant and to meet the following standard requirements. Table 1-2 Board Standard Compliances Standard Description...

  • Page 30: Mechanical Data

    6U, 4HP wide, (233.4 mm x 160 mm x 19.8 mm) Weight 0.453 kg Ordering Information While ordering board variants or board accessories, use the order numbers given in the following tables. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 31: Supported Board Models

    Introduction 1.4.1 Supported Board Models The MVME4100ET Single Board Computer is available in the configurations shown below. Table 1-4 Board Variants Marketing Number Processor MVME4100ET-0171 1.3GHZ MPC8548E, 4G NAND FLASH, 2G DDR2-533 SO-CDIMM, SCANBE at -40C to +71c operating temperature MVME4100ET-0173 1.3GHZ MPC8548E, 4G NAND FLASH, 2G DDR2-533 SO-CDIMM, IEEE at...

  • Page 32: Board Accessories

    Introduction 1.4.2 Board Accessories The following table lists the available expansion and transition modules for the MVME4100ET. Table 1-5 Board Accessories Model Number Description MVME721ET-101 Rear Transition Module at -40C to +71c operating temperature MVME721ET-102 RTM with the SCANBE handles...

  • Page 33: Serial Number Label

    You can find the serial number of the product on a label that is located on the PCB close to the front panel. The following figure shows a sample label and its location. The actual label on your product may vary in content and location. Figure 1-1 Serial Number Label Location MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 34 Introduction MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 35: Hardware Preparation And Installation

    A fully implemented MVME4100ET consists of the following along with the base board: Two single-wide or one double-wide PCI Mezzanine Card (PMC) slot for added versatility.  One transition module for support of the mapped I/O from the MVME4100ET base board  to the P2 connector.

  • Page 36: Unpacking And Inspecting The Board

    3. Remove the desiccant bag shipped together with the board and dispose of it according to your country’s legislation. The product is thoroughly inspected before shipment. If any damage occurred during transportation or any items are missing, contact customer service immediately. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 37: Requirements

    Sweep rate: 0.25 octaves/minute Humidity Designed to operate up to 100% relative humidity, Non condensing The RTC field removable battery should be removed, if MVME4100ET has to be stored beyond its operational temperature range. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 38: Power Requirements

    MVME4100ET-0173 Typical: 18 W at +5 V Maximum: 22 W at +5 V The following table shows the power available when the MVME4100ET is installed in either a 3- row or 5-row chassis and when PMCs are present. Chassis Type...

  • Page 39: Thermal Requirements

    2.3.3 Thermal Requirements The MVME4100ET module requires a minimum air flow of 14 CFM uniformly distributed across the board, with the airflow traveling from the heat sink to the PMC2 site, when operating at a 71°C (160 °F) ambient temperature.

  • Page 40: Figure 2-1 Primary Side Thermally Significant Components

    Hardware Preparation and Installation Figure 2-1 Primary Side Thermally Significant Components MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 41: Equipment Requirements

    Transition module and connecting cables  Configuring the Board To produce the desired configuration and ensure proper operation of the MVME4100ET, you may need to carry out certain hardware modifications before installing the module. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 42: Switch Locations

    The MVME4100ET control registers are described in the MVME4100ET Programmer’s Reference. Prior to installing PMC modules on the MVME4100ET base board, ensure that all switches that are user configurable are set properly. To do this, refer to...

  • Page 43: Smt Configuration Switch, S1

    2.4.1 SMT Configuration Switch, S1 An 8-position SMT configuration switch is located on the MVME4100ET to control the flash bank write-protect, select the flash boot image, and control the safe start ENV settings. The default setting on all switch positions is OFF and is indicated by brackets in Table 2-5.

  • Page 44: Geographical Address Switch, S2

    Geographical Address Switch, S2 The Tsi148 VMEbus Status Register provides the VMEbus geographical address of the MVME4100ET. The switch reflects the inverted states of the geographical address signals. Applications that are not using the 5-row backplane can use the geographical address switch to assign a geographical address per the following diagram.

  • Page 45: Table 2-6 Geographical Address Switch Settings

    5-row chassis in order to get the correct address from the P1 connector. This switch also includes the SCON control switches. More information regarding GA address switch assignments can be found in the MVME4100ET Single Board Computer Programmer’s Reference.

