PYKO-out: Professional IP audio endpoint
7. SPECIFICATIONS
Configuration
Size 140 mm x 41 mm x 145 mm (1/3 1U rack)
Power supply 24 VDC, +/- 20%
WARNING ​ Do not open the power supply module. It contains hazardous
voltages. There are no user-serviceable parts inside.
Temp / humidity
(non-condensing)
Operating: 0 °C – 45 °C / 0% - 70%
Storage: -5 °C – 70 °C / 0% - 95%
Power requirements at
0.4 A
24 V
Net weight 0,477 kg (∼1.05 lb)
Outputs
Analog audio (mono) 2 outputs
Impedance 50 Ω
Connectivity
Audio 2x3 pins on terminal block
Ethernet port RJ45 10/100-bit.
GPIO 4 GPIs compatible TTL
4 relay GPOs
on 2x8 pins on terminal block
Serial port 1 RS232 on DB9
USB USB 1.1 interface for memory stick (FAT16)
1 port on front panel, 1 internal port (exclusive!)
Audio specifications
Sampling frequencies
Programmable from 8 to 48 kHz
available
A/D and D/A converter
24 bits
resolution
Supported audio formats PCM (16 bits)
