  • Page 1 IT-400-IPC Series IP Camera Tester User Manual （V01.00）...
  • Page 2 Thank you for purchasing the IP camera tester. Please read the manual before using the IP camera tester and use properly. For using the IP camera tester safely, please first read the「Safety Information」carefully in the manual. The manual should be kept well in case of reference. Keep the S/N label for after-sale service within warranty period.

  • Page 3: Table Of Contents

    Content 1 .Safety information ----------------------------------------------------------------------------------------------------- 1 2. IP Camera Tester Introduction --------------------------------------------------------------------------------------- 2 2.1 General ----------------------------------------------------------------------------------------------------------- 2 2.2 Packing list ------------------------------------------------------------------------------------------------------ 3 2.3 Function interface ---------------------------------------------------------------------------------------------- 4 3. Operation ---------------------------------------------------------------------------------------------------------------- 8 3.1 Installing the Battery ------------------------------------------------------------------------------------------- 8 3.2 Instrument connection ----------------------------------------------------------------------------------------- 9 3.2.1 IP camera connection --------------------------------------------------------------------------------- 9 3.2.2 Analog camera connection ------------------------------------------------------------------------- 11 3.2.3 HD Coaxial camera connection ------------------------------------------------------------------- 11...
  • Page 4 3.3.14 CVI camera test ( *Optional ) ----------------------------------------------------------------- 53 3.3.15 TVI camera test ( *Optional ) ------------------------------------------------------------------ 59 3.3.16 AHD camera test ( *Optional ) ---------------------------------------------------------------- 61 3.3.17 Network tool ---------------------------------------------------------------------------------------- 63 （1）IP address scan -------------------------------------------------------------------------------------- 63 （2）PING Test -------------------------------------------------------------------------------------------- 63 （3）Network test (Ethernet bandwidth test) --------------------------------------------------------- 64 （4）Port Flashing ----------------------------------------------------------------------------------------- 67 （5）DHCP server ----------------------------------------------------------------------------------------- 68...
  • Page 5 3.3.36 Update ----------------------------------------------------------------------------------------------- 100 3.3.37 Office ------------------------------------------------------------------------------------------------ 101 3.3.38 LED Flashlight ------------------------------------------------------------------------------------- 101 3.3.39 Browser --------------------------------------------------------------------------------------------- 102 3.3.40 Notepad:--------------------------------------------------------------------------------------------- 103 3.3.41 System Setting ------------------------------------------------------------------------------------- 104 3.3.42 File explorer ---------------------------------------------------------------------------------------- 108 3.3.43 Theme ----------------------------------------------------------------------------------------------- 110 3. 4 Audio test ---------------------------------------------------------------------------------------------------- 112 3.5 PoE power output -------------------------------------------------------------------------------------------- 113 3.7 DC12V 2A power output ---------------------------------------------------------------------------------- 114 4.

  • Page 6: Safety Information

    1 Safety information ◆ The tester is intended to use in compliance with the local rules of the electrical usage and avoid to apply at the places which are inapplicable for the use of electrics such as hospital, gas station etc. ◆...

  • Page 7: Ip Camera Tester Introduction

    ◆ Never connect the meter with any voltage source while the function switch is in the current, resistance, capacitance, diode, continuity, otherwise it will damage the meter. ◆ Never perform capacitance measurements unless the capacitor to be measured has been discharged fully.

  • Page 8: Packing List

    2.2 Packing list 1) Tester 2) Adaptor DC12V 2A 3) Network cable tester 4) Polymer lithium ion battery (7.4V DC 5000mAh) 5) BNC cable 6) RS485 cable 7) SC, ST Connector（Only for optical power meter） 8) Multi-meter test leads one pair of red and black (only for the Multi-meter models) 9) Output Power cable 10) Audio cable 11) TDR alligator clamp (only for TDR models)

  • Page 9: Function Interface

    2.3 Function interface...
  • Page 10 Press more than 2 seconds, turn on or off the device ,short press to turn on or off the menu display Set key Menu key, press it to call shortcut- menu Near focus: Focus the image nearby Far focus: Focus the image faraway TELE: zoom in the image WIDE: zoom out the image Open/set ,Confirm the setting of parameters, open or enlarge the aperture...
  • Page 11 decrease the aperture Multimeter interface (Optional) The power indicator: it lights green while the tester is powered on by the adapter The data accepted indicator: it lights red while the data is being received The RS485/RS232 data transmission indicator: it lights red while the data is being transmitted The charge indicator: it lights red while the battery is being charged.
  • Page 12 RS485 Interface: RS485communication for the PTZ RS232 Interface: RS232 communication for the PTZ"HD IN" , AHD /TVI/CVI Coaxial interface (Optional ) DC12V2A power output , for provisional DC power supply TDR cable test interface LED lamp SDI input (BNC interface) (Optional) HDMI input Video image signal output（BNC interface）/cable tracer interface (Optional) Video image signal input（BNC interface）/ AHD,CVI and TVI input (BNC interface)

  • Page 13: Operation

    Micro SD card moveable, comes with 8GB, supports up to 32GB Audio input HDMI output interface Audio and earphone output 5V2A USB power output , as power bank DC12V2A charging interface PSE power sourcing equipment. Tests PoE voltage PoE power supply output or LAN test port (Use to test PoE or non-PoE IP camera) 3.