  • Page 46: Installing Accessories

    Do not change settings of switches marked as “reserved”. The setting of switches which are not marked as “reserved” has to be checked and changed before board installation. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 47: Pmc

    3.3V or 5.0V I/O PMC modules. To support 3.3V or 5.0V I/O PMC modules, both PMC I/O keying pins must be installed in the holes. If both the keying pins MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 48 33 MHz PCI mode instead of PCI-X mode. The default factory configuration is for 3.3 V PMC I/O voltage. Follow these steps to install a PMC onto the MVME4100ET board. Installation Procedure Read all notices and follow these steps to install a PMC on the base board.

  • Page 49: Figure 2-6 Typical Placement Of A Pmc Module On A Vme Module

    8. If the PMC module was installed in a non-hot swap chassis, replace the chassis or system cover(s), reconnect the system to the AC or DC power source and turn the equipment power on. Figure 2-6 Typical Placement of a PMC Module on a VME Module MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 50: Xmcspan

    This section describes a recommended procedure for installing a board module in a chassis. The MVME4100ET does not support hot swap. You should remove power to the slot or system before installing the module. Before installing the MVME4100ET, ensure that the serial ports and switches are properly configured.

  • Page 51: Completing The Installation

    The MVME4100ET is designed to operate as an application-specific computing blade or an intelligent I/O board/carrier. It can be used in any slot in a VME chassis. When the MVME4100ET is installed in a chassis, you can connect peripherals and apply power to the board.

  • Page 52: Factory Installed Linux

    A bootable ramdisk based Linux image based on the 2.6.27 kernel is available in NOR flash. To boot this image, use the following MOTLOAD commands: MVME4100> bmw -af8000000 -bf8f00000 -c2000000 execP -l2000400 MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 53 Kernel 2.6.27 on a MVME4100 localhost login: Login as root. The /root/README.MVME4100_LINUX file provides a brief overview of MVME4100ET Linux. Contact Artesyn Embedded Technologies for kernel patches and additional information on using MVME4100ET Linux. MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 54 Hardware Preparation and Installation MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 55: Controls, Leds, And Connectors

    Chapter 3 Controls, LEDs, and Connectors Overview This chapter summarizes the controls, LEDs, connectors, and headers for the MVME4100ET base board. Connectors for the MVME721ET transition module are available in Rear Panel Connectors on page MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 56: Board Layout

    Controls, LEDs, and Connectors Board Layout The following figure shows the components, LEDs, connectors, and the reset switch on the MVME4100ET. Figure 3-1 Component Layout MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 57: Front Panel

    Controls, LEDs, and Connectors Front Panel The following switch, LEDs, and connectors are available on the MVME4100ET front panel. Figure 3-2 Front Panel LEDs, Connectors, Switch MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 58: Reset/Abort Switch

    3.3.1 Reset/Abort Switch The MVME4100ET has a single push button switch to provide both the abort and reset functions. When the switch is depressed for less than 3 seconds, an abort interrupt is generated to the MPC8548E PIC. If the switch is held for more than 3 seconds, a board hard reset is generated.

  • Page 59: Connectors

    3.3.3 Connectors This section describes the pin assignments and signals for the connectors on the MVME4100ET. The table below lists the standard connectors on the MVME4100ET base board. Refer to Figure 3-1 on page 56 for connector locations. Pin assignments for the connectors are in the following sections.

  • Page 60: Xmc Expansion Connector (J6)

    Signal TX0_P RX0_P TX0_N RX0_N TX1_P RX1_P TX1_N RX1_N TX2_P RX2_P TX2_N RX2_N TX3_P RX3_P TX3_N RX3_N REFCLK_P No Connect REFCLK_N No Connect No Connect No Connect No Connect PCIE_END_N INT_N RESET_N MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 61 Table 3-3 XMC Expansion Connector (J6) Pin Assignments (continued) Signal Signal TX4_P RX4_P TX4_N RX4_N TX5_P RX5_P TX5_N RX5_N TX6_P RX6_P TX6_N RX6_N TX7_P RX7_P TX7_N RX7_N No Connect No Connect No Connect No Connect TRST_N I2C_CLK I2C_DATA PRESENT_N MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 62: Ethernet Connectors (J4A/J4B)

