TJM T15 Fitting Instructions Manual

Product:
Vehicle:
Part No. 070SB15F46E
Australian Standards Relating to Installing Vehicle Frontal Protection Systems (VFPS): AS 4876.1-2002
a) Do not attach V.F.P.S. to vehicle using anchorages not intended for this purpose (e.g. engine mounting bolts), other than those
specified by the V.F.P.S. manufacturer in this instruction.
b) Do not use this product for any vehicle make or model other than those specified by the V.F.P.S. manufacturer (as above).
c) Do not remove any plaques or labels from the V.F.P.S.
d) Do not modify the structure of the V.F.P.S. in any way.
• Read instructions fully before commencing fitment.
• Left hand and Right hand components are determined as seated in the
vehicle.
• Check for (and remove) any build up in all captive nuts fitted to the FPS.
• Be aware that a number of government / fleet departments require that the
tow points be painted red.
• Ensure that the "Rated Recovery Label" is affixed alongside the compliance
label, in the driver's side doorjam.
Bolt tensions
All bolt tensions
are as follows
unless otherwise
specified.
For product warranty please refer to our website www.tjm.com.au
File: F-1833.docx
FITTING INSTRUCTIONS
T15 Fleet & Deluxe Frontal Protection System
070AP15N46E
Dia. (mm)
5
6
8
10
12
Page 1 of 19
Mazda BT50
070AB15N46E
Nm ft.lbs Dia. (inch)
1/4"
5 4
5/16"
9 7
3/8"
22 16
7/16"
44 32
1/2"
77 57
Nm ft.lbs
9 7
22 15
33 27
55 43
86 66
28/10/2021
