3�3�2�- MODEL CVM-C5-xxx-485-I
10
Table 3:List of CVM-C5-xxx-485-I terminals�
1 :AuxiliaryPowerSupply
2:AuxiliaryPowerSupply
3: Digitalinput
4: Digitalinput
5: A(+),RS485
6: B(-),RS485
7: GND,forRS485
8: V , L1voltageinput
L1
9: V ,L2voltageinput
L2
1 2
POWER SUPPLY
Ph-Ph
520V ~
V
V
L1 L2
8
9 10
Figure 2: CVM-C5-xxx-485-I terminals�
Device terminals
10: V , L3voltageinput
L3
11: N, neutral
12: S ,L1currentinput
1
13: S , L1currentinput
2
14: S , L1currentinput
2
15: S , L2currentinput
2
16: S , L3currentinput
1
17: S , L3currentinput
2
3 4
INPUT
RS485
A B GND
(+) (-)
Ph-N
300V ~
P1 P2 P1 P2 P1
L1 L2 L3
V N
L3
S1 S2 S1 S2 S1 S2
11 12 13 14
CVM-C5-xxx-485
5
6 7
P2
15 16 17
