IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
A.
Top
1 pc.
C.
Front Panel
1 pc.
H.
Front Panel
2 pcs.
For assembly see instructions in carton 500 992.
home
500 991
3-
Bar
I.
Front Panel
1 pc.
styles Customer Service: www.homestylesfurniture.com,
servicedesk@homestylesfurniture.com,
B.
Sub Top
1 pc.
E.
Glass Holder
1 pc.
N.
Door
1 pc.
3-
888-680-7460
