Super X11SPi-TF User's Manual
Port 60/64 Emulation
This feature allows legacy I/O support for USB devices like mice and keyboards. The options
are Enabled and Disabled.
Server ME Configuration

The following General ME Configuration will display:
•
Oper. Firmware Version
•
Backup Firmware Version
•
Recovery Firmware Version
•
ME Firmware Status #1
•
ME Firmware Status #2
•
Current State
•
Error Code
PCH SATA Configuration

When this submenu is selected, the AMI BIOS automatically detects the presence of the SATA
devices that are supported by the Intel PCH chip and displays the following items:
SATA Controller
This item enables or disables the onboard SATA controller supported by the Intel PCH chip.
The options are Disable and Enable.
Configure SATA as
Select AHCI to configure a SATA drive specified by the user as an AHCI drive. Select RAID
to configure a SATA drive specified by the user as a RAID drive. The options are AHCI and
RAID.
SATA HDD Unlock
This feature allows the user to remove any password-protected SATA disk drives. The options
are Enable and Disable.
Aggressive Link Power Management
When this item is set to Enable, the SATA AHCI controller manages the power usage of the
SATA link. The controller will put the link in a low power mode during extended periods of I/O
inactivity, and will return the link to an active state when I/O activity resumes. The options
are Disable and Enable.
