Artesyn MVME7100ET Quick Start Manual

MVME7100ET

Quick Start Guide

P/N:6806800L33B (June 2014)
1
What's in the box?
Make sure you receive all items of
your shipment:
• MVME7100ET board
• Printed Safety Notes
When installing or servicing the
module or accessories, strictly
observe the safety precautions
in the Safety Notes. Otherwise,
personal injury or property dam-
age may occur.
2
Observe ESD-safe
measures
Use either a properly grounded ESD
wrist strap or make sure that you are
working in an ESD-safe environment.
3
Prepare the installation
site
• Make sure that all environmental
and power requirements defined in
the MVME7100ET Installation and
Use manual are met.
• Remove all items from the box.
4

Install the board

1. Attach an ESD strap to your wrist.
2. Attach the other end of the ESD
strap to an electrical ground. The
ESD strap must be secured to your
wrist and to ground throughout the
procedure.
3. Remove any filler panel that might
fill that slot.
4. Install the top and bottom edge of
the MVME7100ET into the guides of
the chassis.
5. Ensure that the levers of the two
injector/ejectors are in the outward
position.
6. Slide the MVME7100ET into the
chassis until you feel resistance.
7. Simultaneously move the injector/
ejector levers in an inward direction.
8. Verify that the MVME7100ET is
properly seated.
9. Secure the board to the chassis using
the two screws located adjacent to
the injector/ejector levers.
10.Connect the appropriate cables to
the MVME7100ET.
