tGW-700 Series
User Manual
Tiny Modbus/TCP to RTU/ASCII Gateway
W
ARRANTY
All products manufactured by ICP DAS are warranted
against defective materials for a period of one year
from the date of delivery to the original purchaser.
W
ARNING
ICP DAS assumes no liability for damages consequent
to the use of this product. ICP DAS reserves the right to
change this manual at any time without notice. The
information furnished by ICP DAS is believed to be
accurate and reliable. However, no responsibility is
assumed by ICP DAS for its use, nor for any
infringements of patents or other rights of third parties
resulting from its use.
C
OPYRIGHT
Copyright © 2017 by ICP DAS. All rights are reserved.
T
RADEMARKS
Names are used for identification purposes only and
may be registered trademarks of their respective
companies.
C
U
ONTACT
S
If you have any questions, please feel free to contact
us via email at:
service@icpdas.com, service.icpdas@gmail.com
Ver. 2.2, Nov. 2017
S
UPPORT
This manual relates to the following modules:
tGW-712, tGW-722, tGW-732
tGW-715, tGW-725, tGW735
tGW-718, tGW-724, tGW-734
tGW-712i, tGW-722i, tGW-732i
tGW-715i, tGW-725i, tGW735i
tGW-718i, tGW-724i, tGW-734i
tGW-718-D
