Solid State Logic Live Installation Manual page 36

SSL Live Installation Information
GPIO Connector Pinout
Pin
1
2
3
4
5
6
Pin
1
2
3
4
5
6
www.solidstatelogic.com
GP Input - D-type Male
Description
Input 1A
14 Input 1B
Input 2A
15
Input 2B
Input 3A
16 Input 3B
Input 4A
17 Input 4B
Input 5A
18
Input 5B
Input 6A
19 Input 6B
GP Output - D-type Female
Description
Output 1A
14
Output 1B
Output 2A
15 Output 2B
Output 3A
16 Output 3B
Output 4A
17
Output 4B
Output 5A
18 Output 5B
Output 6A
19 Output 6B
Description
Pin
7 Input 7A
20 Input 7B
8
Input 8A
21
Input 8B
9
Input 9A
22 Input 9B
10 Input 10A
23 Input 10B
11 Input 11A
24
Input 11B
12
Input 12A
25 Input 12B
13
Description
Pin
7
Output 7A
20
Output 7B
8
Output 8A
21 Output 8B
9 Output 9A
22 Output 9B
10 Output 10A
23
Output 10B
11
Output 11A
24 Output 11B
12 Output 12A
25 Output 12B
13 +12V (450mA max)
0V