    3.3.3.3 PCI Mezzanine Card (PMC) Connectors (J11 – J14, J21 – J23) There are seven 64-pin SMT connectors on the MVME4100ET to provide 32/64-bit PCI interfaces and P2 I/O for one optional add-on PMC. PMC slot connector J14 contains the signals that go to VME P2 I/O rows A, C, D, and Z. The pin...
  • Page 63 AD21 AD19 +3.3V (VIO) AD17 FRAME# IRDY# DEVSEL# PCIXCAP LOCK# PCI_RSVD (No Connect) PCI_RSVD (No Connect) +3.3V (VIO) AD15 AD12 AD11 AD09 C/BE0# AD06 AD05 AD04 +3.3V (VIO) AD03 AD02 AD01 AD00 MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 64: Table 3-6 Pmc Slot 1 Connector (J12) Pin Assignments

    Pull-up to +3.3V +3.3V RST# Pull-down +3.3V Pull-down Not Used AD30 AD29 AD26 AD24 +3.3V IDSEL1 AD23 +3.3V AD20 AD18 AD16 C/BE2# IDSEL1B TRDY# +3.3V STOP# PERR# +3.3V SERR# C/BE1# AD14 AD13 MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 65: Table 3-7 Pmc Slot 1 Connector (J13) Pin Assignments

    Table 3-7 PMC Slot 1 Connector (J13) Pin Assignments Signal Signal Reserved (No Connect) C/BE7# C/BE6# C/BE5# C/BE4# +3.3V (VIO) PAR64 AD63 AD62 AD61 AD60 AD59 AD58 AD57 +3.3V (VIO) AD56 AD55 AD54 AD53 AD52 AD51 AD50 MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 66: Table 3-8 Pmc Slot 1 Connector (J14) Pin Assignments

    Table 3-8 PMC Slot 1 Connector (J14) Pin Assignments Signal Signal PMC1_1 (P2-C1) PMC1_2 (P2-A1) PMC1_3 (P2-C2) PMC1_4 (P2-A2) PMC1_5 (P2-C3) PMC1_6 (P2-A3) PMC1_7 (P2-C4) PMC1_8 (P2-A4) PMC1 _9 (P2-C5) PMC1_10 (P2-A5) PMC1_11 (P2-C6) PMC1_12 (P2-A6) PMC1_13 (P2-C7) PMC1_14 (P2-A7) MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 67 PMC1_49 (P2-C25) PMC1_50 (P2-A25) PMC1_51 (P2-C26) PMC1_52 (P2-A26) PMC1_53 (P2-C27) PMC1_54 (P2-A27) PMC1_55 (P2-C28) PMC1_56 (P2-A28) PMC1_57 (P2-C29) PMC1_58 (P2-A29) PMC1_59 (P2-C30) PMC1_60 (P2-A30) PMC1_61 (P2-C31) PMC1_62 (P2-A31) PMC1_63 (P2-C32) PMC1_64 (P2-A32) MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 68: Table 3-9 Pmc Slot 2 Connector (J21) Pin Assignments

    +3.3V (VIO) AD31 AD28 AD27 AD25 C/BE3# AD22 AD21 AD19 +3.3V (VIO) AD17 FRAME# IRDY# DEVSEL# PCIXCAP LOCK# PCI_RSVD (No Connect) PCI_RSVD (No Connect) +3.3V (VIO) AD15 AD12 AD11 AD09 C/BE0# AD06 AD05 MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 69: Table 3-10 Pmc Slot 2 Connector (J22) Pin Assignments

    Not Used Not Used Not Used Pull-up to +3.3V +3.3V RST# Pull-down +3.3V Pull-down Not Used AD30 AD29 AD26 AD24 +3.3V IDSEL1 AD23 +3.3V AD20 AD18 AD16 C/BE2# IDSEL1B TRDY# +3.3V STOP# MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 70: Table 3-11 Pmc Slot 2 Connector (J23) Pin Assignments

