Inputs
CAN Bus
VCI CAN Input
CAN Bus Outputs
Bit rate
Identifier type
Data available
Power
Input Voltage range
Current
Environmental and physical
Weight
Size
Operating temperature
Storage temperature
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Micro/VBOX_Micro_User_Guide/12_-
CAN connection for Racelogic modules only
Allows the user to log up to 16 channels of
incoming CAN data from other systems
125, 250, 500 kbit/s and 1 Mbit/s selectable baud rate
Standard 11 bit and Extended 29 bit 2.0 A
Satellites, UTC time, Latitude, Longitude, Speed,
Heading, Altitude, Vertical velocity, Longitudinal and
Lateral acceleration, Distance since reset
6 – 30 V DC
Typically 70 mA
Approx 275 g
105 mm x 85 mm x 30 mm
-10˚C to +60˚C
-40˚C to +85˚C
