Toshiba BG Series Instructions Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

CCD Camera

BG Series

B/W Model

BG030 / BG031 / BG080 / BG130 / BG202

Color Model

BG030C / BG130C / BG202C

BG030CF / BG130CF / BG202CF

Specifications

Ver8.0

Information contained in this document is subject to change without prior notice.

D4211883H

Table of Contents

Need help?

Do you have a question about the BG Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Toshiba BG Series

Page 1 BG030 / BG031 / BG080 / BG130 / BG202 Color Model BG030C / BG130C / BG202C BG030CF / BG130CF / BG202CF Specifications Ver8.0 Information contained in this document is subject to change without prior notice. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 2: Table Of Contents
Configuration ..........................7 Optional part ........................... 7 Functions ............................8 Specifications ..........................15 Timing chart ..........................29 Warranty rules ..........................33 Repair ............................. 34 Outline Drawing ..........................35 D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 3: Restriction For Use
(*2): Equipment relating to maintenance of public services/functions involving factors of safety refers - Traffic control systems for air transportation, railways, roads, or marine transportation - Equipment for nuclear power generation - Equipment related to the above D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 4: Cases For Indemnity (Limited Warranty)
 About the item which does not have a publication in the specifications and manual of this product, it considers as the outside for a guarantee.  The attachment mistake of a cable. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 5: Usage Precautions
If intense light falls on the screen, vertical stripes may appear on the screen, but this is not a malfunction.  Do not expose the camera's image-pickup-plane to sunlight or other intense light directly Its inner CCD (charge-coupled device) might be damaged. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 7: Overview
Overview This BG series is an integrated-(one-body)-type camera that adopts all pixel data readout inter line CCD. There are 5 models according to the sensor type. These are BG030 (VGA 1/3 type), BG031 (VGA 1/2 type), BG080 (XGA 1/3 type), BG130 (SXGA 1/3 type), BG202 (UXGA 1/1.8 type). Suffix [C] or [CF] is attached to the color models.
Page 8 * Suffix [F] is not shown in the common part of specifications. 2.14 Compact and lightweight This camera is compact and lightweight; it is easy to integrate into industrial equipment. 2.15 EU RoHS & Chinese ROHS D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 9: Configuration
* No application software and manuals are attached to this camera. Optional part - Camera mounting kit Model name: CPT8600, CPTBUBG - Camera Cable CPCBG-xx * Contact your dealer / distributor for details of option units. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 10: Functions
This mode can also operate with AGC (Automatic Gain Control) to automatically adjust fluctuations in subject brightness across a wide range (ALC operation). 5.6.2 MANUAL Exposure time is adjustable by micro-second unit. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 11 Color models have RGB 3x3 matrixes correction. Sharpness Color models have sharpness correction. 5.10 Hue Color models have hue control. 5.11 Saturation Color models have saturation control. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 12 In this case, please input a proper trigger signal. 5.13 Trigger Delay You can add the delay between trigger signal input and the start of exposure. Trigger signal TriggerDelay Exposure GbE bus Image D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 13 (Sensor Read Out End - Exposure Time) (1) FrameTrigger : Reception of Frame Start Trigger. (2) FrameTriggerError : Rejection of Frame Start Trigger. (3) FrameTriggerWait : Start of waiting for Frame Start Trigger. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 14 EXT_TRIG Exposure CCD Transfer GigE Bus Delay Duration TIMER0 ACTIVE EXPOSURE ACTIVE FRAME ACTIVE FRAME TRANSFER FRAME TRIGGER WAIT * GPIO:default=Active Low D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 15 White lines may occur in the upper portions of the screen when strong light exists in a wide area durring the scalable mode. This is not a malfunction. If white lines occur, adjust the amount of incident light using the lens. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 16 : All pixels 255 LSB (@ 8-bit) - Bright Gray : Full screen 85 LSB (01010101B) (@ 8-bit) - Dark Gray : Full screen 170 LSB (10101010B) (@ 8-bit) - Ramp waveform D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 17: Specifications
Power consumption 3.1W Max 3.1W Max 2.9W Max 2.5W Max 3.4W Max 2.7W Max 2.7W Max 2.4W Max 2.2W Max 3.0W Max (at the all pixel readout) DC12V D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 18 DC+12V ±10% (ripple 100 mV(p-p) or less) Power consumption 3.3W Max 2.9W Max 3.5W Max (at the all pixel readout) 2.9W Max 2.5W Max 3.1W Max DC12V D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 19 10μs to 16s 10μs to 16s 30μs to 16s 30μs to 16s 30μs to 16s AE effective area Same as AGC effective area setting AE Exposure value ±2EV D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 20 TriggerWidth mode The exposure time depends on External trigger width Trigger Delay 0 to 4095μs (factory setting: 0μs) Anti-Chattering 2 to 1,000μs (factory setting: 2μs) sampling period D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 21 GigEVision Camera Interface Standard for Machine Vision Ver 1.2 Conformity cable Twist pair (Category 5e or over) Cable length Up to 100m (at the Unshielded Twist Pair (UTP) cable) D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 22 (e.g. dropping frames). In this case, change to frame rate setting lower. Event notification Event name FrameTrigger, FrameTriggerError, FrameTriggerWait ALCLatestInformation, ALCConverged Event notification delay approx. 4ms later from the event occurs Time stamp unit 16ns (62.5MHz) D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 23 (ELECOM CO., LTD) <<DC operation>> - DC Cable CPCBG-03 - LAN Cable LD-TWST/BM30 (ELECOM CO., LTD) Please confirm the EMC adaptability when it combines with parts other than them. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 24 This camera has two ways of power supply, - Supply from LAN cable (PoE) - Supply from camera cable (DC+12V ±10%) If both PoE and DC+12V are connected, power is supplied from PoE. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 25 6.12 Typical spectral response The lens characteristics and light source characteristics is not reflected in table. < BG030 > 1000 Wave Length [nm] < BG031 > 1000 Wave Length [nm] D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 31: Timing Chart
PayloadSize is total bytes of single frame. The formula applies when SCPS (Stream Channel Packet Size) is 1500 byte / packet. (T1 varies depending on the value of SCPS) D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 32 Trigger amplitude [μs] [μs] +3.3V 2.92 26.2 +12V 2.12 31.2 +24V 2.12 31.2 * Toff and Ton are typical value. * These values vary depending on operating environment. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 33 - When the interval of the input trigger signal is extremely short, or when the trigger signal is noisy, there is a possibility of causing the malfunction. In this case, please input a proper trigger signal. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 34 Ton: LINE1~LINE2 rising delay time LINE2 amplitude [μs] [μs] +3.3V 53.2 +12V 78.4 +24V 94.4 * Toff and Ton are typical value. * These values vary depending on operating environment. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 35: Warranty Rules
9. Forgery product, products which does not have proper serial number, products of which serial number is forged, damaged or deleted 10. All defects that happened after the expiration for a warranty term D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 36: Repair
10. The immunity from responsibility of the product is applied in the repair completion products. * Please refer for the inquiry about the software to our homepage or sales personnel. D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
Page 38 □ It sometimes occurs. □ It occurs, after time passes. （ □ Others ） <For dealer use> Reception date : Receipt No. : JOB No. : Check : D4211883H Copyright © 2012 - 2017 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/en/index.htm...