  • Page 14: Instrument Connection

    When the battery icon is full or the charge indicator turns off automatically, indicate the battery charging is completed Notice: When the Charge Indicator turns off, the battery is approximately 90% charged. The charging time can be extended for about 1 hour and the charging time within 12 hours will not damage the battery.
  • Page 15 Note: 1) If the IP camera requires PoE power, then connect the IP camera to the IP tester’s LAN port . The tester will supply PoE Power for the IP camera. Click on the icon labeled POE to turn the PoE Power off or on.

  • Page 16: Analog Camera Connection

    3.2.2 Analog camera connection (1) Connect the camera's video output to the IP tester’s VIDEO IN. The image will display on the tester after pushing the PTZ icon (2) CCTV IP Tester “VIDEO OUT” interface connect to the Video input of monitor and optical video transmitter and receiver, the image display on the tester and monitor (3) Connect the camera or the speed dome RS485 controller cable to the tester RS485 interface, (Note positive and negative connection of the cable).
  • Page 17 (1) Connect the SDI camera's video output to the IP tester’s “SDI IN” interface, the image will display on the tester. The tester only come with SDI input interface. There is no SDI output interface. (2) Connect the SDI camera or the speed dome RS485 controller cable to the tester RS485 interface. Support RS232 PTZ controller;...

  • Page 18: Hdmi In ( *Optional )

    3.2.4 HDMI IN ( *Optional ) DVR or other device’s HDMI in port connect to tester’s HDMI in port, the meter will display input image 3.3 OSD menu  Press the key 2 seconds to turn on  Press the key 2 seconds to turn off ...
  • Page 19  In Lite mode, Press the icon several seconds, can move the icon to other apps  In lite mode, click the finger icon in the lower right corner to release lock icon, move icons and change function icons sequence. Normal mode ...
  • Page 20 In normal mode, press icon several seconds, go screen management status. Change icons sequence and move it to common tools bar. You can move the icon to any pages; self-define the number of icons in any page. Make interface sample and individuality.
  • Page 21 Create New Folder: Drag the icon to the folder in top right corner, enter the folder name. Icon will be auto placed in the new named folder. Press the folder several seconds, to change the folder name, you can move the icon out of folder, the folder will be auto deleted until move out all icons.

  • Page 22: Drop-Down Menu

    Click SD card, install or remove SD card. 3.3.2 Drop-down Menu Press and slide at right top right corner twice to open shortcut menu. The shortcut menu includes POE power output, IP settings, Wi-Fi, HDMI IN, CVBS, Video OUT, LAN, Brightness, settings etc.

  • Page 23: Short Cut-Menu

    HDMI: Click HDMI IN to enter in HDMI IN mode, it can converter test from analog to digital with dual test window IP & HDMIN or Analog & HDMI in. CVBS: Click icon “CVBS “to enter, you can test IP and analog camera at the same time. TV OUT: Click Video OUT to enter floating window, connecting the BNC cable to tester and appears analog video monitor interface, it can test circuit and BNC cable whether normal.

  • Page 24: Screen Capture

    other area on the screen, to exit the menu Short cut-menu setting, you can long press any app in the all applications list, it will auto move to shortcut menu. If delete any app in the short cut – menu, please select an app and press several seconds, it will be deleted.

  • Page 25: Testerplay

    3.3.5 TesterPlay Mobile screen projection (Only for android version) The meter creates WIFI hotspot, connect mobile phone to the tester’s WIFI hotspot, or the tester and mobile phone connect to the same Wi-fi network. Tap icon “ ”, then select “TesterPlay” app to enter, click “Start”...

  • Page 26: Rapid Video

    video 3.3.6 Rapid Press enter function one key to detect all network cameras and auto play the images.
  • Page 27 Auto log in and display camera image. Detailed operation refer to ONVIF function After exit ONVIF app, Click Refresh to search ip address.

  • Page 28: Ip Discovery

    3.3.7 IP discovery Press IP discovery tester auto-scan the whole network segment IP, as well as auto-modify the tester‘s IP to the same network segment with the scanned camera's IP. Tester’s IP address, Tester can auto-modify the tester‘s IP to the same network segment with Local IP：...

