TJM 070SB13F69G Fitting Instructions Manual

Product:
Vehicle:
Part No. Ente 070SB13F69G
Australian Standards Relating to Installing Vehicle Frontal Protection Systems (VFPSs): AS 4876.1-2002
a) Do not attach a V.F.P.S. to a vehicle using anchorages not intended for this purpose (e.g. engine mounting bolts), other than those
specified by the V.F.P.S. manufacturer in this instruction.
b) Do not use this product for any vehicle make or model other than those specified by the V.F.P.S. manufacturer (as above).
c) Do not remove any plaques or labels from the V.F.P.S.
d) Do not modify the structure of the V.F.P.S. in any way.
1. If any product or part of a product manufactured by TJM is found to be defective during a period of three (3) years after the date of purchase,
TJM shall repair (at TJM's discretion) the defective product or part.
2. Any defect in a product distributed by TJM, but not manufactured by TJM, shall be dealt with in accordance with, and to the extent of, the
warranty offered by the manufacturer of that product.
3. TJM does not warrant that the products manufactured by it comply with the laws of the place where those products are purchased or used. It is
the sole responsibility of the purchaser to ascertain whether products being purchased, or the affixation of those products to any other object,
comply with local laws.
4. Except to the extent described in this warranty, TJM shall not be liable for any other claims, including claims arising from incorrect fitment,
product or vehicle modification, faulty design, the use of the product on any indirect special or consequential damage or injury to any person,
company or other entity.
5. Modification or alteration to any product manufactured by TJM to enable fitment in conjunction with other vehicle accessories or modifications
(e.g. lift kits) will void any warranty claims.
070SB13L69G SHOWN
Bolt tensions
All bolt tensions
are as follows
unless otherwise
pecified.
For further information contact T.J.M. Head Office on (07) 3865 9999. Distributors Australia wide.
File: 88700
FITTING INSTRUCTIONS
Outback & Fleet Frontal Protection System
070SB13L69G
Dia. (mm) Nm
5 5
6 9
8 22
10 44
12 77
Toyota 70 Series 09+
070SB13O69G
Warranty
ft.lbs Dia. (inch)
1/4"
4
5/16"
7
3/8"
16
7/16"
32
1/2"
57
Page 1 of 12
070SB15W69G 070SB15Z69G
Nm ft.lbs
9 7
22 15
33 27
55 43
86 66
22/08/2017
