Install the ION 9000
STEP 2 | Aach the slide rail to a standard 19-inch rack
1. Select a 1-RU slot to insert the slide rail to the rack.
2. Align the rail end marked REAR to the rear side of the rack.
3. Insert the screws on the rails in the screw holes of the rack and ensure that the metal
clasp secures the rails to the rack post.
If the screws are aached to the rails, do not detach the screws from the rails
before inserng in the racks.
If the rack has threaded round holes:
1. Use fing pins in the rack mounng kit and screw them through the rack holes.
2. Screw the fing pins through the rails.
3. Aach the chassis-mounng brackets to either side of the ION 9000.
4. Slide the ION 9000 into the rack and confirm that the device is installed securely.
If the rack has unthreaded round holes:
1. Insert the rail behind the hole plate.
2. Secure the rail onto the mounng plates of the rack using screws from the installaon
kit.
3. Aach the chassis-mounng brackets to either side of the ION 9000.
4. Slide the ION 9000 into the rack and confirm that the device is installed securely.
4. On the front side of the racks, snap the rails in place by inserng the screws in the rack.
Ensure that the spring retenon clip is fully engaged, so that the rail is securely aached
to the rack.