  • Page 29: Rapid Onvif Test

    3.3.8 Rapid ONVIF test Rapid ONVIF can display 4K H.265/H.264 camera image by tester mainstream, one key to activate Hikvision camera Press enter ONVIF function, the meter auto scan all ONVIF cameras in different network segments. It lists cameras name and IP address on the Left of screen. Tester can auto login camera and display camera image.
  • Page 30 Click the button “Refresh”, tester will scan the ONVIF camera again. Click the newly displayed ONVIF camera on the “Device List“. The tester will show the IP camera’s relative information and settings. Activate HIKVISION Camera: When connected unactivated HIKVISION Camera, tester can auto recognized, And prompt "The camera is not active, you need to activate it", click "OK"...
  • Page 31 When comes out “activate success” prompt, click login to display camera image. Pop-up settings menu when click the “ONVIF setting” icon in the upper left corner Across network segments scan: After open this function , enter “Setting”-“IP Settings”-“Advanced” to add other network segments IP, Rapid ONVIF function can across network segments to scan camera’s Auto Login: After open this function, tester can auto login camera and display camera image (The login password is the same with last time, the first time using password is the default password "admin")
  • Page 32 View manual: Open Manual Restore Defaults: Revert “Rapid ONVIF” to default settings Confirm: Save the modified parameters Click “MENU” icon to open camera setting. While in the “Live video” menu, click “Video Menu” at the top right of the image to access the following tools: Snapshot, Record, Photo, Playback, PTZ and Settings...
  • Page 33 ONVIF PTZ control: Tap the image in the direction you want the PTZ camera to move. Tap the left side of the image to move left, right to go right, up to go up and down to go down. Compatible IP PTZ cameras will rotate accordingly.
  • Page 34 Profiles：Click “profiles"，can view video streaming current configuration files, as well as switch between Major stream and minor stream.
  • Page 35 Preview pictures：Quickly preview and zoom in or out pictures, automatically and manual refresh Identification: click “Identification” to view information of the camera Time set: click “Time set”, Select "Manual set" to set up the time of camera...
  • Page 36 Maintenance: For camera software reset or restore to factory settings. User Set: Modify camera user name, password etc parameters Network setting：Click “Network Set “to change the IP address. Some cameras cannot support change IP address, so there is no change after saving.
  • Page 37 Zoom in image: press the key to enter the zoom mode. Press it again to exit zoom mode. When the image is enlarged tap left, right, up or down on the image to move the whole image on the screen When the image is enlarged, if not operate on touch screen, it can operate by the keyboard, press the to zoon in , press the key to zoom out ,press upward and downward key to move...
  • Page 38 Snapshot：Click bottom “snapshot” to screenshot the image and store it to SD card. If select manual storage, appears dialog box “Input Name” , user-defined the files name(by Chinese character, English letter ,or digit ) to save in SD card, if select “Auto- storage”， the tester auto stores the files after snapshot.
  • Page 39 To rename or delete a photo, click and hold on the file until this screen appears: Video files can play in the Video player on the main menu. Set preset position: Move the camera to preset position, enter the preset number on the Bottom right corner to complete position preset.
  • Page 40 PTZ Speed set: Horizontal and Vertical Speed set RTSP: Get RTSP address of the current camera Doc: Auto generate test reports document of camera, click "Create document”. Click Preview to view the report document...

  • Page 41: Ip Camera Test

    Enter the camera test information; click "Create Document" to complete the report. Click doc menu again, you can preview the report document. Icons description: the description of function icons on the bottom toolbar 3.3.9 IP camera test Display image from the 4K H.265 camera by mainstream Click icon to enter IP camera test Note: Currently, the IPC Test App only supports some brands’...
  • Page 42 not fully integrated, please use the ONVIF or RTSP apps. IPC test interface Local IP: This is the tester’s IP address. Click “Edit“ to enter “IP setting“ and change the tester ‘s IP address settings IP camera type: Click on the IP Camera type to select the Manufacturer and model number of the integrated IP camera Manual：Click IP camera type, list Honeywell, Kodak, Tiandy, Aipu-waton, ACTi, WoshiDA IP camera etc.
  • Page 43 Stream code: When test camera via RTSP, you can select mainstream or sub stream to test (if camera’s RTSP have not been start or without, it will tip “auto match fail, please witch to manually selecting IP Camera's IP: Enter the IP camera’s IP address manually or click “Search” to auto-scan for the IP camera’s IP address.

  • Page 44: Hdmi In ( *Optional )

    If IP address setting has error or IP camera is not connected. The tester prompts “Network Error” Click to quit from image display and return to IP camera test interface. Once you are viewing video on the IPC Test app, you will see the “Video Menu” icon on the top right.
  • Page 45 for the snapshot. If the unit is set up to automatically set file names, this box will not pop up. (2) Video record When you click the “Record” icon, video starts recording. A red recording icon appears on the screen and begins to flash and a timer appears indicating the time elapsed for the video.
  • Page 46 (3)Photo Click the icon “photo” to enter, click the selected thumbnail photo to display it on the screen. Double-tap the image you want to view to make it full screen. Double-click again the photo to return. To rename or delete an image, click and hold on the file until this screen below appears Click to close and return to PTZ controller.
  • Page 47 (4) Recorded video playback Click the “Playback” icon to view your recorded videos. Tap on the video file image you want to watch. To rename or delete a video, click and hold on the file until this screen appears: Video files also can play in the main menu “Video Player".

