Connector 1 - POWER (Fischer 2 PIN)

PIN

1

2

I/O

I

I

https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Micro/VBOX_Micro_User_Guide/10_-

Function

Power+

Ground

Range

6 – 30 V

0 V

_VBOX_Micro_PIN_OUTS
