ION 9000 Overview

Power on the ION 9000

Connect the power cables to the ION device and plug the device power cable into an AC power
outlet. When you switch on the power, the device is powered on and the power indicator turns
green.

Shut down the ION 9000

Shut down the ION 9000 in the following ways:
• Shut down using the Device Toolkit commands
Run the device toolkit command debug shutdown to shut down the device.
Ensure the device is physically accessible to turn it back on, before execung the
command.
• Shut down using the Power Switch
Press the power switch 5 mes (press and hold for 1 second, then, release) to shut down the
device.

Reboot the ION 9000

Press the power switch 3 or 4 mes to reboot the ION 9000.
