SETTING UP AND ONBOARDING DEVICES
STUN Settings
Server Address
Server Port
Keep Alive Period
Save
Undo
DeviceHQ Onboarding
Initial factory out of the box setup and using DeviceHQ onboarding process
DeviceHQ account setup
1.
End user login, sign up and register to DeviceHQ with new account
2.
End user need to generate a new Device / Machine API key pair
3.
End user need to create a MTCAPW configuration file with the machine API key pair in step 2
4.
End user upload MTCAPW zipped configuration file created in step 3 to DeviceHQ
MTCAPW device setup require only power on and check LED status
5.
Install CBRS SIM card
6.
Attach two LTE antennas
7.
Power on the device
8.
Wait for two minutes and check all the LEDs on the device to indicate active wifi and internet connection
9.
MTCAPW will automatically register to DeviceHQ after active internet connection
End user claiming the MTCAPW on DeviceHQ
10.
Login to DeviceHQ
11.
Go to URL
12.
Enter the serial number of the MTAPW that just checked in above
13.
Assign device configuration file in step 4 to the device serial number selected
14.
Power off/on the device and wait for a few minutes so device will auto check in, get the new
configuration file, apply the new configuration file and auto reboot. If everything is successful, the device
will now show up in the end customer DeviceHQ account
Local Bulk Onboarding
Intial factory out of the box setup and local onboarding precess: Windows 10 PC setup and third parties SW need
to be installed.
Install Windows terminal SW:
Install Windows web server SW:
16
String format: any IPv4
address
It is an optional Item
An optional setting
3478 is set by default
An optional setting
0 is set by default
N/A
N/A
https://www.devicehq.com/devices/claiming#/
https://ttssh2.osdn.jp/index.html.en
http://nginx.org/en/docs/windows.html
MultiConnect
Specify the IP address for the expected
STUN Server
Specify the port number for expected STUN
Server. Value Range: 1-65535
Specify the keep alive time period for the
connection with STUN Server. Value Range :
0-65535
Click Save to save the settings
Click Undo to cancel the modification
®
CBRS Wi-Fi AP MTCAPW-L12G2 Admin Guide
