IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
A.
B.
Side Panel
Side Panel
1 pc.
1 pc.
M.
Shelf
1 pc.
K.
Base
1 pc.
Hardware List
M6x35
Head Cap Bolt
Hex Wrench
4 pcs. (+1 extra)
1 pc.
M6x50
Small Hex Wrench
Head Cap Bolt (long)
1 pc.
4 pcs. (+1 extra)
5
001
Top carton is also needed for assembly.
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8" Drill Bit
home
5001-006
Buffet
C.
Front Rail
1 pc.
E.
Front Upright
1 pc.
D.
Front Rail
1 pc.
H.
Back Upright
1 pc.
Cam Lock
10 pcs. (+2 extra)
Cross Dowel
4 pcs. (+1 extra)
styles Customer Service: www.homestylesfurniture.com,
servicedesk@homestylesfurniture.com,
F.
Back Rail
1 pc.
G.
I.
Divider
Back Rail
1 pc.
1 pc.
J.
Back Panel
2 pcs.
M3.5x13
Wood Screw (short)
Cam Lock Screw
8 pcs. (+1 extra)
1 pcs. (+1 extra)
0
M3.5x25
Adjustable Pin
Wood Screw (long)
4 pcs. (+2 extra)
16 pcs. (+1 extra)
888-680-7460
N.
Door
1 pc.
P.
Drawer
2 pcs.
Refer to later page(s) of these
instructions for drawer assembly.
M4x25
Machine Screw
6 pcs.
M3.5x16
Wood Screw
for Back Panel
8 pcs. (+1 extra)
L.
Leg
2 pcs.
O.
Door
1 pc.
Knob
2 pcs.
Handle
2 pcs.
