Page 1 Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals Release: 7.0 Document Revision: 04.01 www.nortel.com NN43001-557...
Page 2 While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are subject to change without notice.
Page 3: Table Of Contents
How to get help Getting Help from the Nortel Web site 7 Getting Help over the phone from a Nortel Solutions Center 7 Getting help from a specialist by using an Express Routing Code 8 Getting Help through a Nortel distributor or reseller 8...
Page 4 Man-Machine Interface (MMI) commands Regulatory approvals Regulatory notices 119 Pin-outs LMI Multi I/O cable assembly 123 T1 CSU Cable Kit adapters 127 Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 5: New In This Release
New in this release The following sections detail what is new for Nortel Communication Server 1000 Release 7.0. Navigation • “Features” (page 5) • “Other” (page 5) Features There have been no updates to the feature descriptions in this document.
Page 6 6 New in this release June 2007 Standard 01.02. This document is up-issued to remove the Nortel Network confidential statement. May 2007 Standard 01.01. This document is issued to support Communication Server 1000 Release 5.0. This document contains information previously contained in the following legacy document, now retired: Mini-Carrier Remote: Service Implementation Guide (553-3001-357).
Page 7: How To Get Help
Getting Help over the phone from a Nortel Solutions Center If you do not find the information you require on the Nortel Technical Support web site, and you have a Nortel support contract, you can also get help over the telephone from a Nortel Solutions Center.
Page 8: Getting Help From A Specialist By Using An Express Routing Code
To access some Nortel Technical Solutions Centers, you can use an Express Routing Code (ERC) to quickly route your call to a specialist in your Nortel product or service. To locate the ERC for your product or service, go to: www.nortel.com/erc...
Page 9: Introduction
Note on legacy products and releases This NTP contains information about systems, components, and features that are compatible with Nortel Communication Server 1000 software. For more information on legacy products and releases, click the Technical Documentation link under Support & Training on the Nortel home page: www.nortel.com...
Page 10: Intended Audience
In this document, the following systems are referred to generically as system: • Communication Server 1000E (CS 1000E) • Communication Server 1000M (CS 1000M) • Meridian 1 Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 11: Related Information
Communication Server 1000M and Meridian 1 Large System Maintenance (NN43021-700) Online To access Nortel documentation online, click the Technical Documentation link under Support & Training on the Nortel Web site: www.nortel.com CD-ROM To obtain Nortel documentation on CD-ROM, contact your Nortel customer representative.
Page 13: Description
MCR will provide essential functionality to as many as 16 digital telephones at the remote site, until full service is restored. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 14 • fractional T1 use, • increased availability of superloop network card slots (MCR uses no additional network cards). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 15: Product Description
Interface card (RMI), connected via one or two T1 carrier links to the LMI at the local site, controls up to eight standard IPE line cards. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 16 Multi-I/O Cable Assembly (NT5D87)" (page 23)). The RMI plugs into the core processor slot in the cabinet and communicates with the LMI in order Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 17: Physical Architecture
(NT5D64/NT5D68) faceplate" (page 18), Figure 3 "LMX (NT5D65/NT5D69) faceplate" (page 19), and Figure 4 "RMI (NT5D67) faceplate" (page 20), respectively. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 18 Figure 2 LMI (NT5D64/NT5D68) faceplate The LMI has four LED indicators — Carrier 0 Alarm, Carrier 1 Alarm, Maintenance, and Status. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 19 Physical architecture 19 Figure 3 LMX (NT5D65/NT5D69) faceplate The LMX has two LEDs — Maintenance and Status. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 20 LMI and the MMI, SDI, Alarm, and the T1 carrier links. See “LMI Multi I/O cable assembly” (page 123) for pin-out information. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 21: Lmi/Lmx Multi-I/O Cable Assembly
LMI and up to three LMXs. This cable carries the DS-30X and MMI interfaces. See “LMI/LMX Multi-I/O cable assembly” (page 124) for pin-out information. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 22: Rmi Multi-I/O Cable Assembly
RMI and the MMI, Alarm, and the T1 carrier links. See “RMI Multi-I/O cable assembly” (page 125) for pin-out information. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 23: Functionality
