BU Series
CMOS Camera
Instruction Manual
Model
B/W Camera
: BU302MG / BU505MG
Color Camera
: BU302MCG / BU302MCF / BU505MCG / BU505MCF
Thank you for purchasing our product.
Before using this CMOS camera, please read through this instruction manual
carefully in order to use this product correctly and safely.
After reading, keep this instruction manual handy so that you can refer to,
whenever you need it.
Information contained in this document is subject to change without prior notice.
Copyright © 2016 TOSHIBA TELI CORPORATION, All rights reserved.
D4253386C
http://www.toshiba-teli.co.jp/en/
