Tenda I-WL-D305 User Manual

4 antennas wireless n300 adsl2+ modem router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Copyright Statement
© 2015 Shenzhen Tenda Technology Co., Ltd. All rights reserved.
Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and product names
mentioned herein are trademarks or registered trademarks of their respective holders. Copyright of the whole product as
integration, including its accessories and software, belongs to Shenzhen Tenda Technology Co., Ltd. No part of this
publication can be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in
any form or by any means without the prior written permission of Shenzhen Tenda Technology Co., Ltd.
Disclaimer
Pictures, images and product specifications herein are for references only. To improve internal design, operational
function, and/or reliability, Tenda reserves the right to make changes to the products without obligation to notify any
person or organization of such revisions or changes. Tenda does not assume any liability that may occur due to the use or
application of the product described herein. Every effort has been made in the preparation of this document to ensure
accuracy of the contents, but all statements, information and recommendations in this document do not constitute the
warranty of any kind, express or implied.
Technical Support
Technical Support: support@tenda.com.cn
Telephone: (86 755) 2765 7180
Email: sales@tenda.com.cn
Website: http://www.tendacn.com
Skype: tendasz
YouTube: Tendasz1999
i

Advertisement

Table of Contents
loading

Related Manuals for Tenda I-WL-D305

Summary of Contents for Tenda I-WL-D305

  • Page 1 Tenda reserves the right to make changes to the products without obligation to notify any person or organization of such revisions or changes. Tenda does not assume any liability that may occur due to the use or application of the product described herein.
  • Page 2 Tenda reserves the right to make changes to the products without obligation to notify any person or organization of such revisions or changes. Tenda does not assume any liability that may occur due to the use or application of the product described herein.

  • Page 3: Table Of Contents

    Contents Shortcut to Common Function Setup ............................v Chapter 1 Product Overview ............................... 1 1.1 What It Does ..................................1 1.2 Product Features ................................... 1 1.3 Package Contents ................................. 2 1.4 Front Panel ................................... 3 1.5 Back Panel.................................... 4 Chapter 2 Hardware Installation ..............................5 2.1 DSL Access ..................................
  • Page 4 4.4.1 Diagnostics ................................126 4.4.2 Ping test ..................................126 4.5 Management ..................................127 4.5.1 Settings ..................................127 4.5.2 System Logs ................................128 4.5.3 SNMP Agent ................................129 4.5.4 TR-069 Client ................................130 4.5.5 Internet Time ................................131 4.5.6 Access Control ................................132 4.5.7 Update Software ................................

  • Page 5: Shortcut To Common Function Setup

    How to expand your wireless network coverage? How to make your set-top box available? How to reset the modem router to factory defaults? © 2015 Shenzhen Tenda Technology Co., Ltd. All rights reserved. Technical Support: support@tenda.com.cn Telephone: (86 755) 2765 7180 Email: sales@tenda.com.cn...

  • Page 6: Chapter 1 Product Overview

    Chapter 1 Product Overview Get to know your modem router overall. This part includes the following: 1.1 What It Does 1.2 Product Features 1.3 Package Contents 1.4 Front Panel 1.5 Back Panel 1.1 What It Does The Wireless ADSL2+ Modem Router, integrated with functions of ADSL2+ modem and wireless router, is especially designed for ordinary home users.

  • Page 7: Package Contents

    Other Advanced Features: IPv6, DDNS, virtual server, DMZ, port triggering, IP filter, MAC filter and UPnP, etc. Tenda Green: Equipped with hardware buttons Power On/Off and WiFi On/Off. You can conveniently turn on or off power and WiFi to save energy when not in use 1.3 Package Contents...

  • Page 8: Front Panel

    1.4 Front Panel The LEDs on the device are described below: Item Name Status Description Solid Power electricity is provided to the device properly. Power is off. Solid/Off The system is malfunctioning. Blinking The system works properly. Solid The device is connected to the Internet properly. Transmitting Internet data…...

  • Page 9: Back Panel

    1.5 Back Panel Item Name Description RJ11 port. Connect the telephone line from ISP to this port for DSL service connection. LAN port or WAN port. When you access the Internet via the DSL, this port works as a LAN port which can be used to connect to a PC, switch, or a router;...

  • Page 10: Chapter 2 Hardware Installation

    Chapter 2 Hardware Installation Before you start to cable the modem router, you should figure out your Internet access type. Cable you modem router correctly, and make sure it works well. It supports two types of access, DSL access and Ethernet access. Choose your access type and cable your device and modem router.
  • Page 11 ③ Connect your computer to the LAN port of the modem router. The overall diagram of DSL Access is shown below: _________________________________________________________________________________________________ 1. Before connecting, make sure the Internet service is available. 2. ADSL splitter is used to make you active in phone service and Internet service simultaneously. If you don’t need the telephone service, just connect the telephone line from your ISP to the DSL port.

  • Page 12: Ethernet Access

    2.2 Ethernet Access  ①→②→③. Ethernet access cabling is detailed below. Cable the modem router and your computer following the steps Note that you may get to the Internet via a modem or an Ethernet cable directly, choose your access type correctly and follow the diagram.
  • Page 13 The overall diagram of Ethernet Access is shown below: _________________________________________________________________________________________________ 1. Before connecting, make sure the Internet service is available. 2. Disconnect the modem router from WAN or DSL connection, and unplug it from the power when it is thunderstorm. _________________________________________________________________________________________________...

  • Page 14: Chapter 3 Internet Setup

    Chapter 3 Internet Setup Internet setups are detailed in this part, which include connection types, link types and wireless security setup, etc. This part includes the following: 3.1 Log in to UI 3.2 Set up Internet 3.3 Quick Wireless Security Setup 3.1 Log in to UI (User Interface) To configure the parameters of the modem router, you should log in to its UI (User Interface) first.

  • Page 15: Set Up Internet

    3.2 Set up Internet The device supports auto-detecting link type and PVC, which can help you configure the device easily and quickly. If you do want to configure the details, take below for references. About Link Type Link type includes three options: Auto, DSL and Ethernet. Auto is recommended to you if you cannot figure out which type your Internet access is.