ESF mode, and bipolar violations are counted in D4 mode to determine system health. B8ZS must always be used for MCR. Signaling must be clear-channel end-to-end. Robbed-bit signaling is not supported. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 24 Carrier Remote Interface product. The Mini-Carrier Remote system uses the same type of extensive carrier diagnostics that have proven useful on the Carrier Remote IPE product, Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 25 LMI and RMI. DIP switch settings on the LMI and RMI determine the binary daisy chain address, T1 line build-out, framing mode, terminal baud, and terminal settings. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 26 LEDs flashing three times. The board will not go into service until the entire self-test passes. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 27 This may be repeated until a timeslot is available or the caller hangs up. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 28 Should the existing Nortelline cards be updated such that they operate on an expanded cardLAN message set, the MCR system must also be updated. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 29 2 is reached on all carriers. The following models of the Meridian Digital Telephone support ESAM: Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 30 (see, “Do-not-ring mode” (page 32)), — as a default setting, incoming trunk calls ring to all telephones; Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 32: Physical Description
The T1 interface is capable of driving 655 feet without a repeater. A CSU is required for connection to the Public Switched Telephone Network (PSTN). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 33 The cardLAN interface circuitry responds to both card slot addresses, acting to the switch as two Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 34: Engineering Guidelines
NT8D37EC or NT8D37EC or NT8D37EC NT8D37BA or IPE Module (AC NT5D64 NT5D65 0-6 and 8-14 NT8D37EC or DC powered) Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 35 LMX If required by the customer, the following optional cables may be connected to the LMI Multi-I/O cable assembly (NT5D85): Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 36 Serial Data Interface (SDI) If required by the customer, the following optional cables can be connected to the RMI Multi-I/O cable assembly (NT5D87): Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 37 Description Card Slots Slot Quantity NT8D02 Digital Line Card 1-10 NT8D03 Analog Line Card 1-10 NT8D09 Analog Line Card 1-10 Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 38 The CSU must be configured for no-robbed-bit signaling. If a portion of the twenty-four channels of the first T1 carrier link are used, the Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 39 ESAM, starting with firmware load 12.01: Table 7 Digital Telephone Mode Support as of Release 12.01 Phone Type Normal Mode ESAM M2006 M2008 M2008HF Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 40: Mechanical Overview
8 "Cabling for a single Local Mini-carrier Interface card (LMI)" (page shows LMI cabling connections required at the local site. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 41 32 LMIs are put in a daisy chain at the local site. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 42 Remote-site cabling Figure 10 "Remote Mini-carrier Interface cabling" (page 43) shows the RMI cabling connections required at the remote site. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 43: Power Requirement
Normal: 0ûC to +65ûC 0 Short Term: 0ûC to +70ûC Operating relative humidity: Normal: 10% to 95% (non-condensing) Short Term: 5% to 95% (non-condensing) Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 44 IEC 68-2-29, Test Eb under the following conditions: Constant acceleration of 1.2 g Duration of 30 minutes per surface Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 45 Bellcore NEBS(TR-EOP 000063) for Zone 4, upper floor. Electromagnetic compatibility The LMI, RMI, and LMX circuit packs do not interfere with operation of other licensed communication systems. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 46: Safety Requirements
Canadian Standards Association (CSA): The MCR circuit packs comply with and are certified under CSA C22.2, No. 225 and No. 950-95. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 47: Installation And Configuration
Meridian 1 Small System Installation and Commissioning (NN43011-310). These documents describe how to install, verify, and maintain CS 1000 and Meridian 1 systems. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 48: Quick Reference To System Installation
