4.3 Optical power meter specifications

Measure Range(dBm)
Wavelength(nm)
Detector
Uncertainly
Display Resolution
Operating Temperature(℃)
Storage Temperature (℃)
Connector type

4.4 Visual fault locator specifications

Laser type
Wavelength Calibration
Output power
Modulation mode
Measurement Range
Connector
Working Temperature
Operating Temperature
The data above is only for reference and any change of them will not be informed in advance. For more
detailed technical inquiries, please feel free to call the Technical Department of our company.
-70～+10dBm
850nm,1300nm,1310nm,1490nm,1550nm,1625nm
InGaAs
＜±3%dB(-10dBm,22℃)
＜±5%dB(full range,22℃)
Linear:0.1% ; Nonlinear:0.01dBm
-10～+50
-20～+70
FC/PC
LD
650nm
5mW（Optional 10mW,20mW）
CW/1Hz/2Hz
5KM（Optional 10-20KM）
FC/PC exchangeable
－10℃～+50℃
-20℃～+70℃