  • Page 16: Internet Setup Instruction

    Internet Setup Instruction access  PPPoE ① Select Auto or DSL link type and select PPPoE connection type. (Note that Auto mode only supports two ② connection types: PPPoE and IPoE.) Check Auto PVC scan. If the scan failed, uncheck this option and configure the PVC and country settings ③...
  • Page 17  PPPoA ① Select Auto or DSL link type and select PPPoA connection type. (Note that Auto mode only supports two ② connection types: PPPoE and IPoE.) Configure the PVC, ISP and country settings manually. Click here to check PVC value or consult your ISP if ③...
  • Page 18  IPoE ① ② Select Auto or DSL link type and select IPoE connection type. Check Auto PVC scan. If the scan failed, uncheck this option and configure the PVC and country settings ③ manually. Click here to check PVC value or consult your ISP if you cannot locate this info. Select your address mode (Dynamic IP or Static IP).
  • Page 19  IPoA ① ② Select Auto or DSL link type and select IPoA connection type. Configure the PVC, ISP and country settings manually. Click here to check PVC value or consult your ISP if ③ you cannot locate this info. (Note that Auto PVC scan is not available for IPoA.) ④...
  • Page 20  Bridge ① ② Select Auto or DSL link type and select Bridge connection type. Configure the PVC, ISP and country settings manually. Click here to check PVC value or consult your ISP if ③ you cannot locate this info. (Note that Auto PVC scan is not available for Bridge.) ④...
  • Page 21 Ethernet access  PPPoE ① ② Select Auto or Ethernet link type and select PPPoE connection type. ③ Type the user name and password of PPPoE provided by your ISP. ④ Finish the wireless setup. (Recommended) Click OK.  IPoE ①...
  • Page 22 ③  Static IP requires a group of IP info provided by your ISP. Type them in the corresponding field. ④ Finish the wireless setup. (Recommended) Click OK.  Bridge ① ② Link Type: Select Auto or Ethernet. ③ Select Bridge connection type. ④...

  • Page 23: Quick Wireless Security Setup

    3.3 Quick Wireless Security Setup On Home Page, you can set up the basic wireless parameters, like wireless SSID, wireless key and RF Power (namely signal strength). Also, you can disable or enable wireless feature here. After you have finished settings, click to save and apply them.

  • Page 24: Chapter 4 Advanced Settings

    Chapter 4 Advanced Settings This chapter describes the advanced features of your modem router. The information is for users with a solid understanding of networking concepts who want to configure the router for unique situations. This part includes the following: 4.1 Device Info 4.2 Advanced Setup 4.3 Wireless...
  • Page 25 Here you can view the WAN Information including Interface, Description, Type, IGMP, NAT, Firewall, Status, IPv4 Address and VLAN ID as seen in the screenshot. Statistics Here you can view the packets received and transmitted on LAN/WAN ports. Statistics--LAN: Displays the packets received and transmitted on the LAN ports as seen in the screenshot below. _________________________________________________________________________________________________ 2.4GHz interface represents data transmitted and received via wireless.
  • Page 26 Statistics--WAN: Displays the packets received and transmitted on the WAN ports as seen in the screenshot below. Statistics-ADSL: Displays the DSL port status e.g., packets received and transmitted on the DSL port. Route Here you can view the route table as seen in the screenshot:...

  • Page 27: Advanced Setup

    Here you can view the IP and MAC addresses of the PCs that attach to the device either via a wired or wireless connection as seen in the screenshot: DHCP Here you can view the DHCP leases, including IP and MAC addresses of the PCs, hostnames and remaining lease time as seen in the screenshot.

  • Page 28: Layer2 Interface

    4.2.1 Layer2 Interface Click Advanced Setup > Layer2 Interface to enter the Layer2 Interface screen. This router provides two kinds of Layer2 Interface: - ATM Interface for ADSL broadband Internet service - ETH Interface for connecting to the Internet via an Ethernet cable. By default, system applies the ATM Interface (ADSL uplink).
  • Page 29 Enter the VPI and VCI values, select a DSL Link Type (Internet connection type): EoA (EoA is for PPPoE, IPoE, and Bridge.), PPPoA or IPoA. Leave other options unchanged from factory defaults and click and then refer to To Set up WAN Service for ATM Interface to configure the WAN service for Internet access.

