12. APPENDIX E: AUDIO CONNECTORS

The audio inputs/outputs of PYKO-out come on a terminal block connector with two lines of three pins
each (= two counterparts).
[]

Pinout
Pin
Signal
1
GND
2
OUT 1-
3
OUT 1+
4
GND
5
OUT 2-
6
OUT 2+
PYKO-out: Professional IP audio endpoint
