Feature
Storage One Changeable Optical Device (DVD-ROM/ Combo/ CD-RW/ DVD+RW/ DVD-RW /DVD-Dual Drive)
One Changeable Primary 2.5" 9.5mm (h) Hard Disk Drive
One External USB 1.44Mb Floppy Disk Drive (Optional)
One Changeable 2nd 2.5" 9.5mm (h) RAID (Optional)
Supports Master Mode IDE, Supporting PIO Mode 5 / ATA-33/66/100/133 (Ultra DMA)
One Fixed 7-In-1 Card Reader Module (Factory Option)
One Changeable TV Tuner (Optional)
Data Backup RAID 0, RAID 1, HDD Fault Tolerance System (Optional)
Audio AC'97 2.2 Compliant Device
3D Stereo Enhanced Sound System
Virtual 6-Channel Audio Output
Compatible Sound Blaster PRO™
Keyboard, Pointing Full Size Winkey Keyboard with Numeric Keypad
Device & Buttons Built-In TouchPad
3 Hot Keys (Default Internet Browser/ Default Email Program & Application)
Interface & Three USB 2.0 Ports
Communication One Mini IEEE1394 Ports
One S-Video Jack for TV Output
One Serial Port
One Parallel Port (LPT1) Supporting ECP/EPP
One Infrared Transceiver (IrDA 1.1/FIR/SIR/ASKIR)
Infrared Transfer 1cm ~ 1M Operating
Distance
115.2K bps SIR
4M bps FIR
One DVI-Out Port
One PS/2 Port (Mouse/Keyboard)
One Headphone Jack
One Microphone Jack
PCMCIA One Type II PCMCIA 3.3V/5V Socket Supporting CardBus
Indicators LED Indicators (HDD Activity, Suspend/Power On/AC-In, Battery Charging/Battery Full, Num Lock, Caps Lock,
Scroll Lock)
All manuals and user guides at all-guides.com
Specification
S/PDIF Digital Output (5.1 CH)
Built-In Microphone
Built-In 4 Speakers
Built-in Sub Woofer (Factory Option)
One S/PDIF Out Port
One RJ-11 Jack (Modem)
One RJ-45 Jack (Local Area Network)
1000BASE-T (Gigabit) LAN On Board
10/100 BASE-T Compatible
Integrated V.90/l56K MDC Modem (V.92 Compliant)
One DC-In Jack
802.11g Wireless LAN (Optional)
300K Pixel Video Camera Module (Optional)
Bluetooth Module (Optional)
One S-Video Jack for Video Input (Optional with TV
Tuner Module)
One Line-In Jack for Audio Input (Optional with TV
Tuner Module)
Introduction
System Specifications 1 - 3
