Black Electric Single Motor Desk Frame
Instruction Manual
SKU: DESK-V100EB
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-v100eb
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DESK-V100EB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivo DESK-V100EB

Summary of Contents for Vivo DESK-V100EB

  • Page 1 Black Electric Single Motor Desk Frame Instruction Manual SKU: DESK-V100EB Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v100eb GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
  • Page 3 ASSEMBLY STEPS STEP 1 Loosen screws on Crossbar (A) using 5mm Allen Wrench (T-A), extend, and then re-tighten screws. Mount Crossbar (A) to Leg (B) and Motorized Leg (C) using M8x50 Screws (S-A) and 5mm Allen Wrench (T-A). STEP 2 Place Feet (D) on Leg (B) and Motorized Leg (C).
  • Page 4 STEP 3 Assemble Side Brackets (E) to Leg (B) and Motorized Leg (C) using M8x12 Screws (S-B) and 5mm Allen Wrench (T-A). STEP 4 Place frame assembly upside down on the desktop. Slide Tray (F) under Crossbar (A). Loosen the screws on Crossbar (A) using 5mm Allen Wrench (T-A).
  • Page 5 STEP 5 Secure frame assembly to the desktop with ST4.2x16 Screws (S-D) and a Phillips screwdriver. STEP 6 Loosen the knobs on Sync Rod (G). Insert the hex shaft into Leg (B) until it reaches the notch. While holding the hex shaft, extend Sync Rod (G) onto the hex shaft of Motorized Leg (C) until it reaches the retainer.
  • Page 6 STEP 7 Mount Controller (H) to the desktop using ST4.2x16 Screws (S-D) and a Phillips screwdriver. Connect Power Cable (J) to AC Adapter (I). Connect cables from Motorized Leg (C) and AC Adapter (I) to Controller (H). STEP 8 Manage cables using Cable Management Clips (S-E). Insert Hooks (K) into Side Brackets (E).
  • Page 7 CONTROLLER Plug Power Cable (J) into an AC outlet. Follow the reset process to initialize the desk. The desk is now ready for use. TROUBLESHOOTING DESCRIPTION RESOLUTION No response while pressing button Check to make sure all cables are fully connected.
  • Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
