Connector 3 - ANTENNA (SMA)
PIN
Center
Chassis
Name
-
-
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Micro/VBOX_Micro_User_Guide/10_-
Function
RF Signal / Power for active
antenna
Ground
_VBOX_Micro_PIN_OUTS
29
