3.3.26 Digital Multi-meter ( *Optional )
Click icon
to enter
1) SYMBOLS:
U: DC Voltage Measuring
Ω: Resistance Measuring
~
U
: AC Voltage Measuring
: Continuity Testing
AC/DC
Voltage and current measurement state display
Auto- range
The Multimeter auto adjust the range by input signal or tested components
Data hold
Hold data
Relative
Display the relative measurement value
measurement
Press the key to change display state
10A socket
In 10A current measurement state ,indicate use 10A socket
The current measurement value over the range, if in the Auto range state, to
Over range
switch Auto.
A: DC Current Measuring
: Diode Testing
~
A
: AC Current Measuring
: Capacitance Measuring
85