• Take inventory of the MCR equipment by comparing the received equipment against the shipping documents. Refer to Table 8 Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 49 Remote site • Take inventory of MCR equipment by comparing the received equipment against the shipping documents. Refer to Table 8 Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 50: System Installation
Communication Server 1000M and Meridian 1 Large System Installation and Commissioning (NN43021-310) and Communication Server 1000M and Meridian 1 Small System Installation and Commissioning (NN43011-310). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 51 Up to three LMXs may be installed, depending on configuration. LMX (IPE) NT5D65 Remote Mini-carrier Interface card (RMI) for installation in remote site cabinets. NT5D67 Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 52 2. Second T1 carrier link External alarm 4. Man-Machine Interface (MMI) 5. (not used) (See Figure 7 "RMI Multi-I/O Cable Assembly (NT5D87)" (page 23).) Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 53 1 adapter (CPE to network, female DB15 to RJ48, NT7R93BA) 1 adapter (CPE to CPE, female DB15 to RJ48, NT7R93CA) 1 label (2 in. X 1.473 in., white, self-laminating) Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 54 Terminate the twisted-pair wires with an 8-pin modular plug. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 55 MCR circuit packs." (page 55) for the proper settings for these jumpers. Figure 11 Jumper settings on MCR circuit packs. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 56 DIP Switch 2 (SW2), positions 7 and 8, ON. In cases in which there are three LMIs in the daisy chain, LMI 1 and LMI 3 are end cards, each of Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 57 8 data bits, and 1 stop bit (N, 8, 1). Note: Both T1s are set to the same cable distance and framing mode. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 58 LMI in a daisy chain configuration. Table 13 LMI maintenance daisy chain addresses SW2 at U23 positions 1-5 (1 = ON, 0 = OFF) Address Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 59 If your CSU terminates to a DB15 connector, connect the NT7R93AA adapter to the CSU and connect the span cable to the adapter. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 60 Table 14 "LMX DIP SW2 function: LMX address" (page 61)). Switch 3 (SW3) is reserved and all positions should be OFF. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 61 LMX 3. (See Figure 8 "Cabling for a single Local Mini-carrier Interface card (LMI)" (page 41).) --End-- Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 62 For a DC system, connect the NTAK05 DC power converter cord to the DC power source over the NTAK28AA Junction Box and the NTAK0410 power cable. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 63 Push the locking device levers toward the faceplate to insert the card connector into the backplane connector and lock the card in place. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 64 Interface terminal), to avoid a constant alarm condition. The alarm relay contacts will remain active during such an alarm condition. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 65 534 – 655 feet 400 – 533 feet 267 – 399 feet 134 – 266 feet 0 – 133 feet Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 66 AC/DC power supply. It can also be powered with a DC power system using the NTAK05 DC power supply from a –52 V battery source through Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 67: System Configuration
• enable or disable alarms, • clear errors and logs, • set performance parameters, and • specify tests. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 68 For example, LD 45 can be activated to perform loopback testing. To exit this mode, enter @@@. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 69: Host Mmi Interface
Clear Alarm Log — Clears near-end alarm log. C A L D Clear Alarm Log Distant — Clears distant-end alarm log. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 70 Emergency Stand-Alone Mode automatically when two channels go into alarm. Emergency Stand-alone Mode, Force — Causes the specified card to operate in the Emergency Stand-Alone Mode at all times. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 71 Set Span — Allows user to set the number of timeslots used by the T1. Set Time — Allows user to set or verify the time currently maintained by near-end mini-carrier interface cards. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 72 After three unsuccessful password attempts, the user will be logged out. MMI logout To log out of the MMI, type Q. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 73 The help screen can be made to appear by entering ?, HE, or HELP. Entering any of these commands causes a screen similar to the following to appear: Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 74 Its display is similar to Figure 14 "ALARM DISABLE (A D) screen" (page 74). Figure 14 ALARM DISABLE (A D) screen Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 75 This command resets MCR’s near-end error counter to zero. Its display is similar to Figure 17 "CLEAR ERROR (C E) screen" (page 76). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 76 You can check this by noting the firmware version in the Display Configuration command response. The card’s running firmware version will read "A Pre-12.00 Version". Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 77 T1 timeslots. Its display is similar to Figure 20 "DISPLAY BLOCK (D B) screen" (page 77). Figure 20 DISPLAY BLOCK (D B) screen Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 78 You can check this by noting the firmware version in the Display Configuration command response. The card’s running firmware version will read "A Pre-12.00 Version". Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 79 24-hour period. Its display is similar to Figure 22 "DISPLAY HISTORY (D H) screen" (page 79). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 80 Its display is similar to Figure 24 "DISPLAY PERFORMANCE (D P) screen" (page 80). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 81 Figure 27 "ESAM (E) screen" (page 82). The commands are described in alphabetic order. Note: The ESAM SAVE command is reserved for future use. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 82 The ESAM Never command instructs MCR not to operate in the Emergency Stand-Alone Mode. Its display is similar to Figure 30 "ESAM Never (E N) screen" (page 83). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 83 This command should be used before the PROVISION DOWNLOAD command. The display is similar to Figure 32 "PROVISION REFRESH (P R) screen" (page 84). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 84 FMM to upload the provisioning file from the terminal. The display is similar to Figure 33 "PROVISION UPLOAD (P U) screen" (page 85). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 85 SET [TIME | DATE | ALARM | CONFIG | NAME | ESAM | SPAN] The SET command configures various properties of the MCR system. The commands are described in alphabetic order. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 86 This command configures the date kept at the near end of the system. Its display is similar to Figure 37 "SET DATE (S D) screen" (page 87). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 87 Its display is similar to Figure 39 "SET ESAM:SYSTEM PARAMETERS screen" (page 88). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 88 Its display is similar to Figure 41 "SET ESAM:SET SLOT PARAMETERS screen" (page 89). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 89 Figure 43 "SET ESAM: PHONE PARAMETERS: XUT PARAMETERS screen" (page 89). Figure 43 SET ESAM: PHONE PARAMETERS: XUT PARAMETERS screen Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 90 10PPS2 Make/Break Ratio from its default of 0. Its display is similar to Figure 46 "SET ESAM: PHONE PARAMETERS: XUT PARAMETERS: 10PPS2 MAKE/BREAK RATIO screen" (page 91). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 91 "Unknown." Its display is similar to Figure 49 "SET ESAM: TRUNK PARAMETERS: TRUNK TYPE screen" (page 92). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 92 600 ohms. Its display is similar to Figure 51 "SET ESAM: TRUNK PARAMETERS: TERMINATION IMPEDANCE screen:" (page 93). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 93 Its display is similar to Figure 53 "SET ESAM: QUIT (NO SAVE) screen" (page 94). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 94 This command sets the name of the near-end and remote sites. Its display is similar to Figure 55 "SET NAME (S N) screen" (page 94). Figure 55 SET NAME (S N) screen Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 95 Figure 57 "SET TIME (S T) screen" (page 95). Figure 57 SET TIME (S T) screen Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 96 To insure that all mini-carrier links are connected to their corresponding I/O cable connectors at the remote site, you must identify, test, and tag each mini-carrier link individually as follows: Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 97 If the LED for carrier 0 stays ON due to a carrier alarm condition on the RMI (near-end), the D S command will Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 98 Threshold Duration — Mini-Carrier signal monitoring duration (1 second to 3600 seconds) to detect bit error rate (CRC and BIPV) Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 99 (U23) and SW3 (U51), positions 1 through 8, on the LMI if displaying the local site, or SW2 and SW3, positions 1 through 8 on the RMI if displaying the remote site. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 101: Maintenance