    No Connect (MONARCH#) Table 3-11 PMC Slot 2 Connector (J23) Pin Assignments Signal Signal Reserved (No Connect) C/BE7# C/BE6# C/BE5# C/BE4# +3.3V (VIO) PAR64 AD63 AD62 AD61 AD60 AD59 AD58 AD57 +3.3V (VIO) AD56 MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 71 AD47 AD46 AD45 +3.3V (VIO) AD44 AD43 AD42 AD41 AD40 AD39 AD38 AD37 AD36 AD35 AD34 AD33 +3.3V (VIO) AD32 Reserved (No Connect) Reserved (No Connect) Reserved (No Connect) Reserved (No Connect) MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 72: Serial Port Connector (Com1/J1)

    There is one front access asynchronous serial port interface (SP0) that is routed to the micro DB-9 front-panel connector. You can use the Artesyn part MTCA-CONSOLE-CABLE to convert to a DB9 male connector. The pin assignments for this connector are as follows:...
  • Page 73 Reserved (N/C) IRQ6* Reserved (N/C) IRQ5* +3.3V (Not Used) Reserved (N/C) IRQ4* Reserved (N/C) IRQ3* +3.3V (Not Used) Reserved (N/C) IRQ2* Reserved (N/C) IRQ1* +3.3V (Not Used) Reserved (N/C) -12V +5VSTDBY +12V (N/C) MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 74: Vmebus P2 Connector

    The VME P2 connector is a 160-pin DIN. Row B of the P2 connector provides power to the MVME4100ET and to the upper eight VMEbus address lines and additional 16 VMEbus data lines. The Z, A, C, and D pin assignments for the P2 connector are the same for both the...

  • Page 75: Mvme721Et Pmc I/O Module (Pim) Connectors (J10, J14)

    PMC Host I/O connector J10 routes only power and ground from VME P2. There are no Host I/O signals on this connector. The MVME4100ET routes PMC I/O from J14 of PMC Slot 1 to VME P2 rows A and C. The MVME721ET routes these signals (pin-for-pin) from VME P2 to PMC I/O Module connector J14.

  • Page 76: Headers

    No Connect No Connect No Connect +3.3V No Connect No Connect No Connect No Connect No Connect No Connect Headers This section describes the pin assignments of the Headers on the MVME4100ET. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 77: Processor Cop Header (P4)

    The 20-pin boundary scan header provides an interface for programming the on-board PLDs and for boundary scan testing/debug purposes. The pin assignments for this header are as follows: Table 3-17 Boundary Scan Header (P5) Pin Assignments Signal Signal TRST_N (BSCANEN_N) MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 78 Table 3-17 Boundary Scan Header (P5) Pin Assignments (continued) Signal Signal No Connect AUTOWR_N No Connect No Connect No Connect Pin 10 must be grounded in the cable in order to enable boundary scan. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 79: Functional Description

    The MVME4100ET VMEbus board is based on the MPC8548E System on Chip (SoC) processors. The MVME4100ET provides front panel access to one serial port with a mini DB-9 connector and two 10/100/1000 Ethernet ports with two RJ-45 connectors. The front panel includes a fail indicator LED, user-defined indicator LED, and a reset/abort switch.

  • Page 80: Block Diagram

    Functional Description Block Diagram The following figure is a block diagram of the MVME4100ET architecture. Figure 4-1 Block Diagram MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 81: Processor

    1.3 GHz core frequency with a corresponding 533 Mb DDR2 memory bus. The MVME4100ET supports the power-on reset (POR) pin sampling method for processor reset configuration. The states of the various configuration pins on the processor are sampled when reset is de-asserted to determine the desired operating modes.

  • Page 82: System Memory

    For programming information, see the MVME4100ET Single Board Computer Programmer’s Reference. System Memory The MVME4100ET includes one SO-CDIMM socket. The SO-CDIMM socket supports 2 GByte DDR2 SDRAM module. The MVME4100ET supports memory speeds up to DDR533. Timers Timing functions for the MVME4100ET are provided by four global high-resolution timers integrated into the MPC8548E plus four additional independent 32-bit timers in a PLD.

  • Page 83: Local Bus Interface

    I/O registers. The LBC has programmable timing modes to support devices of different access times, as well as device widths of 8, 16, and 32 bits. The MVME4100ET uses the LBC in GPCM mode to interface to two physical banks of on-board flash, an on-board Quad UART (QUART), an MRAM, and on-board 32-bit timers along with control/status registers.