  • Page 30: Wan Service

    Eth0 is 1/WAN port on the back of the device. It is to function as a WAN port here. After you finish your settings, click and then refer to To Set up WAN Service for ETH Interface to configure the WAN service for Internet access.
  • Page 31 PPPoE IPv4 Only Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ATM interface you added just now from the pull-down menu in the figure below. Click Next. Step 3: Select PPP over Ethernet (PPPoE). Edit the Enter Service Description field which is optional. Suggest you keep the default.
  • Page 32 Step 4: Finish PPP Username and Password and other settings on the figure below. Click Next. PPP Username/Password: For logging in to your ISP. If you cannot locate this information, ask your ISP to provide it. PPPoE Service Name: Provided by your ISP. Only enter it if instructed by your ISP. Authentication Method: Used by ISP to authenticate the client that attempts to connect.
  • Page 33 a network can transmit. Any messages larger than the MTU are divided into smaller packets before being sent. The default MTU is 1460 bytes. For some ISPs, you might need to change the MTU. This is rarely required, and should not be done unless you are sure it is necessary for your ISP connection.
  • Page 34 Step 7: Here you can view your configurations. Click Apply/Save to save your settings if everything is correctly set. When the PPPoE connection is successful, you can access the Internet. IPv4 & IPv6 (Dual Stack) Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ATM interface you added just now from the pull-down menu in the figure below.
  • Page 35 Step 3: Select PPP over Ethernet (PPPoE). Edit the Enter Service Description field which is optional. Suggest you keep the default. Select a network protocol: IPv4&IPv6 (Dual Stack). Click Next. Step 4: Configure PPP Username and Password and other settings on the figure below. Each field with its indication is mentioned above in IPv4 Only (PPPoE) section.
  • Page 36 IP address by checking Use Static IPv6 Address and enter the static IPv6 address. Step 5: To configure the Default Gateway interface when using IPv6, select the interface that you want to configure with the WAN gateway address in Selected WAN Interface box. Then click Next. Step 6: To configure the WAN DNS address, check the Obtain IPv6 DNS info from a WAN interface option, or select the Use the following Static IPv6 DNS address option to enter the static DNS server IPv6 addresses provided by your ISP.
  • Page 37  When the PPPoE connection is successful, you can access the Internet. IPv6 Only Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ATM interface you added just now from the pull-down menu in the figure below. Click Next.
  • Page 38 Step 3: Select PPP over Ethernet (PPPoE). Edit the Enter Service Description field which is optional. Suggest you keep the default. Select a network protocol you need: IPv6 Only. Click Next. Step 4: Configure PPP Username and Password and other settings on the figure below. Each field with its indication is mentioned above in IPv4 Only (PPPoE) section.
  • Page 39 If ISP provides you with the static IPv6 address, configure a static IP address by checking Use Static IPv6 Address and enter the static IPv6 address. Step 5: To configure the Default Gateway interface when using IPv6, select the interface that you want to configure with the WAN gateway address in Selected WAN Interface box.
  • Page 40  When the PPPoE connection is successful, you can access the Internet. IPoE IPv4 Only If you get an IP address from your ISP automatically or if your ISP assigns you a static (fixed) IP address, subnet mask and gateway, you need to select the IP over Ethernet (IPoE). Step 1: Click Advanced Setup >...
  • Page 41 Step 3: Select IP over Ethernet. Edit the Enter Service Description which is optional. Suggest you keep the default. Select a network protocol: IPv4 Only. Click Next. Step 4: Finish WAN IP Settings on the figure below. Click Next.
  • Page 42 Obtain an IP address automatically: This allows the router to automatically acquire IP information from your ISP or your existing networking equipment. Use the following Static IP address: This allows you to specify the Static IP information provided by your ISP or that corresponds with your existing networking equipment.
  • Page 43 Step 7: To finish DNS Server Configuration, click the Select DNS Server Interface from available WAN interfaces option, or select the Use the following Static DNS IP address option and enter the static DNS server IP addresses provided by your ISP. At last, click Next. ...
  • Page 44 IPv4 & IPv6 (Dual Stack) Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ATM interface you added just now from the pull-down menu in the figure below. Click Next. Step 3: Select IP over Ethernet. Edit the Enter Service Description which is optional. Suggest you keep the default. Select a network protocol: IPv4&IPv6 (Dual Stack).
  • Page 45 Step 4: To finish WAN IP Settings, select Obtain an IPv6 address automatically, check Dhcpv6 Prefix Delegation (IAPD). If your ISP is using stateful DHCPv6, check Dhcpv6 Address Assignment (IANA) also. Or select Use the following Static IP address if your ISP provides you with an IPv6 address. Click Next. If ISP provides you with the static IPv6 address, configure a static IP address by checking Use the following Static IPv6 address and enter the static IPv6 address.
  • Page 46 Step 5: Configure NAT settings. If you are unsure about the options, please keep the default settings and then click Next. Step 6: To configure the Default Gateway interface, select the interface that you want to configure with the WAN gateway address in Available Routed WAN Interfaces box and move it into Selected Default Gateway Interfaces box.
  • Page 47 Step 8: Here you can view your configurations. Click Apply/Save to save your settings if everything is correctly set. When the IPoE connection is successful, you can access the Internet. IPv6 Only Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ATM interface you added just now from the pull-down menu in the figure below.
  • Page 48 Step 3: Select IP over Ethernet (IPoE). Edit the Enter Service Description field which is optional. Suggest you keep the default. Select a network protocol you need: IPv6 Only. Click Next. Step 4: Enter the WAN information provided by your ISP to configure the WAN IPv6 settings. To obtain an IP address automatically: Select Obtain an IPv6 address automatically.
  • Page 49 Step 5: Finish Network Address Translation Settings. Suggest keep the default settings. Click Next. Step 6: To configure the Default Gateway interface when using IPv6, select the interface that you want to configure with the WAN gateway address in Selected WAN Interface box. Then click Next. Step 7: To configure the WAN DNS address, check the Obtain IPv6 DNS info from a WAN interface option, or select the Use the following Static IPv6 DNS address option to enter the static DNS server IPv6 addresses provided by your ISP.
  • Page 50 Step 8: Here you can view your configurations. Click Apply/Save to have this interface to be effective. When the IPoE connection is successful, you can access the Internet. Bridge If you wish to initiate a dialup directly from your PC for Internet access or enjoy the entire Internet connection (instead of sharing it with others), you can use the Bridging DSL link type and create a dialup program on your PC.
  • Page 51 Step 3: Select Bridging. Edit the Enter Service Description which is optional. Suggest you keep the default. Click Next. Step 4: Here you can view your configurations. Click Apply/Save to activate your settings..
  • Page 52 After the bridging connection is successful, initiate a dialup directly from your PC for Internet access. NOTE To configure multiple WAN connections, simply configure multiple ATM interfaces and then follow the instructions above.  PPPoA If you have selected the PPPoA from the ATM Interface screen in Layer2 Interface, you will see the screen below when you click the WAN Service tab, select the configured interface and click Next.
  • Page 53 Step 4: Enter PPP username and its password provided by your ISP. Click Next. PPP Username: This is for logging in to your ISP. If you cannot locate this information, ask your ISP to provide it. PPP Password: This is for logging in to your ISP. If you cannot locate this information, ask your ISP to provide it. Authentication Method: This is used by ISP to authenticate the client that attempts to connect.
  • Page 54 Step 5: To configure the WAN gateway address. After you configure it click Next. The default setting is recommended. Step 6: To configure the WAN DNS address. Choose a way to get DNS server according to what your ISP has provided. -Click the Select DNS Server Interface from available WAN interfaces option.