LMI for any reason, all values set with the SET SPAN command, and all commands on the Span setup menu, must be reconfigured Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 102: Maintenance Overview
Communication Server 1000M and Meridian 1 Large System Maintenance (NN43021-700) and Communication Server 1000M and Meridian 1 Small System Maintenance (NN43011-700). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 103 Reconfigure the ESAM data (see xxx for procedure). Return the card to service using LD 32 (see xxx for procedure). --End-- Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 104: Mmi Diagnostic Tools
Far-end alarms are communicated across the link if the MicroLink is up; that is, the carrier is good end-to-end in both directions. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 105: Fault Isolation/Correction Using Mmi Maintenance Commands
Figure 60 "DISPLAY STATUS DISTANT screen" (page 106). These commands are also discussed on “DISPLAY STATUS DISTANT (D S D)” (page 81). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 106 To clear the alarm log, use the CLEAR ALARM LOG (C A L) and CLEAR ALARM LOG DISTANT (C A L D) commands. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 107 (C E) or CLEAR ERROR DISTANT (C E D) command, as appropriate. Clearing these errors does not affect the errored second counters. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 108: Monitoring For Errors
This information is accumulated for an hour, at which time the counters are reset to 0. Results are maintained for each of the previous 24 hours. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 109 TEST (T) command. The screen displayed by the TEST (T) command is similar to Figure 63 "TEST screen" (page 110). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 110 By using the off-line tests in tandem, you will be able to isolate a Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 111 The following figure demonstrates how the signaling is looped back. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 112 You can perform the Off-line Distant-end Loopback test on the distant-end MCR. A failure is detected if the MCR Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 113 MCR toward the carrier. No test data is generated or received at either end of the link. You can perform the Off-line Loopback Toward Network Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 114 T1 link. This test can be used to isolate network problems. Figure 68 Off-line Loopback Toward Network test Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 115: Man-Machine Interface (Mmi) Commands
Display History — Displays near-end performance counters for a specified carrier for the last 24 hours. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 116 Flash module to the far-end card’s Flash module. Provision Erase — Erases and tests the provisioning section of the Flash memory. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 117 Test Verbose — Instructs system to display error reports while tests of specified carrier link at the near end are in progress. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 118 118 Man-Machine Interface (MMI) commands Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 119: Regulatory Approvals
You must, upon request, provide the following information to your local telephone company: Facility Interface Code: 04DU9-DN Service Order Code: 6.0P USOC Jack Type:RJ48C Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 120 • This equipment returns answer supervision on all DID calls forwarded back to the PSTN. Permissible exceptions are: Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 121 This precaution may be particularly important in rural areas. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 122 Ringer Equivalence Number of all the devices may not exceed 5. Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 123: Pin-Outs
GND (SHD) P2 – 4 GND (SHD) P1 – 23 P3 – 3 T1P1RXT P1 – 48 P3 – 11 T1P1RXR Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 124 Table 28 "LMI/LMX Multi-I/O cable assembly (NT5D86) pin-out" (page 125) is the pin-out table for the LMI/LMX Multi-I/O cable assembly (NT5D86). Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 125 RMI Multi-I/O cable assembly (NT5D87) to its correct connection: Table 29 RMI Multi-I/O cable assembly (NT5D87) connections CONN CONNECTS TO Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 126 P1 – 39 P5 – 9 MMIARB1 P1 – 41 P5 – 8 MMIARB2 P1 – 9 P6 – 3 SDIRXD Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 127: T1 Csu Cable Kit Adapters
ORANGE P1 – 2 RING IN P2 – 11 RING IN BLACK P1 – 3 GROUND P2 – 2 GROUND Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
Page 128 P2 – 4 BROWN P1 – 7 SIG1 P2 – 15 SIG1 GRAY P1 – 8 SIG2 P2 – 8 SIG2 Nortel Communication Server 1000 Mini-Carrier Remote Fundamentals NN43001-557 04.01 4 June 2010 Copyright © 2003-2010 Nortel Networks. All Rights Reserved.