  • Page 84: Nvram

    115 Kbaud. Refer to the ST16C554D data sheet for additional details and/or programming information. 4.8.4 Control and Timers PLD The MVME4100ET Control and Timers PLD resides on the local bus. The Control and Timers PLD provides the following functions on the board: Local bus address latch ...

  • Page 85: Duart Interface

    PMCs installed. 4.10.1 Tsi148 VME Controller The VMEbus interface for the MVME4100ET is provided by the Tsi148 VMEbus controller. The Tsi148 provides the required VME, VME extensions, and 2eSST functions. TI SN74VMEH22501 transceivers are used to buffer the VME signals between the Tsi148 and the VME backplane.

  • Page 86: 4.12.1 Power Sequencing

    4.12.3 Power Supply Filtering and Fusing Each of the switching power supply inputs on the MVME4100ET will have an inductor to reduce switching noise from being fed back onto the +5.0 V input. The LTC3828 supplies will each have a 10 A fuse to protect the supplies from over-current in case of component failure.

  • Page 87: 4.13.1 System Clock

    The Local Bus Controller (LBC) clock output is connected to the PLD but is not used by the internal logic. 4.14 Reset Control Logic There are multiple sources of reset on the MVME4100ET. The following sources generate a board level reset: Power-up ...

  • Page 88: 4.15 Real Time Clock Battery

    +3.3 V and battery voltages. 4.16 Debug Support The MVME4100ET provides a boundary scan header for boundary scan test access and device programming. The MVME4100ET also provides a separate standard COP header for processor COP emulation.

  • Page 89: Transition Module

    Chapter 5 Transition Module Overview This chapter provides information on the features of MVME721ET transition module. It also includes a drawing of the module showing the components and rear panel connectors. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 90: Transition Module Layout

    Transition Module Transition Module Layout The following illustration shows the component layout and connectors on the MVME721ET transition module. Figure 5-1 Component Layout S1 SMT Switch MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 91: Features

    The MVME721ET transition module is for I/O routing through the rear of a compact VMEbus chassis. It connects directly to the VME backplane in chassis’ with an 80 mm deep rear transition area. The MVME721ET is designed for use with the host MVME4100ET board. It has the following features:...

  • Page 92: Seeprom Address Switch, S1

    Figure 5-1 on page Figure 5-3 S1 Switch Positions Table 5-2 SEEPROM Address Switch Assignments (RTM) Position Function A(2) A(1) A(0) Default (OFF) Table 5-3 Switch Settings and Device Addresses A(2:0) Device Address $AA (default) MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 93: Rear Panel Connectors

    VMEbus specifications. Table 5-4 Transition Module Connectors Connector Function J1A, J1B, J1C, J1D COM port connectors 10/100/1000Mb/s Ethernet connector 10/100/1000Mb/s Ethernet connector PIM power/ground PIM I/O VME backplane connector MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 94: Figure 5-4 Rear Panel Connectors And Leds

    PMC I/O (PIM) connector J10 routes only power and ground from VME P2 connector. There are no host I/O signals on this connector. The MVME4100ET routes PMC I/O from J14 of PMC Slot 1 to VME P2 rows A and C. The MVME721ET routes these signals (pin-for-pin) from VME P2 to PMC I/O module connector J14.

  • Page 95: Pmc Input/Output Module

    PIM module on top of the transition module, aligned with the appropriate two PIM connectors. The two connectors on the underside of the PIM module should then connect smoothly with the corresponding connectors on the transition module (J10 and J14). MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 96: Figure 5-5 Installing The Pim

    PIM front bezel and rear standoffs. Tighten the screws. Refer to the following figure for proper screw/board alignment. The example below may not accurately represent your MVME721ET Figure 5-5 Installing the PIM PIM Alignment MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 97: Motload Firmware

    The implementation of MOTLoad and its memory requirements are product specific. The MVME4100ET single-board computer (SBC) is offered with a range of memory (for example, DRAM or flash). Typically, the smallest amount of on-board DRAM that an SBC has is 32 MB.

