MOUNTING/WIRING
SUBHEAD
FMS-1655L Surface Mount Display
5.05"
The FMS-1655L display backplate may be mounted directly to a standard single-gang wall
box using the two slots along the centerline. Use the backplate as a template to mark the
mounting holes and the cable access hole at the center of the backplate.
Due to continuous improvement, JCI reserves the right to change product specifications without notice.
3.04"
-
10
-
ø 0.143"
ø 0.750"
ø 0.143"