  • Page 55 Step 7: Here you can view your configurations. Click Apply/Save to have this interface to be effective. Step 8: When the PPPoA connection is successful, you can access the Internet. IPv4 & IPv6 (Dual Stack) Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ATM interface you added just now from the pull-down menu in the figure below.
  • Page 56 Step 3: Edit the Enter Service Description. This field is optional. We recommend that you keep the default. Select a network protocol: IPv4 & IPv6 (Dual Stack). Click Next. Step 4: Enter PPP username and its password provided by your ISP. Click Next. Step 5: To configure the WAN gateway address.
  • Page 57 NOTE Default gateway interface list can have multiple WAN interfaces served as system default gateways but only one will be used according to the priority with the first being the highest and the last one the lowest priority if the WAN interface is connected.
  • Page 58 Step 7: Here you can view your configurations. Click Apply/Save to save your settings if everything is correctly set. Step 8: When the PPPoA connection is successful, you can access the Internet. IPv6 Only Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ATM interface you added just now from the pull-down menu in the figure below.
  • Page 59 Step 3: Edit the Enter Service Description. This field is optional. We recommend that you keep the default. Select a network protocol: IPv6 Only. Click Next. Step 4: Enter PPP username and its password provided by your ISP. Click Next. Step 5: Select a preferred wan interface as the system default IPv6 gateway.
  • Page 60 Step 6: To configure the WAN DNS address, select the configured WAN interface for IPv6 DNS server information or enter the static IPv6 DNS server addresses. And then click Next. NOTE Selecting a WAN interface for IPv6 DNS server will enable DHCPv6 Client on that interface. Step 7: Here you can view your configurations.
  • Page 61  IPoA Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ATM interface you added just now from the pull-down menu in the figure below. Click Next. Step 3: Edit the Enter Service Description. This field is optional. It is recommended that you keep the default. Click Next.
  • Page 62 WAN IP Address: The Internet IP address provided by your ISP for accessing the Internet. WAN Subnet Mask: The subnet mask address provided by your ISP for accessing the Internet. Step 5: Keep the defaults if you are unsure about the options on the screen below and click Next. Step 6: To configure the WAN gateway address.
  • Page 63 Step 8: Here you can view your configurations. Click Apply/Save to save your settings if everything is correctly set. Step 9: IPoA WAN service setup parameter is shown as below.
  • Page 64 To Set up WAN Service for ETH Interface Three Internet connections: PPP over Ethernet (PPPoE), IP over Ethernet (IPoE) and Bridging are available in the Ethernet uplink mode. If you selected and configured the ETH Interface (Ethernet uplink), follow steps below to configure the WAN service: ...
  • Page 65 Step 4: Enter the PPP username and password provided by your ISP. If you are not sure about other options, just leave them unchanged from defaults. And click Next. PPP Username: This is for logging in to your ISP. If you cannot locate this information, ask your ISP to provide it. PPP Password: This is for logging in to your ISP.
  • Page 66 egress the WAN port without modification. Multicast Proxy: If enabled, the router will use multicast proxy. Step 5: Configure the WAN gateway address. After you configure it click Next. The default setting is recommended. Step 6: Configure the WAN DNS address according to your ISP. -Click the Select DNS Server Interface from available WAN interfaces option;...
  • Page 67 When the PPPoE connection is successful, you can access the Internet. IPv4 & IPv6 (Dual Stack) Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ETH interface you added just now from the pull-down menu in the figure below. Click Next.
  • Page 68 Step 3: Select PPP over Ethernet. Edit the Enter Service Description. This field is optional. It is recommended that you keep the default. Select a network protocol: IPv4&IPv6 (Dual Stack). And click Next. Step 4: Enter PPP username and PPP password provided by your ISP. Check Launch Dhcp6c for Prefix Delegation (IAPD).
  • Page 69 Step 5: Select an available WAN interface as the system default gateway. Then click Next. Step 6: Configure DNS server (Select an available DNS server interface or use a specified DNS server); configure IPv6 DNS server (Obtain IPv6 DNS info from a WAN interface or use a specified DNS server), and then click Next. Step 7: Here you can view your configurations.
  • Page 70 When the PPPoE connection is successful, you can access the Internet. IPv6 Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ETH interface you added just now from the pull-down menu in the figure below. Click Next. Step 3: Select PPP over Ethernet.
  • Page 71 Step 4: Enter PPP username and PPP password provided by your ISP. Check Launch Dhcp6c for Prefix Delegation (IAPD). If your ISP is using stateful DHCPv6, check Launch Dhcp6c for Address Assignment (IANA) also. Or configure a static IP address. Step 5: Select a preferred WAN interface from the WAN interface list as the system default IPv6 gateway.
  • Page 72 Step 7: Here you can view your configurations. Click Apply/Save to save your settings if everything is correctly set. When the PPPoE connection is successful, you can access the Internet.
  • Page 73  IP over Ethernet (IPoE) If you get an IP address from your ISP automatically or if your ISP assigns you a static (fixed) IP address, subnet mask and gateway, you need to select the IP over Ethernet (IPoE). IPv4 Step 1: Click Advanced Setup >...
  • Page 74 Step 4: Enter the IP address/subnet mask/gateway IP address provided by your ISP or select Obtain an IP address automatically and then click the Next button. Obtain an IP address automatically: This allows the router to automatically acquire IP information from your ISP or your existing networking equipment.
  • Page 75 Step 6: Here you can configure the WAN gateway address. After you configure it click Next. The default setting is recommended. Step 7: Here you can configure the WAN DNS address. -Click the Select DNS Server Interface from available WAN interfaces option; -Or select the Use the following Static DNS IP address option and enter static DNS server IP addresses for the system.
  • Page 76 When the IPoE connection is successful, you can access the Internet. IPv4 & IPv6 (Dual Stack) Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ETH interface you added just now from the pull-down menu in the figure below. Click Next. Step 3: Select IP over Ethernet as WAN service type.
  • Page 77 Step 4: Enter information provided by your ISP to configure the WAN IP settings.
  • Page 78 Step 5: Here you can configure the NAT. If you are not an advanced user, the default settings are recommended and then click Next. Step 6: Configure a WAN interface as the default gateway. Step 7: Configure DNS server (Select an available DNS server interface or use a specified DNS server); configure IPv6 DNS server (Obtain IPv6 DNS info from a WAN interface or use a specified DNS server), and then click Next.
  • Page 79 Step 8: Here you can view your configurations. Click Apply/Save to save your settings if everything is correctly set. When the IPoE connection is successful, you can access the Internet. IPv6 Step 1: Click Advanced Setup > WAN Service and then click the Add button. Step 2: Select the ETH interface you added just now from the pull-down menu in the figure below.
  • Page 80 Step 3: Select IP over Ethernet as WAN service type. Edit the Enter Service Description. This field is optional. We recommend that you keep the default. Select a network protocol: IPv6 Only. And then click Next. Step 4: Enter the WAN information provided by your ISP to configure the WAN IPv6 settings. To obtain an IP address automatically: Select Obtain an IPv6 address automatically and Check Dhcp6c Prefix Delegation (IAPD).
  • Page 81 Step 5: Here you can configure the NAT. If you are not an advanced user, the default settings are recommended and then click Next. Step 6: To configure the Default Gateway interface when using IPv6, select the interface that you want to configure with the WAN gateway address in Selected WAN Interface box.
  • Page 82 Step 8: Here you can view your configurations. Click Apply/Save to save your settings if everything is correctly set. When the IPoE connection is successful, you can access the Internet.  Bridging If you wish to initiate a dialup directly from your PC for Internet access or enjoy the entire Internet connection (instead of sharing it with others), you can select the Bridging and create a dialup program from your PC.
  • Page 83 default. And click Next. Step 4: Here you can view your configurations. Click Apply/Save to save your settings if everything is correctly set. After the bridging connection is successful, initiate a dialup directly from your PC for Internet access.

