TJM 070SB13L32R Fitting Instructions Manual

T13 outback deluxe frontal protection system

Advertisement

Quick Links

Product:
Vehicle:
Part No.
070SB13L32R
Australian Standards Relating to Installing Vehicle Frontal Protection Systems (VFPS): AS 4876.1-2002
a)
Do not attach V.F.P.S. to vehicle using anchorages not intended for this purpose (e.g. engine mounting bolts), other than those
specified by the V.F.P.S. manufacturer in this instruction.
b)
Do not use this product for any vehicle make or model other than those specified by the V.F.P.S. manufacturer (as above).
c)
Do not remove any plaques or labels from the V.F.P.S.
d)
Do not modify the structure of the V.F.P.S. in any way.
• Read instructions fully before commencing fitment.
• Estimated Fitting Time: 4hrs
The fitment of TJM products does not nullify the OE manufacturer's
operating guidelines and/or warnings. Ensure you are familiar with and
adhere to the usage instructions specified by the manufacturer in the
owner's manual or other official
• Left hand and Right hand components are determined as seated in the
vehicle.
• Check for (and remove) any build up in all captive nuts fitted to the FPS.
• When fitting accessories to TJM products (ie. driving lights and aerials),
ensure suitable washer plates are used under the mounting surface that
allow the accessory to be secured in a way that prevents it from damaging
the product.
• When removing protective coatings, ensure all new edges are deburred,
clean any swarf from the area and apply rust preventative to exposed
surfaces.
• Supplementary kit 076SKITA32R is required for fitment of TJM Torq winch.
Bolt tensions
All bolt tensions are
as follows unless
otherwise
specified.
For product warranty, please refer to our website, www.tjm.com.au
File: F-13409
FITTING INSTRUCTIONS
T13 Outback Deluxe Frontal Protection System
Holden Colorado 2016+
Dia. (mm)
5
6
8
10
12
Page 1 of 28
documentation.
Nm
ft.lbs
Dia. (inch)
1/4"
5
4
5/16"
9
7
3/8"
22
16
7/16"
44
32
1/2"
77
57
Nm
ft.lbs
9
7
22
15
33
27
55
43
86
66
28/03/2017