  • Page 48: Video Monitor Test

    3.3.11 Video monitor test Analog camera test and PTZ control, click icon to enter Display the input video image, click the top menu bar icon to enter video level meter, (PEAK level, SYNC level, COLOR BURST measurement) Select relative function on the right side Toolbar to operate , functions including “Photos”, “Snapshot” , “Record”...
  • Page 49 A. Protocol Use the up and down arrow keys to move the yellow cursor to the “protocol ”, set corresponding Protocol and support more than thirty PTZ protocols. Such as Pelco-D,Samsung, Yaan, LiLin, CSR600, Panasonic,Sony-EVI etc. B. Port Click and move, to “port” Select the communication port for the PTZ camera controlling (RS485) C.
  • Page 50 PTZ Control:  Press arrow keys to control to control the PTZ direction of rotation  Press the key to switch on or turn off the aperture.  Press the key , adjust the focus manually  Press the key , manually adjust the zoom 2) Video and storage setting Click icon “set”, to enter and set analog video image brightness, contrast, color saturation, as well as the...
  • Page 51 If not use touch screen to operate, press the key to zoom out, press the key zoom in, press upward and downward key to move the image For analog video input, as the resolution is 720*480, it is normal that the zoom in image is not clear.
  • Page 52 (5) Video record When you click the “Record” icon, video starts recording. A red recording icon appears on the screen and begins to flash and a timer appears indicating the time elapsed for the video. Click on the “Record” icon again to stop recording and save the video file to the SD card. if select manual storage, before recording begins ,appears dialog box “Input Name”...
  • Page 53 To rename or delete an image, click and hold on the file until this screen below appears. (7) Recorded video playback Click the “Playback” icon to view your recorded videos. Tap on the video file image you want to watch. To rename or delete a video, click and hold on the file until this screen appears:...
  • Page 54 Video files also can play in the main menu “Video Player". (8) Video level meter Click the icon to enter, the IP camera tester has adopted hardware high-speed sampling and processing technology, can perform both NTSC and PAL video amplitude signal measurements for PEAK to PEAK, SYNC levels and COLOR BURST chroma level.
  • Page 55 Video signal level 140±15IRE NTSC Chroma level( COLOR BURST) 40±5IRE SYNC signal level 40±5IRE Video signal level 1000±200mV Chroma level( COLOR BURST) 300±35mV SYNC signal level 300±35mV Video signal PEAK to PEAK level: For NTSC format, the video signal level is 140±15IRE For PAL format, the video signal level is 1000±200mV If the level is too low, it will cause the image to lose quality and limit the distance it will travel over cable.

  • Page 56: Color-Bar Generator (Tv Out)

    3.3.12 Color-bar generator (TV OUT) to enter, the tester sends the color bars from the “Video out” port, click the icon “PAL”, Click select “PAL/NTSC” output formats. Click the selected color-bars, testing image or single bar (red, green, blue, white or black). Double click to full display on the screen and output, click to return main menu.

  • Page 57: Sdi Camera Test ( *Optional )

    terminal’ s connect its receiving port. A. When maintaining the dome camera, the tester sends out the color bar by its BNC output to the monitor at the monitoring center. If the monitor receive the color bar, it means the video transmit channel works normally.

  • Page 58: Cvi Camera Test ( *Optional )

    1920x1080I 50Hz 1920x1080I 60Hz IPC tester’s HDMI output port can be use as SDI to HDMI converter, output HD SDI image to HD TV monitor. Select relative function on the right side Toolbar to operate, “Snapshot“ , “Record”, “Photos ”, “Video playback”, “PTZ control”, “Video Brightness and Storage set”, the operation is the same to the video monitor function, please refer to the relevant instructions “3.3.1”...
  • Page 59 （1）PTZ control 1.1 Coaxial PTZ control Click the icon “PTZ” on the right toolbar to do the corresponding setting. “Port”: select coaxial control...
  • Page 60 Enter PTZ address to perform parameters setting Operation instructions, please refer to “3.3.1 PTZ (1) Video monitor test” The PTZ address in the tester must be consistent with the dome camera or decoder, then the IPC tester can test .After setting the parameter, the tester can control the PTZ and lens. To control PTZ by screen touch: Tap left, right, upward and downward on the touch screen to control the PTZ rotation direction, PTZ cameras will rotate accordingly.
  • Page 61  Press arrow keys to control to control the PTZ direction of rotation  Press the key to switch on or turn off the aperture.  Press the key , adjust the focus manually  Press the key , manually adjust the zoom Set preset position: Move the PTZ camera to the preset position, the Tap it and input preset position number.
  • Page 62 1.2 RS485 control Operation instructions, please refer to “3.3.1 PTZ (1) PTZ control parameters setting” （2）Coaxial camera menu setting Tap icon “UTC””, select “menu setting” to enter the dome camera menu Input calling dome camera menu address code, after finishing the parameter settings, you can press the or click the icon to call the dome camera menu.
  • Page 63 Press arrow keys to set (3) Snapshot, record, photo viewer and video play back, please refer to “3.3.1 PTZ (1) Video monitor test”. Tap “close menu” or press the key “ ”to close camera menu...

  • Page 64: Tvi Camera Test ( *Optional )

    (4) Save setting Click icon “Set” on the right toolbar to enter storage setting. Support auto-storage and manual storage. When select manual storage, user can name and store the files. 3.3.15 TVI camera test ( *Optional ) HD TVI camera, TVI dome camera test and PTZ control, Click icon to enter When HD TVI signal input, the tester will display the image resolution on the top bar.
  • Page 65 1280x720P 25FPS / 1280x720P30FPS / 1280x720P 50FPS / 1280x720P 60FPS 1920x1080P 25FPS / 1920x1080P 30FPS / 1920x1080P 50FPS / 1920x1080P 60FPS /2048x1536P 18FPS/2048x1536P 25FPS/2048x1536P 30FPS /2560x1440P 15 FPS/2560x1440P 25 FPS/2560x1440P 30 FPS/2688x1520P 15FPS/2592x1944P 12.5FPS/2592x1944P 20FPS Coaxial camera menu settings Tap icon “UTC”, select “menu setting” to enter the dome camera menu...

