Intellisystem IT-900-IPC Series User Manual page 128

PTZ control
Color bar generator
UTP Cable tester
Data monitor
Network test
Cable tracer
PoE /PSE voltage test
Digital Multi-meter
*(Optional)
Optical power meter
*(Optional)
Visual fault locator
*(Optional)
TDR cable test
*(Optional)
External power
supply
Battery
Rechargeable
Support RS485 control, Baud 600-115200bps, Compatible with more
than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin,
Yaan, etc
Output one channel PAL/NTSC color bar video signal for testing
monitor or video cable.(red, green ,blue, white and black color )
Test UTP cable connection status and display on the screen. Read the
number on the screen
Captures and analyzes the command data from controlling device, also
can send hexadecimal
IP address scan, link scan, and Ping test. Quickly search the for IP
camera's IP address on your network
Find a connected cable from a bundle of cables using audio tones
Measures PoE switch voltage and displays pin configuration
AC/DC Voltage, AC/DC current, Resistance, Capacitance, Data hold,
Relative measurement, Continuity testing. Testing speed: 3 times/
seconds, Data range -6600～+6600.
Calibrated Wavelength(nm) :850/1300/1310/1490/1550/1625nm
Power range(dBm) :-70～+10dBm
Test fiber's bending and breakage ( SM and MM fiber)
Cable's open circuit (Breakpoint) and short circuit measurement(BNC
cable, telephone cable)
POWER
DC 12V 2A
Built-in 7.4V Lithium polymer battery ,5000mAh
After charging 5-6 hours, normal working time 10 hours
