Summary of Contents for MiTAC 5114VU

  • Page 1 5114VU Motherboard Reference Part Number : 5615 7026 0001 R00 (Jul. 2000)
  • Page 2 Trademarks All brand and product names are trademarks or registered trademarks of their respective companies. Note The information in this guide is subject to change without notice.
  • Page 3 Caution Texts Concerning Lithium Batteries DANISH ADVARSEL! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren. NORWEGIAN ADVARSEL: Eksplosjonsfare ved feilaktig skifte av batteri. Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten.
  • Page 4 Class B Regulations U. S. A. Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 5 Important Safety Instructions • Read all of these instructions. • Follow all warnings and instructions marked on the product. • Unplug this product from the wall outlet before installing an add-on card inside this product. • Do not use this product near water. •...
  • Page 6: Table Of Contents

    Table of Contents Preface ...................... 9 Chapter 1 Introduction............... 10 Features ..................10 Specifications ................10 CPU, Memory, and Main Components ........10 Interfaces and Controllers............11 Chapter 2 System Components ............12 Major Components...............12 Chapter 3 Connector and Jumper Definition........16 Connector Definitions..............17 Internal Connectors..............17 External Connectors ...............17 Jumper Settings ................18...
  • Page 7 Appendix A Software Drivers and Utilities .........33 Installation Instructions for Windows 98 ........33 Audio Driver ................33 Video Driver ................33 Installation Instructions for Windows NT 4.0 ....... 34 Audio Driver ................34 Video Driver ................34...
  • Page 8 List of Figures Figure 2-1. Major Components of System Board......12 Figure 3-1. Connector and Jumper Locations......16 Figure 4-1. Inserting CPU ............19 Figure 4-2. Installing CPU ............20 Figure 4-3. DIMM Socket Locations..........21 Figure 4-4. Installing DIMM Module ..........22 List of Tables Table 2-1.
  • Page 9: Preface

    Preface This manual contains basic information necessary for both the end user and service personnel. Although most of the information you need are contained in this manual, we recommend you to contact an authorized dealer for service purposes. Making personal alterations to the system can violate the effectivity of your warranty.
  • Page 10: Chapter 1 Introduction

    Chapter 1 Introduction This chapter introduces the specifications and the features of the motherboard. Features • Socket 7 For AMD K6-2 / K6 III CPU • Plug and Play support For automatic resource assignment, your system is PnP version 1.01a compliant.
  • Page 11: Interfaces And Controllers

    • Cache 512KB cache memory • ROM BIOS 2Mb flash EEPROM, supporting audio, video, security, setup, and power management Interfaces and Controllers • VIA MVP4 chipset The chipset consists of the VT82C8501 north bridge and the VT82C686A PCI Super I/O Integrated Peripheral controller. •...
  • Page 12: Chapter 2 System Components

    Chapter 2 System Components This chapter introduces the components of the motherboard. Major Components ES1989 TAG1 TAG RAM Socket 7 PCI Slots VT82C8501 Cache DIMM Sockets VT82C686A ROM BIOS Figure 2-1. Major Components of System Board...
  • Page 13: Table 2-1. Major Components Description

    Reference Description Name The PCI audio drive controller features: ES1989 • 16-bit stereo CODEC • Mic-in, Line-in, Line-out support • Multi-stream Direct Sound and Direct Sound 3D acceleration • AC-3 speaker virtualization • S/PDIF output for DVD content • Full legacy DOS game support VT82C8501 North Bridge provides: VT82C8501 North Bridge...
  • Page 14 (Continued) Reference Description Name VT82C686A PCI Super I/O Integrated Peripheral VT82C686A Controller provides: Super South Bridge • PC98 Compliant PCI to ISA bridge • IDE controller • Power management controller • DMA33 / ATA-66 controller • Interrupt controller • 82C54 based timer •...
  • Page 15 (Continued) Reference Description Name Socket 7 AMD K6 processor features: • Advanced 6 issue RISC86 superscalar microarchitecture - ten parallel specialized execution units - multiple x86 to RISC86 instruction decoders - advanced two-level branch prediction - speculative execution - out of order execution - register renaming and data forwarding - issues up to six RISC86 instructions per clock •...
  • Page 16: Chapter 3 Connector And Jumper Definition

    Chapter 3 Connector and Jumper Definition This chapter defines the connectors and jumpers on the motherboard. Line-in MIC-in Line-out VGA1 COM1 USB1 GAME1 BAT1 FAN1 PCI1 PCI2 PCI3 PCI4 JP11 JP10 JP13 JP14 JP12 JP15 DIMM1 DIMM2 FAN2 IDE1 IDE2 FDD1 Figure 3-1.
  • Page 17: Connector Definitions

    Connector Definitions Internal Connectors Connector Definition pin 3-4 Sleep LED pin 5-6 HDD LED pin 11-13 Power LED pin 15-16 Power button pin 19-20 Reset BAT1 Battery Power supply DIMM 1~2 DIMM sockets FAN1 CPU fan FDD1 IDE1, IDE2 PCI 1~4 PCI slots Socket 7 CPU socket...
  • Page 18: Jumper Settings