  • Page 66: Ahd Camera Test ( *Optional )

    Input calling dome camera menu address code, after finishing the parameter settings, you can press the or click the icon to call the dome camera menu More operation instructions (such as PTZ control, coaxial camera menu setting, snapshot, recording and playback etc), please refer to“3.3.6 CVI camera test”...
  • Page 67 When AHD signal input, the tester will display the image resolution on the top bar. Double-taps on the screen to make the image displayed full screen. The tester supports resolution as follows: 1280x720P 25FPS / 1280x720P 30FPS / 1920x1080P 25FPS / 1920x1080P 30FPS/2048x1536P 18FPS/2048x1536P 25FPS/2048x1536P 30FPS /2560x1440P 15 FPS/2560x1440P 25 FPS/ 2560x1440P 30 FPS/2592x1944P 12.5FPS/2592x1944P 20FPS (1) Coaxial PTZ control...

  • Page 68: Network Tool

    More operation instructions please refer to “3.3.6 CVI camera test” 3.3.17 Network tool （1）IP address scan Connect the cable to the LAN port, click icon to enter, Set your IP address search range by changing the Start and End IP addresses. Click the “Start” button to scan the IP address range. You can also input an IP address in the Port Number Scan to scan for open ports.

  • Page 69: 3）Network Test (Ethernet Bandwidth Test)

    Application: PING testing is the most conventional network debugging tools. It is used for testing if the connected IP camera or other network equipment’s Ethernet port is working normally and the IP address is correct. It’s normal that the first data packet will be lost when test start. （3）Network test (Ethernet bandwidth test) Network test (Ethernet bandwidth test) To use the Network tester, you will need two IP testers.
  • Page 70 b) Start send packet test: Using the other IP tester, type in the Server's IP address at the top right corner of the screen. This app is used to send packets for network speed testing. Click the “Start” button to send the packets and start testing. Network bandwidth testing can also be tested with a computer using compatible network bandwidth testing software.
  • Page 71 “Start” to test network bandwidth. Or use tester as a Server, computer as test Client（select Client, input tester’s IP address to test） When use tester as Server, shows results:...

  • Page 72: 4）Port Flashing

    （4）Port Flashing Connect a network cable to the meter’s “LAN” port, click the icon to open the Port Flashing app. Click “Start”. The IP tester sends a unique signal to make the connected LAN port of the switch flash. If the tester and PoE switch are connected well, the LAN port of POE switch flash at special frequency, If not, no any changes on the LAN port Application: The tester will send special signals to make the connected LAN port flicker at special frequency, which...

  • Page 73: 5）Dhcp Server

    （5）DHCP server Click on the DHCP icon to open the DHCP server app. Select the “Start” check box at the top and make any desired changes to the network settings. Click “Save” to start assigning dynamic IP addresses for IP cameras and other networked devices. Click the “Refresh” button to check your Client list. （6）Trace route It is used to determine path of the IP packet access target.

  • Page 74: 7）Link Monitor

    Click “start” to trace the goal address （7）Link monitor Click the icon to open the Link Monitor app. This app is used to see if an IP address is occupied by other network devices. This will avoid new address conflicts Click “Add”...

  • Page 75: Rapid Ip Discovery

    Application: Add an IP camera or other network device to the current network group, the new IP address must not be occupied, otherwise it will result IP conflicts and stop the equipment normal working. Link monitor can check if the new setting IP address is occupied. 3.3.18 Rapid IP Discovery Connect the cable to tester’s LAN port.
  • Page 76 The IP camera needs to be connected to the LAN port before you turn PoE Power on. If the IP camera Supports PoE, the PoE power is delivered via pins 1, 2, 3, and 6 on the LAN port. The IP tester will display “48V ON”...

  • Page 77: Cable Test

    3.3.20 Cable Test Click icon to enter Test LAN cable or telephone cable. Connect LAN cable or telephone cable with the CCTV tester and cable tester. And then the connecting status, cable type and the sequence of wires as well as the serial number of the cable tester kit will be displayed.

  • Page 78: Rj45 Cable Tdr Test

    3.3.21 RJ45 cable TDR test Connect cable to tester’s LAN port, click icon “ ” to enter RJ45 cable TDR test app. Single test: Test cable status, length and attenuation. Repeat test: Continue to test cable status, length and attenuation. Status: After link up, screen display “online”, if not link up or open circuit, screen display ”open circuit”, if cable pair is short circuit, screen display “short circuit”...
  • Page 79 Advanced Test: Test cable pair status, length, attenuation, reflectivity, impedance, skew and other parameter. Attenuation reflectivity: After link up, if reflectivity value is 0, it is the best quality communication Impedance: After link up, if the impedance value is 100 Ω , it is the best quality communication, the range is generally in 85-135 Ω...
  • Page 80 Cable sequence diagram: A straight- through and cross-over cable diagram, the cable sequence display for reference Click “Help”, check the instruction of all parameters.

