D. Address
Set the ID according the ID of PTZ camera (0~254), the setting address data must be consistent the
speed dome address.
E. Pan speed: Set the pan speed of PTZ camera (0~63)
F. Tilt speed: Set the tilt speed of PTZ camera (0~63)
G. Set preset position (Set PS)
Click and select "Set PS", set and save preset position number (1~128).
H. Call the preset position (Go ps)
Click and select "Set PS", set and save preset position number (1~128), click "sure" to save,
Call some special preset number, can call the dome camera menu.
Check and set the protocols, address, interface and baud, all must be consistent with the dome camera,
then the IPC tester can test .After setting the parameter, the tester can control the PTZ and lens.
To control PTZ by screen touch:
Tap left, right, upward and downward on the touch screen to control the PTZ rotation direction. By two
fingers move outward and inward on the touch screen to zoom in and out the PTZ.
PTZ Control:
Press the key
Press the key or
Press the key or
Press the key or
control the PTZ direction of rotation
, to switch on or turn off the aperture.
, adjust the focus manually
, manually adjust the zoom