  • Page 98: Tests

    RAM, which is not considered a true device and can be directly tested without a device path string. Refer to the devShow command description page in the MOTLoad Firmware Package User’s Manual. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 99: Command List

    Block Compare Byte/Halfword/Word bdTempShow Display Current Board Temperature Block Fill Byte/Halfword/Word blkCp Block Copy blkFmt Block Format blkRd Block Read blkShow Block Show Device Configuration Data blkVe Block Verify blkWr Block Write MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 100 ELF Object File Loader errorDisplay Display the Contents of the Test Error Status Table eval Evaluate Expression execProgram Execute Program fatDir FAT File System Directory Listing fatGet FAT File System File Load MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 101 Display state of L2 Cache and L2CR register contents l3CacheShow Display state of L3 Cache and L3CR register contents Memory Display Bytes/Halfwords/Words memShow Display Memory Allocation Memory Modify Bytes/Halfwords/Words mpuFork Execute program from idle processor MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 102 Symbol Table Attach Symbol Table Lookup stop Stop Date and Time (Power-Save Mode) taskActive Display the Contents of the Active Task Table Trace (Single-Step) User Program Trace (Single-Step) User Program to Address MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 103 Serial Internal Loopback testStatus Display the Contents of the Test Status Table testSuite Execute Test Suite testSuiteMake Make (Create) Test Suite testWatchdogTimer Tests the Accuracy of the Watchdog Timer Device tftpGet TFTP Get MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 104: Using The Command Line Interface

    The MOTLoad prompt changes according to what product it is used on (for example, MVME6100, MVME3100, MVME4100ET). Example: MVME4100> If an invalid MOTLoad command is entered at the MOTLoad command line prompt, MOTLoad displays a message that the command was not found. MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 105 Mon Aug 29 15:24:13 MST 2005 MVME4100> If the partial command string cannot be resolved to a single unique command, MOTLoad informs the user that the command was ambiguous. Example: MVME4100> te "te" ambiguous MVME4100> MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 106: Rules

    For help with a specific test or utility the user can enter the following at the MOTLoad prompt: help <command_name> The help command also supports a limited form of pattern matching. Refer to the help command page. Example MVME4100> help testRam MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 107: Firmware Settings

    6.5.1 Default VME Settings As shipped from the factory, the MVME4100ET has the following VME configuration programmed via Global Environment Variables (GEVs) for the Tsi148 VME controller. The firmware allows certain VME settings to be changed in order for the user to customize the environment.
  • Page 108 Inbound Image 0 Ending Address Upper Register = 00000000 Inbound Image 0 Ending Address Lower Register = 1FFF0000 Inbound Image 0 Translation Offset Upper Register = 00000000 Inbound Image 0 Translation Offset Lower Register = 00000000 MVME4100> MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 109 Outbound Image 2 Ending Address Lower Register = B0FF0000 Outbound Image 2 Translation Offset Upper Register = 00000000 Outbound Image 2 Translation Offset Lower Register = 40000000 Outbound Image 2 2eSST Broadcast Select Register = 00000000 MVME4100> MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 110 Outbound Image 7 Starting Address Upper Register = 00000000 Outbound Image 7 Starting Address Lower Register = B1000000 Outbound Image 7 Ending Address Upper Register = 00000000 Outbound Image 7 Ending Address Lower Register = B1FF0000 MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 111: Control Register/Control Status Register Settings

    –s –o(0 - 7) To display Master Control Register state:  vmeCfg –s –r234 To display Miscellaneous Control Register state:  vmeCfg –s –r238 To display CRG Attribute Register state:  vmeCfg –s –r414 MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 112: Editing Vme Settings

     vmeCfg –d –o(0 - 7) Deletes Master Control Register state:  vmeCfg –d –r234 Deletes Control Register state:  vmeCfg –d –r238 Deletes CRG Attribute Register state:  vmeCfg –d –r414 MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 113: Restoring Default Vme Settings

    These transactions occur across the VMEbus in the case of the MVME4100ET. MOTLoad uses one of four mailboxes in the Tsi148 VME controller as the inter-board communication address (IBCA) between the host and the target.