  • Page 84: Lan Setup

    4.2.3 LAN Setup Here you can configure the LAN IP Address and subnet mask. This IP address is to be used to access the device’s settings through a web browser. Be sure to make a note of any changes you apply to this page. This part includes the following information: ...
  • Page 85 Leased Time: The lease time is a time length that the IP address is assigned to each device before it is refreshed. Static IP Lease List: Displays a list of devices with reserved static IP addresses. Add Entries: Click to add a static IP lease entry. A maximum 32 entries can be configured. Remove Entries: Click to remove a static IP lease entry.
  • Page 86  IPv6 LAN Applications Enable DHCPv6 Server：Check to enable the DHCPv6 Server. Stateless: If selected, IPv6 clients will generate IPv6 addresses automatically based on the Prefix Delegation's IPv6 prefix and their own MAC addresses. Stateful: Stateful DHCPv6 is supported based on the assumption of prefix length less than 64. Select this option and configure the start/end interface ID and leased time.

  • Page 87: Nat

    4.2.4 NAT This section explains the following: • Virtual Server • Port Triggering • DMZ Host • UPnP Virtual Server The Virtual Server is useful for web servers, ftp servers, e-mail servers, gaming and other specialized Internet applications. When you enable the Virtual Server, the communication requests from the Internet to your router’s WAN port will be forwarded to the specified LAN IP address.
  • Page 88 ports at the Internet interface. Protocol: Select the protocol from the Protocol drop-down list. If you are unsure, select TCP/UDP. Internal Starting Port and Internal Ending Port: These are the starting number and ending number for the ports of a computer on the router’s local area network (LAN).
  • Page 89 To configure your router to make your local web server public: Procedure 1. Click NAT > Virtual Server to enter it and then click the Add button. 2. Select Web Server (HTTP) that you wish to host on your network from the Select a Service drop-down list. The port number (8080) used by this service will then be automatically populated.
  • Page 90 Port Triggering Some applications such as games, video conferencing, remote access applications and others require that specific ports in the Router's firewall be opened for access by the applications. Port Trigger dynamically opens up the 'Open Ports' in the firewall when an application on the LAN initiates a TCP/UDP connection to a remote party using the 'Triggering Ports'. The Router allows the remote party from the WAN side to establish new connections back to the application on the LAN side using the 'Open Ports'.
  • Page 91 automatically opened by the built-in firewall when connections initiated by an application are established. DMZ Host The default DMZ (De-Militarized Zone) host feature is helpful when you are using some online games and videoconferencing applications that are not compatible with NAT (Network Address Translation). DMZ Host IP Address: The IP Address of the device for which the router’s firewall will be disabled.

  • Page 92: Security

    Enable UPnP: Check/uncheck to enable/disable the UPnP feature. _________________________________________________________________________________________________ NOTE UPnP is activated only when there is a live WAN service with NAT enabled. _________________________________________________________________________________________________ 4.2.5 Security This section explains the following information: • IP Filtering • MAC Filtering IP Filtering Outgoing IP Filtering Setup By default, all outgoing IP traffic from LAN is allowed, but some IP traffic can be BLOCKED...
  • Page 93 This screen allows you to create a filter rule to identify outgoing IP traffic by specifying a new filter name and at least one condition below. All of the specified conditions in this filter rule must be satisfied for the rule to take effect. Click to save and activate the filter.
  • Page 94 Click Add to enter the following screen: This screen allows you to create a filter rule to identify incoming IP traffic by specifying a new filter name and at least one condition below. All of the specified conditions in this filter rule must be satisfied for the rule to take effect. Click to save and activate the filter.

  • Page 95: Parental Control

    _________________________________________________________________________________________________ Warning! Changing from one policy to another of an interface will cause all defined rules for that interface to be REMOVED AUTOMATICALLY! You will need to create new rules for the new policy. _________________________________________________________________________________________________ Click Add to enter the following screen: Here you can create a filter to identify the MAC layer frames by specifying at least one condition below.
  • Page 96 • Time Restriction • URL Filter Time Restriction Click Parental Control > Time Restriction > Add to enter the following screen. Here you can add time of day restriction that an attached LAN device can access the Internet. The Browser's MAC Address automatically displays the MAC address of the LAN device where the browser is running. To restrict other LAN device, check the "Other MAC Address"...
  • Page 97 Select the URL List Type (Exclude or Include) first and then click Add to enter the screen below for configuring the list entries. URL Address: Enter a specific URL or a key word of domain name in this field. Click to apply and save the settings.

  • Page 98: Bandwidth Control

    2. Then type ipconfig /flushdns and hit Enter on the keyboard. _________________________________________________________________________________________________ 4.2.7 Bandwidth Control When multiple devices each of which requests a different bandwidth attach to the modem router, to ensure the attached devices obtaining a fair bandwidth and getting a fluent Internet experience, set a bandwidth control rule. Check Enable Bandwidth Control to enable this feature.

  • Page 99: Routing

    Description: Name the bandwidth control rule as you like. IP Address Range: Type the IP address range of target hosts. Follow the example If you want to set one host, follow the example Max Upstream Speed (Kbps): Set the upstream speed as your actual bandwidth need. Max Downstream Speed (Kbps): Set the downstream speed as your actual bandwidth need.
  • Page 100  Available Routed WAN Interfaces: Displays the available routed WAN interfaces. Select a WAN interface and click the button to add it to the Selected Default Gateway Interfaces box.  Apply/Save: Click to save and activate your settings. Static Route Static routes provide additional routing information to your router.

  • Page 101: Dns

    router.  Metric: Enter a number in the Metric field. This stands for the number of routers between your network and the destination.  Apply /Save: Click to apply and save your settings. _________________________________________________________________________________________________ NOTE 1. Destination IP address cannot be on the same IP segment as WAN or LAN segment as the router. 2.
  • Page 102 ② Check the Select DNS Server Interface from available WAN interfaces option if the device gets a DNS address automatically from an upstream device. Or select the Use the following Static DNS IP address option and enter static DNS server address provided by your ISP. ③...
  • Page 103 Username: Enter the DDNS user name registered with your DDNS service provider. Password: Enter the DDNS Password registered with your DDNS service provider. Click to save your settings. Example: dyn.com Hostname: tenda.dyndns.org Username: tenda Password: 123456789 ① Add Dynamic DNS...

  • Page 104: Dsl

    ② Enter the hostname. Here is “tenda.dyndns.org” for example. ③ Specify a WAN connection interface. ④ DynDNS Settings Enter your DynDNS username. Here is “tenda” ⑤ for example. Enter the password of DynDNS account. Here is “123456789” for example. ⑥...

  • Page 105: Storage Service

    Check the checkbox next to a modulation to enable it and then click Advanced Settings: Click it to enter the Advanced Settings screen as below. Here you can select the test mode and tone. _________________________________________________________________________________________________ If you are unsure about the DSL parameters, please apply the factory default settings. Wrong configurations may fail your Internet access.
  • Page 106 Click and then uplug your USB device. Removing directly may damage your USB storage device. User Account Accessing the USB storage device requires an account. You can click to use the default account or you can customize a new one. Pay attention to that your computer system will record the account you used at the first time. Application: How to access the USB storage device attached to the modem router? Step 1: Plug USB storage device.
  • Page 107 to save and apply. Step 3: Access the USB storage device from a computer. Click +R on the keyboard to pop up the Run dialog, and type \\192.168.1.1 in the blank field. Click OK. Step 4: Access the USB storage device with the account “samba”. , and enter your account “samba”...