  • Page 81: Cable Search (*Optional )

    3.3.22 Cable Search (*Optional ) Connect test cable or BNC cable to the UTP port or the CABLE SCAN (VIDEO OUT) port on the bottom. Click icon to enter, click the Number on the screen to adjust audio type. Use the blue Combination cable identifier and network cable tester’s copper pointer to touch all the cables in the bundle .

  • Page 82: Tdr Cable Test ( *Optional )

    negative pole -, otherwise will damage the tester. Note: While the cable tracer tester is receiving the audio signal from the tester, it may be influenced by other signals and make some noise. 3.3.23 TDR cable test ( *Optional ) Note: The testing cable can’t be connected to any equipment;...
  • Page 83 in cable type for testing, click “+” and“-” to adjust cable’s wave speed. User-defined calibration: Choose the cable 100 meters to 200 meters (more than 50 meters), click “Cable”, “Type” to select user-defined 1 for calibration, 11 groups user-defined can be set. Select user-defined and click “Calibration “to enter test , click “user-defined 1”can define cable name, such as: AiPu BNC-5 2.
  • Page 84 3. Click “+”or“-” to adjust wave speed, while display length is the same with the actual Length, click “Save“ to save calibration data. It can be used for the same cable testing next time. Application: TDR test is the use of pulse reflection method, to transmit pulse signal for tested cable, when cable is open circuit or short-circuit, reflected pulse is generated, the tester receives and deals with the reflected wave, measurement results displayed on the screen.

  • Page 85: Poe Voltage And Power Measurement

    3.3.24 PoE voltage and power measurement Click icon to enter PoE voltage measurement Connect a network cable from a PoE switch to the IP tester’s PSE IN port. Connect an IP camera or other PoE using node to IP tester’s LAN port, the PoE voltage and the cable’s pin connection status show on the screen.

  • Page 86: Power Input Test

    3.3.25 12V power input test Connect 12V power adaptor to tester’s charging port, then click icon “PoE” to enter voltage measurement app ,screen show the current adaptor input voltage and power. Note: the current 12V input measured power is the battery charging power and the device working power,the measured power will change depending on the different of battery power and backlight brightness.

  • Page 87: Digital Multi-Meter ( *Optional )

    3.3.26 Digital Multi-meter ( *Optional ) 1. Click icon to enter 2) SYMBOLS: U: DC Voltage Measuring A: DC Current Measuring Ω: Resistance Measuring : Diode Testing : AC Voltage Measuring : AC Current Measuring : Continuity Testing : Capacitance Measuring AC/DC Voltage and current measurement state display Auto- range...
  • Page 88 ⑶ OPERATING INSTRUCTION DC Voltage Measuring a. Connect the black test lead to the “COM” jack and the red test lead to the “V/Ω” jack. b. Select , enter the DC voltage measurement. c. the tester default Auto range status ,by click “DC auto range” , press the key can select manual range and restore auto range .
  • Page 89 00.00mA  66.00mA range 000.0mA  660.0mA range  10.00A range（use 10A socket） 00.00A d. Select the range to enter current measurement Note:  When only the figure “OL” is displayed, it indicates over range situation and the higher range has to be selected.
  • Page 90 00.00 KΩ  66.00KΩ range 000.0 KΩ  660.0KΩ range 0.000 MΩ  6.600MΩ range 00.00 MΩ  66.00MΩ rang Continuity Testing Ω a. Connect the black test lead to the “COM” jack and the red test lead to the “V/ ”...
  • Page 91  66.00μF range 00.00uF  660.0μF range 000.0uF  0.000mF 6.600mF range  00.00mF 66.00mF range d. Before connect test leads across two sides of the capacitor under measurement, be sure that the capacitor has been discharged fully. Note: The capacitance of a capacitor should be tested separately, should not test in the installation of circuit.

  • Page 92: Optical Power Meter ( *Optional )

    Relative value measurement Click “Relative “to enter, the tester Auto-save the data, the displayed new measurement and relative value is red color. Press it again to quit The hold function and the relative value be combined use, the display value is yellow The meter protection ...
  • Page 93 again to quit. Relative power value (optical link loss) measurement While testing, set the wavelength for measurement. Click “relative” (difference) to test, the tester Auto save current fiber power value as the base reference value. Input another optical fiber to be measured, the displayed new measurement and relative value is red color.

  • Page 94: Visual Fault Locator ( *Optional )

    Data hold and Relative measuring use together, the data is yellow while the function is effect. 3.3.28 Visual Fault Locator ( *Optional ) Click icon to enter VFL four status can select——“Steady mode”, “Evasive 1Hz”, “Evasive 2Hz”and“Time off”. Click button “Steady mode” to enter steady status, click button “Evasive 1Hz” and “Evasive 2Hz, to enter pulse mode, click button “Time off”, VFL is turned off.

