Install the ION 9000
STEP 1 | Aach the rack-mount brackets to the ION 9000
1. Unpack the installaon kit and retrieve the rails.
2. Remove the chassis mounng brackets from the rails by extending the bracket out and
sliding the bracket release buon towards the front to fully withdraw it from the rails.
The ION 9000 uses the chassis mounng brackets to aach to the slide rails for
mounng on the rack.
3. Aach the mounng brackets to both sides of the ION 9000.
4. Retrieve the slide lock ears from the ION 9000 accessory kit.
The slide lock ears aach to the front of the ION 9000 and lock the device in place in the
rack.
