light load
under inflated
If left unchecked, the mounts will deflate over time. To maintain correct inflation, check the gap every two weeks
B Removal
Breadboards should be manipulated only using appropriate lifting equipment.
Breadboards should be lifted only in an unpopulated condition.
Before removing the breadboard, ensure that all pressure is vented from the passive mounts. Failure to vent the
pressure may cause the mounts to rupture when the load is removed.
To remove the breadboard, reverse the installation procedure.
12mm
correctly inflated
Caution
and reinflate the system as necessary.
Fig. 3.6 Correct inflation of passive mounts
Warning
Caution
ScienceDesk Workstation
heavy load
12mm
over inflated
9
