Black Electric Dual Motor Desk Frame
Instruction Manual
SKU: DESK-V103E
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-v103e
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DESK-V103E and is the answer not in the manual?

Questions and answers

Related Manuals for Vivo DESK-V103E

Summary of Contents for Vivo DESK-V103E

  • Page 1 Black Electric Dual Motor Desk Frame Instruction Manual SKU: DESK-V103E Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v103e GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...

  • Page 2: Electrical Safety Instructions

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.

  • Page 3: Tools Needed

    TOOLS NEEDED Phillips Screwdriver DO NOT EXCEED WEIGHT CAPACITY. 275lbs Failure to do so may result in serious injury. (124.74kg) Level Drill ASSEMBLY STEPS STEP 1 Place the side brackets (B) upside down on a flat surface, then place telescopic crossbar (A) over the brackets as shown, making sure the screw posts on the brackets fit into the holes in the crossbar (A).
  • Page 4 STEP 4 Tighten all screws with the Allen wrench (S-I) to secure length. STEP 5 Drill 3/8" (10mm) deep pilot holes under the desktop with a 3/32" (or 3mm) drill bit, then remove the crossbar with brackets. STEP 6 Attach the legs (E) to the assembled frame using M6x10 bolts (S-A).
  • Page 5 STEP 8 Attach the fixing plate (F) to the crossbar using M4x6 flat head bolts (S-E) with a Phillips screwdriver. STEP 9 Connect motor cables, control panel (J) and power cable (I) to the control unit (G). STEP 10 Slide the control unit onto the fixing plate as shown.
  • Page 6 STEP 11 Fix the hooks (H) to the shelf (D) with M4x6 bolts and tighten with a Phillips screwdriver. Hang the shelf onto the frame as shown. STEP 12 Tighten installed thumbscrews to secure. STEP 13 Press anti-vibration pads (S-H) into desktop mounting holes. STEP 14 Attach the desktop with 7/8"...
  • Page 7 STEP 15 Place the control panel (J) at the desired location and mark drilling locations with a pencil. Drill 5/8" (16mm) deep pilot holes under the desktop with a 5/64" (or 2mm) drill bit. Attach the control panel to the desktop with 3/4" screws (S-D) using a Phillips screwdriver. Add cable clips (S-G) to organize.
  • Page 8 - 92% within < 3hr www.vivo-us.com AVG. RESOLUTION TIME : < 15 M (within office hrs) Chat live with an agent! AVG. RESOLUTION TIME : 5M 4S 309-278-5303 (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