  • Page 108: Interface Grouping

    Access successfully! 4.2.12 Interface Grouping Interface Grouping supports multiple ports to PVC and bridging groups. Each group will perform as an independent network. To support this feature, you must create mapping groups with appropriate LAN and WAN interfaces using the Add button.
  • Page 109 Click Add to enter the screen below:  Group Name: Define a name for group.  WAN Interface used in the grouping: WAN connection to which the interface grouping rules apply.  Available LAN Interfaces: LAN interfaces which are available for interface grouping. ...

  • Page 110: Ip Tunnel

    4.2.13 IP Tunnel This section explains the following information: • IPv6inIPv4 • IPv4inIPv6 IPv6inIPv4 Click IPv6inIPv4 and Add to enter the following screen:  Tunnel Name: Specify the name of the tunnel.  Mechanism: Currently, only 6RD configuration is supported. ...

  • Page 111: Certificate

    IPv4inIPv6 Click IPv4inIPv6 and Add to enter the following screen:  Tunnel Name: Specify the name of the tunnel.  Mechanism: Currently, only DS-Lite configuration is supported.  Associated WAN Interface: Specify the WAN interface of the tunnel.  Associated LAN Interface: Specify the LAN interface of the tunnel. ...
  • Page 112 certificates can be stored. ① To generate a certificate signing request: Click the Create Certificate Request button to enter the page below. ② ③ Specify the Common Name, Organization Name and State/Province Name ④ Enter the 2-letter Country Code for the certificate. Click Apply to apply your settings.
  • Page 113 ② ③ Enter the certificate name. ④ Paste the certificate content and private key. Click Apply to apply your settings. Trusted CA (Certificate Authority) Certificates Here you can add, view or remove CA certificates. CA certificates are used by you to verify peers' certificates. Maximum 4 certificates can be stored.

  • Page 114: Multicast

    ① To Import certificate： Click the Import Certificate button to enter the page below. ② ③ Enter the certificate name. ④ Paste the certificate content. Click Apply to apply your settings. 4.2.15 Multicast Here you can configure the multicast feature. ①...
  • Page 115 ① To configure IGMP for IPv6 ② Check the LAN to LAN (Intra LAN) Multicast Enable box. Keep other options unchanged from factory defaults if you are not an advanced user. This is strongly recommended.

  • Page 116: Iptv

    4.2.16 IPTV If you check the Enable IPTV checkbox, you must choose a layer2 interface, and then configure the PVC info (ATM), or VLAN info (ETH). Click to save it. Enable IPTV: Check to enable the IPTV service, or disable it. ①...

  • Page 117: Wireless

    After successful IPTV configurations, Port 4/iTV on the back panel of the device can only be an IPTV port. _________________________________________________________________________________________________ For tagged service, enter valid 802.1P Priority and 802.1Q VLAN ID. For untagged service, set -1 to both 802.1P Priority and 802.1Q VLAN ID. _________________________________________________________________________________________________ 4.3 Wireless This section explains the following information:...

  • Page 118: Security

     Enable Wireless: check/uncheck to enable/disable the wireless feature.  Hide Access Point (Hide SSID): This option allows you to have your network names (SSID) publicly broadcast. If you choose to enable it, the SSID will be hidden.  SSID: This is the public name of your WiFi. ...
  • Page 119 WPS Setup Wi-Fi Protected Setup makes it easy for home users who know little of wireless security to establish a home network, as well as to add new devices to an existing network without entering long passphrases or configuring complicated settings. Enable WPS: This is WPS ON/OFF turn.
  • Page 120 Manual Setup AP You can set the network authentication method, selecting data encryption, specify whether a network key is required to authenticate to this wireless network and specify the encryption strength. Click when done.  Network Authentication: Select Open, Shared, WPA-PSK, WPA2-PSK or Mixed WPA/ WPA2-PSK from the drop-down list to encrypt your wireless network.

  • Page 121: Mac Filter

    4.3.3 MAC Filter The MAC-based Wireless Access Control feature can be used to allow or disallow clients to connect to your wireless network. MAC Restrict Mode: Disabled, Allow and Deny  Allow: Only allow PCs at specified MAC addresses (in the list) to connect to your wireless network. ...

  • Page 122: Wireless Bridge

    ③ Enter 00:1A:3D:9C:BB:23 in the MAC address box as shown in the figure below, and click Set up successfully! ________________________________________________________________________________________________ NOTE If “Allow” mode is activated with no MAC address being limited, WPS feature will be disabled. Go to Wireless > Security to check WPS status).
  • Page 123 AP Mode: You can select Wireless Bridge (also known as Wireless Distribution System) to disable access point functionality. Selecting Access Point enables access point functionality. Wireless bridge functionality will still be available and wireless stations will be able to associate to the AP. Bridge Action: There are three options available: Enabled, Enabled (Scan) and Disabled.
  • Page 124 ① Before you get started: View and note down the security settings of Router 1: wireless name (SSID), channel, security mode, MAC address and wireless key. Click Advanced > Wireless > Basic to check the SSID, MAC address (BSSID) and Channel. SSID: Tenda_112252 BSSID: 00:90:4C:11:22:53 Channel: 6...
  • Page 125 WPS: Disable Security Mode: WPA2-PSK / AES Wireless Key: 12345678 ② View the LAN settings of Router 1. Click Advanced > Advanced Setup > LAN to check LAN IP address and Subnet Mask, and verify that the DHCP Server is enabled. LAN IP Address: 192.168.1.1;...
  • Page 126 After you prepare two steps above, do as follows: ① Configure Router 2: Set the LAN IP address of Router 2 to a different IP address yet on the same segment as Router 1.  Click Advanced > Advanced Setup > LAN to change the LAN IP address into 192.168.1.10. ...
  • Page 127  Enter the MAC address of Router 1 which you have noted down (00:90:4C:11:22:53).  Then click Apply/Save to save the settings. b. If you select Enable(Scan) in Bridge Action field.  Select the SSID of Router 1 (Tenda_112252) in Remote Bridges MAC Address field. ...
  • Page 128 b. If you select Enable(Scan) in Bridge Action field:  Select the SSID of Router 1 (Tenda_112252) in Remote Bridges MAC Address field. If you cannot find the SSID on the list, click Refresh to refresh the list.  Then click Apply/Save to save your settings. After you fininsh the settings on Router 2 above, do as follows: ①...
  • Page 129  Then click Apply/Save to save the settings. b. If you select Enable(Scan) in Bridge Action field:  Select the SSID of Router 2 (Tenda_112252) in Remote Bridges MAC Address field.  If you cannot find the SSID on the list, click Refresh to refresh the list. ...

  • Page 130: Station Info

    The configuration is finished. Then the devices can only connect Router 2 via Ethernet cables. NOTE The WDS feature (also known as Wireless Bridge) can only be implemented between 2 WDS-capable wireless devices. Plus, SSID, channel, security settings and security key must be exactly the same on both such devices. 4.3.5 Station Info This page shows authenticated wireless stations and their status.

