Racelogic VBOX Micro User Manual page 28

Hide thumbs Also See for VBOX Micro:
Table of Contents

Advertisement

Connector 2 - COMS (Fischer 5 PIN)
PIN
1
2
3
4
5
I/O
I/O
O
I
I/O
I/O
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Micro/VBOX_Micro_User_Guide/10_-
Function
Power
RS232 Tx
RS232 Rx
CAN High
CAN Low
_VBOX_Micro_PIN_OUTS
28
