SSL Live Installation Information

D 32.32 AES Digital 2U Stagebox

Primary MADI Coaxial
Connections Key
D 32.32 Weight & Dimensions
Height 2U - 89 mm (3.5 inches)
Depth 305 mm (12 inches)
Width 483 mm (19 inches)
Weight
Power
Ratings
100–240 V AC, 50/60 Hz, 0.6-0.4 A
www.solidstatelogic.com
32 AES Digital Inputs/Outputs
(16 AES Pairs)
Arranged as In/Out Pairs
*5
Local Setup
Redundant MADI
Connectors Coaxial Connectors
*2
6.2 kg
<60 W
MIDI
Controls
*15b
*20
Additional
MADI outputs
*2 *2
GPIO
Maintenance USB
In & Out
Port
*19a
*24
Local Mains Power
Wordclock Inlet
*13 *1