  • Page 131: Diagnostics

    4.4.1 Diagnostics The device is capable of testing the connection to your DSL service provider, the connection to your Internet service provider and the connection to your local network. If a test displays a fail status, click “Rerun Diagnostic Tests” at the bottom of this page to make sure the fail status is consistent.

  • Page 132: Management

    4.5 Management This section explains the following information: • Settings • System Logs • SNMP Agent • TR-069 Client • Internet Time • Access Control • Update Software • Reboot 4.5.1 Settings This section explains the following information: • Backup •...

  • Page 133: System Logs

    Restore Backup Here you can restore the configurations of the modem router from a file saved on your PC. Restore Default Under some circumstances (for example, join a different network or unfortunately forgetting the login password), you may need to remove the existing configuration and restore the factory default settings. 4.5.2 System Logs The System Log dialog allows you to view the system log and configure the system log options.

  • Page 134: Snmp Agent

    To configure the system log, click Configure System Log.  Log: If Enable is selected, the system will begin to log all the selected events.  Log Level: Set the log level. All events above or equal to the selected level will be logged. ...

  • Page 135: Client

    SNMP Agent：Select “Enable” to activate the SNMP Agent feature or “Disable” to deactivate it.   Read Community: Specify a Read Community string. The default is public.  Set Community: Specify a Set Community string. The default is private.  System Name: Specify a descriptive system name.

  • Page 136: Internet Time

     Inform: Select Enable/Disable to enable/disable the TR-069 Client function. By default, it is disabled.  Inform Interval: Specify the inform interval.  ACS URL: Enter the ACS (Auto-Configuration Server) URL address.  ACS User Name: Enter the ACS (Auto-Configuration Server) user name. ...

  • Page 137: Access Control

    4.5.6 Access Control This section explains the following information: • Password • AccessControl - Service Password Access to your broadband router is controlled through two user accounts: admin and support. Admin has unrestricted access to change and view configuration of your Broadband Router. Support is used to allow a professional technician to access your Broadband Router for maintenance and to run diagnostics.

  • Page 138: Update Software

    Access Control - Service Here you can manage the device either from LAN or WAN side using HTTP, ICMP, TELNET, SNMP, FTP, TFTP and HTTPS. _________________________________________________________________________________________________ NOTE If you are not an advanced user, it is recommended to keep the default settings. ________________________________________________________________________________________________ 4.5.7 Update Software Firmware upgrade is released periodically to improve the functionality of your device and add any new features.
  • Page 139 This modem router supports three types to update firmware. Type 1: General Update ① To update software, do as follows: Obtain an updated software image file from our website: www.tendacn.com.
  • Page 140 ② Click the "Browse" button to locate the firmware file. ③ Click to start updating. Type 2: Updating Via FTP Server Updating via FTP server is supported. Make sure there is an available FTP server. ① ② Type the FTP Server IP address, like the right figure ③...

  • Page 141: Reboot

    NOTE The update process will cost 2 minutes, and the device will reboot. 4.5.8 Reboot Click the Reboot button to reboot the router.

  • Page 142: Appendix 1 Applications

    Appendix 1 Applications Application 1: How to change SSID and wireless password? ① ② Go to Wireless > Basic interface. ③ Specify a SSID as you like, like Tenda_myhome. Click Apply/Save to save the settings. ④ ⑤ Go to Wireless > Security interface. ⑥...

  • Page 143: Application 2: How To Reset The Modem Router

    Application 2: How to reset the modem router? The device supports two methods to reset to factory defaults. Note that after you reset the device, you should reconfigure it for Internet service. Method 1: WPS/RST button Press the WPS/RST button on the back of the modem router for about 8 seconds to reset it to factory defaults. Method 2: Restore Default Settings from User Interface ①...

  • Page 144: Appendix 2 Configure Your Pc

    Appendix 2 Configure Your PC This part is just for your references when your computer connecting to the modem router cannot get an IP address. Screens to configure TCP/IP properties in other Operating Systems are similar to those below. Windows 8 Right click the icon on the bottom right corner of your desktop.
  • Page 145 Find and double click Internet Protocol Version 4(TCP/IPv4). Select Obtain an IP address automatically and Obtain DNS server address automatically and click OK. Click OK on the Ethernet Properties window (see Step 4 for the screenshot).

  • Page 146: Windows 7

    Windows 7 Click the icon on the bottom right corner of your desktop. Click Open Network and Sharing Center. Click Local Area Connection > Properties. Find and double click Internet Protocol Version 4(TCP/IPv4).
  • Page 147 Select Obtain an IP address automatically and Obtain DNS server address automatically and click OK. Click OK on the Local Area Connection Properties window (see Step 4 for the screenshot).

  • Page 148: Mac

    1. Click on the Apple icon from the top-left corner and select System Preferences. 2. Click Network. 3. Click on Ethernet. 4. Select Using DHCP. 5. Click Apply.

  • Page 149: Appendix 3 Join Your Wireless Network

    Appendix 3 Join Your Wireless Network Windows 8 Click the icon on the bottom right corner of your desktop. TIP: 1. If you cannot find the icon , please move your mouse to the top right corner of your desktop, select Settings >...

  • Page 150: Windows 7

    Windows 7 Click the icon on the bottom right corner of your desktop. Double click your SSID (wireless network name) and then follow onscreen instructions. When your SSID (wireless network name) displays Connected as shown below, you’ve connected to it for Internet access successfully.

  • Page 151: Mac

    Click > System Preferences. Select Network from Internet & Network. Click WiFi. Turn WiFi on. Click No network selected. Select the wireless network name of your router. Enter the wireless password and click Join.

  • Page 152: Iphone/Ipad

    iPhone/iPad Scroll screen to find the Settings icon and click it. Click WiFi, and turn on WiFi. Find the name of the wireless network you wish to connect, and click it. Enter the wireless password and click Join. Connected successfully!

  • Page 153: Appendix 4 Faqs

    Appendix 4 FAQs What information should I have to access the Internet via the DSL uplink? If you have DSL broadband service, you might need the following information to set up your modem router. • Active Internet service provided by a DSL account •...