  • Page 114: Boot Images

    The MVME4100ET’s IBCA needs to be mapped appropriately through the master’s VMEbus bridge. For example, to use remote start using mailbox 0 on an MVME4100ET installed in slot 5, the master would need a mapping to support reads and writes of address 0x002ff610 in VME CR/CSR space (0x280000 + 0x7f610).

  • Page 115: Checksum Algorithm

    Unsigned int checksum( Unsigned int *startPtr,/* starting address */ Unsigned int endPtr/* ending address */ unsigned int checksum=0; while (startPtr < endPtr) { checksum += *startPtr; startPtr++; return(checksum); MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 116: Image Flags

    MOTLoad currently uses an Image Flag value of 0x3, which identifies itself as an alternate MOTLoad image that executes from RAM. MOTLoad currently does not support execution from flash. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 117: User Images

    The boot loader performs no other initialization of the board than that specified prior to the transfer of control to either a POST, USER, or Alternate MOTLoad image. Alternate boot images need to initialize the board to whatever state the image may further require for its execution. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 118: Alternate Boot Images And Safe Start

    Some later versions of MOTLoad support alternate boot images and a safe start recovery procedure. If safe start is available on the MVME4100ET, alternate boot images are supported. With alternate boot image support, the boot loader code in the boot block examines the upper 8 MB of the flash bank for alternate boot images.

  • Page 119: Startup Sequence

    MOTLoad RTOS Version 2.0, PAL Version 0.b EA02 MVME4100> Startup Sequence The firmware startup sequence following reset of MOTLoad is to: Initialize cache, MMU, FPU, and other CPU internal items  Initialize the memory controller  MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 120 During interactive mode, the user has the option to display locations at which valid boot images were discovered, specify which discovered image is to be executed, or specify that the recovery image in the boot block of the active flash bank is to be executed. MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 121: Battery Exchange

    Appendix A Battery Exchange Battery Exchange Some blade variants contain an on-board battery. The battery location is shown in the following figure. Figure A-1 Battery Location MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 122 Battery Exchange The battery provides data retention of seven years summing up all periods of actual data use. Artesyn therefore assumes that there usually is no need to exchange the battery except, for example, in case of long-term spare part handling.
  • Page 123 3. Dispose of the old battery according to your country’s legislation and in an environmentally safe way. The RTC field removable battery should be removed, if MVME4100ET has to be stored beyond its operational temperature range. MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 124 Battery Exchange MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 125: Related Documentation

    The publications listed below are referenced in this manual. You can obtain electronic copies of Artesyn Embedded Technologies - Embedded Computing publications by contacting your local Artesyn sales office. For released products, you can also visit our Web site for the latest copies of our product documentation.
  • Page 126 MR2A16A Rev. 5 9/2007 Texas Instruments Data Sheet SCES357E SN74VMEH22501 Revised March 2004 8-bit Universal Bus Transceiver and Two 1-bit Bus Transceivers with Split LVTTL Port, Feedback Path, and 3-state Outputs Exar MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 127 Version 4.0.1 Quad UART with 16-Byte FIFO's June 2006 On Semi ADT7461 Digital Temperature Sensor ADT7461/D Rev 4 January 2009 Tundra Semiconductor Corporation Tsi148 PCI/X-to-VME Bus Bridge User Manual FN 80A3020 MA001_08 MVME4100ET Single Board Computer Installation and Use (6806800K76G)

  • Page 128: Related Specifications

    ANSI/VITA 32-2003 PCI-X on PMC ANSI/VITA 39-2003 PMC I/O Module (PIM) Draft Standard VITA 36 Draft Rev 0.1 July 19, 1999 Universal Serial Bus Universal Serial Bus Specification Revision 2.0 April 27, 2000 MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 129 Institute for Electrical and Electronics Engineers, Inc. IEEE Standard for a Common Mezzanine Card Family: CMC Family IEEE Std 1386 - 2001 IEEE Standard Physical and Environmental Layer for PCI Mezzanine Cards IEEE Std 1386.1 - 2001 (PMC) MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 130 Related Documentation MVME4100ET Single Board Computer Installation and Use (6806800K76G)
  • Page 132 Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other product or service names are the property of their respective owners. © 2016 Artesyn Embedded Technologies, Inc.

Table of Contents