  • Page 95: Audio Record

    Click” Steady mode”, red laser source emits steady, click again to quit. Click icons “Evasive 1Hz”or“Evasive 2Hz”to enter pulse mode, the red laser source is emitted by a certain frequency, press it again to quit 3.3.29 Audio Record Connect an audio device to the IP tester’s audio input port. Click the icon to enter the Audio Recorder app.

  • Page 96: Data Monitor

    3.3.30 Data monitor Pls click icon to enter Click “Setting” to choose the baud rate of RS485/RS232; it must be the same as the DVR or the Control keyboard The DVR or Control keyboard send the code to the tester, if it can be read, the protocol will shown on the upper right, like Pelco-D, if not, like P:--- While the tester receives the code, press the key to empty.

  • Page 97: Audio Player

    3.3.31 Audio player Click the icon to enter. The audio player only supports MP3 format Audio files. 3.3.32 Media Player Click the icon to enter The Media player can browse video and image files. It supports the video formats of MP4, H.264, MPEG4, and MKV.

  • Page 98: Rtsp Player

    3.3.33 RTSP Player The RTSP Player app will allow you to view the RTSP video stream from an IP camera. If you were unable to view your camera via the ONVIF or IPC Test apps, it is possible your camera will have an RTSP stream and you can view live video.

  • Page 99: Hik Test Tool

    IPC Password: Enter the IP camera’s password. Once you have entered all the necessary information, select Enter at the bottom left to view the RTSP stream. Note: in the event the ip tester does not auto detect the rtsp stream, refer to the specific camera manufacturer for the specific rtsp stream url.
  • Page 100 2 . Input password：Input new password, tap “ok” to activate 3. Confirm activation After activating the camera, the program default modifies the camera IP. Activated multiple cameras in the local area Network, and pop-up menu to modify IP, improve project efficiency.
  • Page 101 Play: display image from the camera Modify network information: Change the camera IP address, subnet mask and gateway etc. Modify user information: Modify the camera's user name and password. Factory Reset： Camera factory reset...

  • Page 102: Dahua Test Tool

    3.3.35 Dahua test tool Dahua test tool is developed for installation and debugging of the Dahua IP camera, it can display image, and modify IP, user name and password etc. Making Dahua camera test more convenient and quickly. Click “DH” icon , to enter Dahua test tool.
  • Page 103 Pop up stream menu, select mainstream or second stream to test If the camera not supports non-verification login, please select “camera” of online detection menu, and input correct user name and password, then click “log in”. After logging successful, you can test it. Play: select mainstream or seconded stream, IP camera live video display...
  • Page 104 Modify network information: modify camera parameter, such as ip address, subnet mask, gateway etc. Modify user information: modify camera user name and password, which is onvif, Dahua test tool, IPC TESTE user name and password, not web user name and password.

  • Page 105: Update

    Factory reset setting: camera will be soft reset, and the device’s user name, password and network set be saved. Other settings information is factory reset. 3.3.36 Update Copy the downloaded update file to SD card "update" directory, if no directory, please create one. Click the icon to open the Update menu.

  • Page 106: Office

    If there are update programs, applications will be listed in the interface, click related applications, update to the latest version. 3.3.37 Office Quick office app (support excel, word, ppt format) doc. editable 3.3.38 LED Flashlight It is convenient for the installation or maintenance in the evening or in the dark. Click icon enter...

  • Page 107: Browser

    While in the flashlight app, click the red button to turn on the LED lamp. Press it again to turn it off. If you don’t press the red button to shut off the lamp and press the button to exit the app, the lamp will stay on.

  • Page 108: Notepad

    3.3.40 Notepad: Notepad can be used to record the important testing results, click the key “Save” to save the contents. Notepad can auto record the storage date and time. pls click to view the notepad , all saving contents display. Click each record bar to show the details.

  • Page 109: System Setting

    3.3.41 System Setting Click icon to enter Language: Select your desired language: English, Chinese, Korean, Russian, Italian, Polish, Spanish, French or Japanese Typewriting: You can select typewriting or install other typewriting: Date/Time: Set the Date/time of the IP tester...
  • Page 110 IP setting: Manually set the IP address, Subnet Mask, Default Gateway and DNS address or select “Dynamic allocation” to use DHCP. WLAN Net: Turn WiFi off or on by pressing the “Open the wifi” button. Once WiFi is turned on, and click connected WIFI, it will scan for wireless networks in your area.
  • Page 111 Wi-Fi hotspot: input “SSID” name and “password”, and then click “ok”to create Wi-Fi hotspot. Brightness: Set the desired brightness of the IP tester and adjust the sleep time settings. Volume: Set volume level SD Card: Displays SD Card Capacity. You can also format the SD card or unmounts it before removing it.
  • Page 112 Start the FTP server and then input the tester’s FTP address in the PC’s address bar. This will enable the PC to read, copy and edit the files from the SD card without the use of SD card reader. Version information: Shows applications version information, if press any apps icon several seconds to uninstall Screen display rotation::Click on “Screen Rotation”...

  • Page 113: File Explorer

    Modify Lock screen password, you need input lock password again. Select password Lock screen or pattern Lock screen to reset lock screen password. After reset pattern lock screen, you need to draw a new lock pattern. Restore the factory settings: If the tester to restore factory settings, all your personal files and apps will be removed.
  • Page 114 FTP server You can choose internal or external SD card. Other operation details, please refer to FTP settings...