    Jumper Settings NOTE: Jumpers not described in this chapter are reserved for factory use only. Do not change the default settings. AMD K6 Jumper Settings JP10 JP11 JP12 JP13 JP14 JP15 K6-2/K6 III close open close open close open open open close close...
  • Page 19: Chapter 4 Cpu And Memory Installation

    Chapter 4 CPU and Memory Installation NOTE: To avoid damage during installation, you are advised to ask your dealer for help. NOTE: Static electricity can destroy electronic devices. Whenever you handle any option outside of its protective packaging, first discharge any static electricity from your body by touching a protective grounding device or unpainted metal on the rear panel of the system unit.
  • Page 20: Figure 4-2. Installing Cpu

    4. Press the arm downwards to the horizontal position. You will feel some resistance while doing so. This is normal as the pressure starts to secure the CPU in place. Figure 4-2. Installing CPU...
  • Page 21: System Memory Installation

    System Memory Installation 1. Locate the DIMM sockets (DIMM1 ~ DIMM2) on the motherboard. TAG RAM Cache DIMM Sockets DIMM1 DIMM2 Figure 4-3. DIMM Socket Locations...
  • Page 22: Figure 4-4. Installing Dimm Module

    2. Align the DIMM module with the socket and firmly insert the DIMM into the socket. Then, push the plastic clips to snap it into place. Figure 4-4. Installing DIMM Module...
  • Page 23: Chapter 5 The Setup Program

    Chapter 5 The SETUP Program This chapter tells you how to configure your system using the SETUP program. Introduction The SETUP program allows you to enter the system configuration information. This information is needed by the system to identify the type of devices installed and to set up special features.
  • Page 24: Moving Around And Making Selections

    Moving Around and Making Selections In general, you use the arrow keys to highlight items and the [PageUp]/[+] and [PageDown]/[−] keys to change entries. Description of keyboard usage is listed below. You can also find keyboard instructions on the menu screen. Description [!], ["] Move the highlight to the previous or next item.
  • Page 25: Standard Cmos Features

    Standard CMOS Features The “Standard CMOS Features” category includes all the items in a standard, AT-compatible BIOS (Basic Input/Output System). The followings describe in sequence all the items of this category. Date/Time The date and time might be incorrect when you start up your computer for the first time.
  • Page 26: Advanced Bios Features

    Advanced BIOS Features The “Advanced BIOS Features” category includes all the items of your system’s special enhanced features. The followings describe in sequence all the items of this category. Virus Warning This item helps prevent computer viruses by monitoring the boot sector and partition table of the hard disk drive.
  • Page 27 Boot Up Floppy Seek This item sets if the system will verify the floppy disk drive type during POST. Boot Up Numlock Status This item sets if the Num Lock key will be automatically activated after system startup. Gate A20 Option This item uses the fast gate A20 line to access any memory above 1MB.
  • Page 28: Advanced Chipset Features

    OS Select for DRAM > 64MB This item allows you to access the memory that is over 64MB in OS/2. Video BIOS Shadow This item sets if the video BIOS will be copied to RAM to increase the video speed. C8000-CBFFF Shadow These items set if ROMs on an expansion card will be copied to RAM for faster speed.
  • Page 29 Primary/Secondary Master/Slave PIO Each of these four items sets the mode timing according to the IDE hard disk drives in your system. PIO means Programmed Input/Output. Rather than have the BIOS issue a series of commands to effect a transfer to or from the disk drive, PIO allows the BIOS to tell the controller what it wants and then let the controller and the CPU perform the complete task by themselves.
  • Page 30: Power Management Setup

    Power Management Setup The “Power Management Setup” category allows you to configure you system to save energy. The followings describe in sequence all the items of this category. ACPI Function This item enables or disables ACPI (Advanced Configuration Power Interface) - a power management standard used by Windows 98 and Windows NT 5.0.
  • Page 31: Pnp/Pci Configurations

    PnP/PCI Configurations The “PnP/PCI Configurations” category allows you to configure the PnP/PCI bus system. PnP (Plug and Play) allows automatic allocation of the IRQ channel, memory address and I/O address for your system so that manual selection is not necessary. PCI (Personal Computer Interconnect) is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components.
  • Page 32: Set Supervisor Password/User Password

    Set Supervisor Password/User Password You can set either supervisor or user password, or both of them. The differences between them are: • Supervisor password can enter and change the options of the setup menus. • User password can only enter but do not have the right to change the options of the setup menus.
  • Page 33 Windows 98, follow these steps: 1. Insert the driver and utility CD into the CD-ROM drive. 2. Run the SETUP.EXE program in the \5114VU\AUDIO\WIN9598 directory on the driver and utility CD. 3. Follow the on-screen instructions.
  • Page 34 3. Select “Unlisted or Updated Driver” and click on “OK”. 4. Insert the CD into the CD-ROM drive. 5. Specify the path \5114VU\AUDIO\NT4.0 on the CD, choose the driver from the list, and click on “OK”. 6. Follow the on-screen instructions. Select “Use Dual DMA” or “Enable MPU401”...
  • Page 35 5. Specify the path \5114VU\VGA\NT4.0 on the CD, and click on “OK”. 6. Follow the on-screen instructions. You have to decompress the drivers and select the appropriate one according to your system specifications: For AGP – AGPVXD32 For mini port -...
