ICP DAS USA tET Series Quick Start Manual

Tiny ethernet i/o module
Hide thumbs Also See for tET Series:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
What's in the shipping package?
The package includes the following items:
tET-P2R2 or
tPET-P2R2
Preparations for devices
1. Power Supply:+12 ~ +48 V
2. Ethernet Hub.(PoE Ethernet Switch for tPET module only)
3. Make sure your PC has workable network settings.
4. Disable or well configure your Windows firewall and Anti-Virus
firewall first, else the "Search Servers" on page 5 may not
work. (Please contact with your system Administrator)
For tET-P2R2/tPET-P2R2
English/ December 2010/ Version 1.0
Software CD
DC
tET-P2R2/tPET-P2R2 Quick Start Guide
Quick Start Guide
(This Document)
1

Advertisement

loading

Related Manuals for ICP DAS USA tET Series

Summary of Contents for ICP DAS USA tET Series

  • Page 1 For tET-P2R2/tPET-P2R2 English/ December 2010/ Version 1.0 What’s in the shipping package? The package includes the following items: tET-P2R2 or Quick Start Guide Software CD (This Document) tPET-P2R2 Preparations for devices 1. Power Supply:+12 ~ +48 V 2. Ethernet Hub.(PoE Ethernet Switch for tPET module only) 3.
  • Page 2 Connecting the Power and Host PC 1. Check Init/Normal switch is on “RUN” position. 2. Connect both the tET/tPET-P2R2 and your computer to the same sub network or the same Ethernet Switch, and power tET/tPET-P2R2 on tET-P2R2/tPET-P2R2 Quick Start Guide...
  • Page 3 Pin Assignments and Wiring Note Pin Assignments Terminal Terminal Assignment Assignment F.G. RL1 COM RL1 NO RL0 COM (R) +Vs RL0 NO (B) GND DI.COM Digital Input/Output Wiring tET-P2R2/tPET-P2R2 Quick Start Guide...
  • Page 4 Wire the DI and DO for self test. The wiring as follows: 1. Connect the RL0 COM and DI0. ( Pin09 connect to Pin06) 2. Supply the External Power +10V to RL0 NO. (External +10V connect to Pin08 ) 3. Supply the External Power GND to DI.COM. (External GND connect to Pin05) DI/DO Modbus Address (1xxxx) DI address: Bits per...

  • Page 5: Configuring Ethernet Settings

    Configuring Ethernet Settings 1. Run the eSearch Utility. The eSearch Utility is located at: CD:\Napdos\Software\eSearch\ http://ftp.icpdas.com/pub/cd/tinymodules/napdos/software/esearch/ 2. Click “Search Servers” button to search your tET/tPET-P2R2. 3. Double-Click your tET/tPET-P2R2 to configure the settings. 2. Double-Click your tET/tPET 1. Click “Search Servers” 4.
  • Page 6 Testing your tET/tPET Module 1. Wait 2 seconds and then click the “Search Servers” button again to ensure the tET/tPET-P2R2 is working well with new configuration. 2. Click the “Web” button to link the tET/tPET-P2R2 web server. 1. Click your tET/tPET on the list Click 2.
  • Page 7 4. Control the I/O for simple test. I/O Setting page, check the “bit0” checkbox for setting In the “Update Settings” button. and click Home In the page, check that the status should show current status are “ON”. tET-P2R2/tPET-P2R2 Quick Start Guide...

  • Page 8: Related Information

    Related Information tET-P2R2/tPET-P2R2 Series Product Page: http://www.icpdas.com/products/ Remote_IO/PETL7000/tPET-P2POR2.htm tET/tPET Series Documentations: CD:\Napdos\tPET\document\ http://ftp.icpdas.com/pub/cd/tinymodules/napdos/tPET/document/ tET/tPET Series Firmware: CD:\ Napdos\tPET\firmware\ http://ftp.icpdas.com/pub/cd/tinymodules/napdos/tPET/firmware/ NS-205, NS-205PES Product Page (optional): http://www.icpdas.com/products/Switch/industrial/ns-205.htm http://www.icpdas.com/products/Switch/industrial/ns-205pse.htm ICP DAS Web Site: http://www.icpdas.com Contact Us (E-Mail): service@icpdas.com , service.icpdas@gmail.com Copyright @ 2010 by ICP DAS Co., Ltd. All Rights Reserved.