  • Page 115: Theme

    3.3.43 Theme Click Theme icon to enter themes setting. Desktop style: you can select lite mode or normal mode. Theme: Pressing square area’s any color icon several seconds, the selected color icon will be auto move the rectangle area, if you press selected color several seconds, and it will be auto deleted Theme colors include fixed order and random order, and click “set”...
  • Page 116 After finished color setting, click “set” to set it as desktop or application background. Set as desktop background: Setting color as desktop background Set as application background: Set color as application background Set at the same time: Setting color as desktop background and application background. Cancel: Cancel current setting.

  • Page 117: Audio Test

    Sliding effect: Tester’s sliding effect includes stereo effect, folding effect, Left and right folding, rotate effect, Ombre effect etc, selecting one of effect to view slide effect in the square area, and click “set” to save 3. 4 Audio test You can test the audio input from audio pickup devices by connecting the audio pickup device to the IP tester with the supplied audio cable.

  • Page 118: Poe Power Output

    3.5 PoE power output The IP tester supports PoE (Power over Ethernet) output to an IP camera via the LAN port. Data transmission and 48VDC use the network cable’s 1, 2, 3, and 6 pins to deliver power. If the IP camera supports PoE, you can directly connect to the camera without the use of an external power supply.

  • Page 119: Dc12V 2A Power Output

    3.7 DC12V 2A power output When the IP tester is turned on, the DC 12V power output ON by default. The smaller end of the supplied converter cable connects to the tester’s DC12V/2A OUTPUT and the other end connects to the camera’s power input.
  • Page 120 auto enter protection mode. Disconnect all the connections of the tester and then connect the tester with power adaptor to resume the tester. Make sure the tester has a sufficient charge otherwise the tester will not able to provide enough output power 3.8 USB 5V 2A power output When the tester is turned on, the 12VDC and 5VDC power output functions are automatically turned on.

  • Page 121: Specifications

    4. Specifications 4.1 General Specifications Model IP Camera Tester【*】models Optional Display New 4.3 inch IPS touch screen CCTV tester 960x540 resolution Network port 10/100/1000M auto adjust, RJ45 Built in WIFI,speeds150M, allows you to connect to a wireless network and view IP WIFI cameras New hardware decoding,4K,H.265/H.264 camera image display by mainstream...
  • Page 122 Support 720x480P/60fps720x576P/60fps，1280x720P/25/30/ 50/60fps， HDMI IN 1920x1080P/25/30/50/60fps，1920x1080I/50/60fps，800x600P/60fps， *(Optional) 1024x768P/60fps，1280x1024P/60fps. HDMI output 1 channel HDMI output, supports up to 1080p 12V/2A power output Output DC12V/2A power to camera RJ45 cable TDR test and cable quality test, to test cable pair status, length, RJ45 cable TDR test attenuation reflectivity, impedance, skew and other parameter.

  • Page 123: Multi-Meter Specifications

    Visual fault locator Test fiber’s bending and breakage ( SM and MM fiber) *(Optional) Cable’s open circuit (Breakpoint) and short circuit measurement(BNC cable, TDR cable test *(Optional) telephone cable) POWER External power supply DC 12V 2A Battery Built-in 7.4V Lithium polymer battery ,5000mAh Rechargeable After charging 5~6 hours, normal working time 10 hours Parameter...
  • Page 124 AC voltage Range Accuracy Resolution 660.0mV (Manual range) ±（1.5%+6） 0.1mV 6.600V 66.00V ±（0.8%+6） 10mV 660.0V 100mV DC current Range Accuracy Resolution 6.600mA 66.00mA ±（0.5%+3） 10uA 660.0mA 100uA 10.00A ±（1%+5） 10mA AC current Range Accuracy Resolution 6.600mA 66.00mA ±（0.5%+3） 10uA 660.0mA 100uA 10.00A ±（1%+5）...
  • Page 125 6.600MΩ 1KΩ 66MΩ 10KΩ ±（1.2%+5） Continuity Range Resolution Function The measurement value less 30Ω±3Ω,the tester will 660.0Ω 0.1Ω sound Diode Range Resolution Function Schottky diode:0.15~0.25V 2.0V rectifier diode:0.6~1.0V triode PN junction:0.5~0.8V Capacitance Range Accuracy Resolution 6.600nF ±（0.5%+20） 66.00nF 10pF 660.0nF 100pF ±（3.5%+8）...

  • Page 126: Optical Power Meter Specifications

    4.3 Optical power meter specifications -70～+10dBm Measure Range(dBm) 850nm,1300nm,1310nm,1490nm,1550nm,1625nm Wavelength(nm) Detector InGaAs ＜±3%dB(-10dBm,22℃) ＜±5%dB(full range,22℃) Uncertainly Linear:0.1% ; Nonlinear:0.01dBm Display Resolution -10～+50 Operating Temperature(℃) -20～+70 Storage Temperature (℃) Connector type FC/PC 4.4 Visual fault locator specifications Laser type Wavelength Calibration 650nm Output power 5mW（Optional 10mW,20mW）...
