Intellisystem IT-900-IPC Series User Manual page 127

*（Optional）
TVI video signal test
（Optional）
AHD video signal test
*（Optional）
Analog video test
Video level meter
Zoom Image
Snapshot, Video
record and playback
12V/2A power output
USB 5V power
output
PoE power output
Screen management
Theme
drop-down menu
Audio test
25,30,50,60fps/ 1080p 25,30fps/2560x1440p 25fps,30fps，UTC control
and call OSD menu
1 channel TVI input （ BNC interface ） ,resolution support 720p
25,30,50,60fps/ 1080p 25,30fps /2048x1536p 18,25,30fps , 2560x1440p
15,25,30fps/ 2688x1520p 15fps , 2592x1944p 12.5,20fps，UTC control
and call OSD menu
1 channel AHD input （BNC interface） ,resolution support 720p 25,30fps
/ 1080p 25,30fps/2048x1536p 18,25,30fps , 2560x1440p 15,25,30fps/
2592x1944p 12.5,20fps，UTC control and call OSD menu
1 channel BNC Input & 1 channel BNC Output , NTSC/PAL (Auto
adapt)
PEAK video signal level, SYNC signal level, COLOR BURST chroma
level measurement for cvbs camera.
Supports Analog and IP camera image zooming & movement
Capture current images and record live video as JPG file. Media player
will view photos and playback video
Output DC12V/2A power to camera
5V 2A power output only ,NO data
48V PoE power output, Max power 24W
Lite mode and normal model available. Under normal mode, you can
change icons sequence and self-define the number of icons in each page
Self-define icons, desktop and application interface background, modify
interface sliding effect
PoE power switch ,IP setting, WLAN switch , HDMI IN functions etc
screen lock, password lock screen or pattern lock
1 channel audio signal input and 1 channel audio signal output to
connect headphones
122
