Quick Guide for the V-Tap ISDN PRI
A connection between the V-Tap and PC software (or Apresa) is needed to get the recorded data
automatically into a user accessible database.
The following checklist can be used to setup this Tunnel connection:
1) Install the Hardware (see page 2).
2) Install the PC Software and enable V-Tap connections (see page 3).
3) Assign an IP address to the V-Tap and open the Settings page (see page 2).
4) The "Tunnel Server Address" must be filled in with the IP address or name of the PC.
must be setup to let pass TCP port 2016, the default "Tunnel Destination Port".
5) Any firewall
6) The Tunnel connection to the PC is stable when the
7) For first tests, better turn off "Tunnel Data Encryption". Otherwise, be sure that the
Encryption password is the same for both V-Tap and Tunnel server.
8) When data is stored during a call then the
9) To see if the PC receives something from the V-Tap, it is possible to make a network trace
for test purposes. On the PC go to menu Action and select 'Network trace'.
The 'tunneltrace.pcap' file can be read afterwards with Wireshark.
10) The SD card in the V-Tap should contain ".WAV" files.
The SD card can be read by the PC software in menu File and 'Import from V-Tap'.
V1.1

CHECKLIST FOR TUNNEL CONNECTION

BLUE LED
© 2018 Vidicode
GREEN LED is steady, not blinking!
blinks.
4