  • Page 154: Appendix 5 Vpi/Vci List

    Appendix 5 VPI/VCI List The following table lists common ISPs and their VPI and VCI numbers. If you cannot locate your ISP and their VPI and VCI information here, ask your ISP to provide it. Country Encapsulation Australia Telstra PPPoA LLC Australia GoldenIT PPPOA_VCMUX...
  • Page 155 Country Encapsulation Brazil Telmar PPPoE LLC Brazil South Region PPPoE LLC Canada Primus Canada PPPoE LLC Canada Rogers Canada (1) PPPoE LLC Canada Rogers Canada (2) 1483 Bridged IP LLC Canada Rogers Canada (3) 1484 Bridged IP LLC Canada BellSouth(1) Canada PPPoE LLC Canada BellSouth(2) Canada...
  • Page 156 Country Encapsulation Hungary Sci-Network PPPoE LLC Iceland Islandssimi PPPoA VC-MUX Iceland Siminn PPPoA VC-MUX India Airtel 1483 Bridged IP LLC India BSNL 1483 Bridged IP LLC India MTNL 1483 Bridged IP LLC RELIANCE India PPPOE LLC COMMUNICATION India TATA INDICOM PPPOE LLC India CONNECT...
  • Page 157 Country Encapsulation Israel(1) PPPoA VC-MUX Italy 1483 Bridged IP LLC Italy PPPoA VC-MUX Jamaica (1) PPPoA VC-MUX Jamaica (2) PPPoA VC-MUX Jamaica (3) 1483 Bridged IP LLC SNAP Jamaica (4) 1483 Bridged IP LLC SNAP Kazakhtelecom Kazakhstan LLC/SNAP Bridging «Megaline» Kazakhstan PPPoA VC-MUX kuwait unitednetwork...
  • Page 158 Country Encapsulation Philippines(1) 1483 Bridged IP LLC Philippines(2) 1483 Bridged IP LLC Portugal PPPoE LLC Puerto Rico Coqui.net PPPoA LLC RomTelecom Romania: 1483 Bridged IP LLC Russia Rostel PPPoE LLC Russia Port telecom PPPoE LLC Russia VNTC PPPoE LLC Saudi Arabia (1) PPPoE LLC Saudi Arabia (2) PPPoE LLC...
  • Page 159 Country Encapsulation Spain Wanadoo (2) PPPoE LLC Spain Terra 1483 Bridged IP LLC/SNAP Spain Terra 1483 Bridged IP LLC/SNAP Spain Uni2 1483 Bridged IP VC-MUX Spain Orange 1483 Bridged IP VC-MUX Spain Orange 20 Megas LLC-BRIDGING Spain Orange 1483 Bridged IP LLC/SNAP Spain Ya.com 1483 Bridged IP VC - MUX...
  • Page 160 Country Encapsulation United States Ameritech PPPoA LLC United States AT&T (1) PPPoE LLC United States AT&T (2) 1483 Bridged IP LLC United States AT&T (3) 1483 Bridged IP LLC United States August.net (1) 1483 Bridged IP LLC United States August.net (2) 1483 Bridged IP LLC United States BellSouth...
  • Page 161 Country Encapsulation United States Sonic 1484 Bridged IP LLC United States SouthWestern Bell 1483 Bridged IP LLC United States Sprint (1) PPPoALLC United States Sprint (2) PPPoE LLC United States Sprint Territory PPPoE LLC SureWest United States 1483 Bridged LLC Snap Communications(1) SureWest United States...
  • Page 162 Country Encapsulation Australia Telstra PPPoA LLC Australia GoldenIT _PPPOA_VCMUX Australia Telstra Bigpond PPPOE_LLC Australia OptusNET PPPOE_VCMUX Australia AAPT PPPOE_VCMUX Australia ADSL Direct PPPOE_LLC Australia Ausie Broadband PPPOE_LLC Australia Australia On Line PPPOA_VCMUX Australia Connexus PPPOE_LLC Australia Dodo PPPOE_LLC Australia Gotalk PPPOE_VCMUX Australia Internode...
  • Page 163 Country Encapsulation Canada Rogers Canada (3) 1484 Bridged IP LLC Canada BellSouth(1) Canada PPPoE LLC Canada BellSouth(2) Canada PPPoE LLC Canada Sprint (1) Canada PPPoA LLC Canada Sprint (2) Canada PPPoE LLC Canada Verizon (1) Canada PPPoE LLC Canada Verizon (2) Canada 1483 Bridged IP LLC Colombia EMCALI...
  • Page 164 Country Encapsulation India MTNL 1483 Bridged IP LLC RELIANCE India PPPOE LLC COMMUNICATION India TATA INDICOM PPPOE LLC India CONNECT PPPOE LLC Indonesia Speedy PPPoE LLC Telkomnet [Shatel] Iran PPPOE LLC Aria-Rasaneh-Tadbir Iran Asia-Tech PPPOE LLC Iran Pars-Online (Tehran) PPPOE LLC Iran Pars-Online (Provinces) PPPOE LLC...
  • Page 165 Country Encapsulation Jamaica (3) 1483 Bridged IP LLC SNAP Jamaica (4) 1483 Bridged IP LLC SNAP Kazakhtelecom Kazakhstan LLC/SNAP Bridging «Megaline» Kazakhstan PPPoA VC-MUX kuwait unitednetwork 1483 Bridged IP LLC Malaysia Streamyx PPPOE LLC Malaysia PPPoE LLC Mexico Telmex (1) PPPoE LLC Mexico Telmex (2)
  • Page 166 Country Encapsulation Russia Rostel PPPoE LLC Russia Port telecom PPPoE LLC Russia VNTC PPPoE LLC Saudi Arabia (1) PPPoE LLC Saudi Arabia (2) PPPoE LLC Saudi Arabia (3) 1483 Bridged IP LLC Saudi Arabia (4) 1483 Routed IP LLC Saudi Arabia (5) 1483 Bridged IP LLC Saudi Arabia (6) 1483 Routed IP LLC...
  • Page 167 Country Encapsulation Spain Orange 20 Megas LLC-BRIDGING Spain Orange 1483 Bridged IP LLC/SNAP Spain Ya.com 1483 Bridged IP VC - MUX Spain Ya.com 1483 Bridged IP LLC/SNAP Spain Wanadoo (3) 1483 Routed IP LLC SpainWanadoo 1483 Bridged IP LLC Sri Lanka PPPOE LLC Telecom-(SLT) Sweden...
  • Page 168 Country Encapsulation United States August.net (2) 1483 Bridged IP LLC United States BellSouth PPPoE LLC United States Casstle.Net 1483 Bridged IP LLC United States CenturyTel (1) PPPoE LLC United States CenturyTel (2) 1483 Bridged IP LLC United States Coqui.net PPPoA LLC United States Covad PPPoE LLC...
  • Page 169 Country Encapsulation SureWest United States 1483 Bridged LLC Snap Communications(1) SureWest United States PPPoE LLC Communications(2) SureWest United States PPPoA LLC Communications(3) United States Toast.Net PPPoE LLC United States Uniserv 1483 Bridged IP LLC United States US West PPPoA VC-MUX United States Verizon (1) PPPoE LLC...

  • Page 170: Appendix 6 Regulatory Compliance Information

    Appendix 6 Regulatory Compliance Information CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment.
