Chapter 5 – System
System
This section includes system information, system logs, system tools (i.e. firmware updates), scheduling, and
external syslog server setup.
Change Password
1.
Old, New, and Confirmation Password: To change your password, type in your old password, then enter
in the new password in the new password and confirm password fields. Click Save to store your settings
or Undo to cancel the changes.
2.
Administrator Time-out: Other options allow you to set when there are no activities on the web user
interface.
3.
Telnet with CLI: Check to Enable CLI access via LAN or WAN.
4.
Connection Type: Check to Enable Telnet or SSH access via LAN or WAN. The Telnet and SSH access IP
port number can be configured to use custom port.
5.
Options: Setup local or remote HTTP or HTTPS web UI access. Enter unique remote IP address and subnet
mask to restrict remote web UI access. Enable web UI access for LAN and/or WAN interfaces. Port
settings apply to WAN web UI access only.
System Information
This section displays System Information for the WAN interface, current date and time, device serial number and
MAC address.
System Status
System Status displays and captures log information. It also allows log files to be sent to an external syslog server.
1.
Web Log: Check Enable for System, Attacks, Drop, and Debug categories, then click Save. Click View to
display or download log files.
2.
Syslog: Check to Enable logging to an external syslog server. The external syslog server's IP address can
be configured using the External Servers option.
System Tools
Options to setup system time, perform firmware updates, ping test, trace route test, reboot or schedule a reboot,
reset to factory defaults, wake up on LAN, and backup configuration settings.
System Time: Configure the time zone. You can select sync current time and date with external time server
or local PC time.
Firmware Upgrade: Perform firmware upgrade.
Note:
To check the current firmware version, refer to the top of the page after login.
Ping Test (NAT mode only): Enter external host IP address and perform ping test.
Tracert Test (NAT mode only): Enter external host IP address and perform trace route test.
Reboot: Select reboot now or set a schedule for an auto-reboot to occur.
Reset to Default: Resets all settings back to factory defaults.
®
MultiConnect
CBRS Wi-Fi AP MTCAPW-L12G2 Admin Guide
SYSTEM
25
